Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 78 —
D216 8-719-032-86DIODE SEL5420E
D217 8-719-056-13DIODE SML79423C-TP15 (DISC 1)
D218 8-719-056-13DIODE SML79423C-TP15 (DISC 1)
D219 8-719-056-13DIODE SML79423C-TP15 (DISC 1)
D220 8-719-056-13DIODE SML79423C-TP15 (DISC 2)
D221 8-719-056-13DIODE SML79423C-TP15 (DISC 2)
D222 8-719-056-13DIODE SML79423C-TP15 (DISC 2)
D223 8-719-056-13DIODE SML79423C-TP15 (DISC 3)
D224 8-719-056-13DIODE SML79423C-TP15 (DISC 3)
D225 8-719-056-13DIODE SML79423C-TP15 (DISC 3)
D226 8-719-056-13DIODE SML79423C-TP15 (^)
D227 8-719-056-13DIODE SML79423C-TP15 (^)
< TRANSISTOR >
Q205 8-729-027-23TRANSISTOR DTA114EKA-T146
Q206 8-729-027-23TRANSISTOR DTA114EKA-T146
Q207 8-729-027-23TRANSISTOR DTA114EKA-T146
Q208 8-729-027-23TRANSISTOR DTA114EKA-T146
Q209 8-729-027-23TRANSISTOR DTA114EKA-T146
Q210 8-729-027-23TRANSISTOR DTA114EKA-T146
Q211 8-729-027-23TRANSISTOR DTA114EKA-T146
Q212 8-729-027-23TRANSISTOR DTA114EKA-T146
Q213 8-729-027-23TRANSISTOR DTA114EKA-T146
Q214 8-729-027-23TRANSISTOR DTA114EKA-T146
Q215 8-729-027-23TRANSISTOR DTA114EKA-T146
Q216 8-729-027-23TRANSISTOR DTA114EKA-T146
Q217 8-729-027-23TRANSISTOR DTA114EKA-T146
Q218 8-729-027-23TRANSISTOR DTA114EKA-T146
< RESISTOR >
R234 1-216-033-00METAL CHIP 220 5% 1/10W
R235 1-216-033-00METAL CHIP 220 5% 1/10W
R236 1-216-033-00METAL CHIP 220 5% 1/10W
R237 1-216-033-00METAL CHIP 220 5% 1/10W
R238 1-216-033-00METAL CHIP 220 5% 1/10W
R239 1-216-033-00METAL CHIP 220 5% 1/10W
R244 1-216-033-00METAL CHIP 220 5% 1/10W
R245 1-216-033-00METAL CHIP 220 5% 1/10W
R246 1-216-033-00METAL CHIP 220 5% 1/10W
R247 1-216-033-00METAL CHIP 220 5% 1/10W
R248 1-216-033-00METAL CHIP 220 5% 1/10W
R249 1-216-033-00METAL CHIP 220 5% 1/10W
R254 1-216-033-00METAL CHIP 220 5% 1/10W
R255 1-216-033-00METAL CHIP 220 5% 1/10W
R256 1-216-033-00METAL CHIP 220 5% 1/10W
R257 1-216-033-00METAL CHIP 220 5% 1/10W
R258 1-216-033-00METAL CHIP 220 5% 1/10W
R259 1-216-033-00METAL CHIP 220 5% 1/10W
R264 1-216-033-00METAL CHIP 220 5% 1/10W
R265 1-216-033-00METAL CHIP 220 5% 1/10W
R266 1-216-033-00METAL CHIP 220 5% 1/10W
R267 1-216-033-00METAL CHIP 220 5% 1/10W
R268 1-216-033-00METAL CHIP 220 5% 1/10W
R269 1-216-033-00METAL CHIP 220 5% 1/10W
R274 1-216-033-00METAL CHIP 220 5% 1/10W
R275 1-216-033-00METAL CHIP 220 5% 1/10W
R276 1-216-033-00METAL CHIP 220 5% 1/10W
R277 1-216-033-00METAL CHIP 220 5% 1/10W
R278 1-216-017-91METAL GLAZE 47 5% 1/10W
R279 1-216-021-00METAL CHIP 68 5% 1/10W
R280 1-216-025-91METAL GLAZE 100 5% 1/10W
R281 1-216-029-00METAL CHIP 150 5% 1/10W
R282 1-216-029-00METAL CHIP 150 5% 1/10W
R283 1-216-033-00METAL CHIP 220 5% 1/10W
R284 1-216-037-00METAL CHIP 330 5% 1/10W
R285 1-216-041-00METAL CHIP 470 5% 1/10W
R286 1-216-045-00METAL CHIP 680 5% 1/10W
R287 1-216-049-91METAL GLAZE 1K 5% 1/10W
R288 1-216-053-00METAL CHIP 1.5K 5% 1/10W
R289 1-216-057-00METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S270 1-762-750-11SWITCH, TACTILE (fl CD NON-STOP)
S271 1-762-750-11SWITCH, TACTILE (6 OPEN/CLOSE)
S272 1-762-750-11SWITCH, TACTILE (p)
S273 1-762-750-11SWITCH, TACTILE (SELECT)
S274 1-762-750-11SWITCH, TACTILE (DISC 3)
S275 1-762-750-11SWITCH, TACTILE (DISC 2)
S276 1-762-750-11SWITCH, TACTILE (DISC 1)
S277 1-762-750-11SWITCH, TACTILE (RETURN)
S278 1-762-750-11SWITCH, TACTILE ())
S279 1-762-750-11SWITCH, TACTILE (0)
S280 1-762-750-11SWITCH, TACTILE (DISC SKIP EX-CHANGE)
S281 1-762-750-11SWITCH, TACTILE (PREV)
S282 1-762-750-11SWITCH, TACTILE (NEXT)
************************************************************
* 1-658-575-11CONNECTOR, BOARD
*****************
< CONNECTOR >
* CN701 1-568-946-11PIN, CONNECTOR 8P
CN702 1-750-413-11CONNECTOR, FFC/FPC 8P
< TRANSISTOR >
Q701 8-729-900-80TRANSISTOR DTC114ES
< RESISTOR >
R703 1-249-435-11CARBON 33K 5% 1/4W
R704 1-249-429-11CARBON 10K 5% 1/4W
R705 1-249-417-11CARBON 1K 5% 1/4W F
************************************************************
* 1-650-669-11LEAF SWITCH BOARD
*****************
< CONNECTOR >
* CN1001 1-568-854-11SOCKET, CONNECTOR 11P
CN1001 1-695-372-31PIN, CONNECTOR (PC BOARD) 11P
< TRANSISTOR >
Q1001 8-749-010-90TRANSISTOR PHOTO REFLECTOR
NJL5165KA-H
Q1002 8-749-010-90TRANSISTOR PHOTO REFLECTOR
NJL5165KA-H
< RESISTOR >
R1001 1-247-818-11CARBON 300 5% 1/4W
R1002 1-247-820-11CARBON 360 5% 1/4W
R1003 1-249-414-11CARBON 560 5% 1/4W F
R1004 1-247-834-11CARBON 1.3K 5% 1/4W
R1005 1-247-818-11CARBON 300 5% 1/4W
LEAF SWITCHCONNECTORCD PANEL
