Ref. No.Part No. Description Remarks Ref. No. Part No. Description Remarks
— 79 —
< SWITCH >
S1001 1-692-832-11SWITCH, PUSH (1 KEY) (A PLAY)
S1002 1-692-832-11SWITCH, PUSH (1 KEY) (B PLAY)
S1004 1-571-281-21SWITCH, LEAF (A HALE)
S1005 1-571-281-21SWITCH, LEAF (A CrO2)
S1006 1-572-248-11SWITCH, LEAF (REC A)
S1007 1-572-248-11SWITCH, LEAF (B HALE)
S1008 1-571-281-21SWITCH, LEAF (B CrO2)
S1009 1-571-281-21SWITCH, LEAF (REC B)
************************************************************
* A-4403-279-AMAIN BOARD, COMPLETE (MY,SP,KR,HK,CH)
*********************
* A-4403-712-AMAIN BOARD, COMPLETE (TH)
*********************
* A-4403-716-AMAIN BOARD, COMPLETE (IA)
*********************
< CAPACITOR >
C001 1-164-159-11CERAMIC 0.1uF 50V
(MY,SP,KR,HK,CH)
C127 1-162-282-31CERAMIC 100P 10% 50V
C128 1-162-306-11CERAMIC 0.01uF 20% 16V
C129 1-126-933-11ELECT 100uF 20% 10V
C130 1-162-282-31CERAMIC 100P 10% 50V
C131 1-164-159-11CERAMIC 0.1uF 20% 50V
(MY,SP,KR,HK,CH)
C132 1-164-159-11CERAMIC 0.1uF 20% 50V
(MY,SP,KR,HK,CH)
C133 1-164-159-11CERAMIC 0.1uF 20% 50V
C134 1-164-159-11CERAMIC 0.1uF 20% 50V
(MY,SP,KR,HK,CH)
C135 1-162-290-31CERAMIC 150P 10% 50V
(MY,SP,KR,HK,CH)
C136 1-162-290-31CERAMIC 220P 10% 50V
(MY,SP,KR,HK,CH)
C137 1-164-159-11CERAMIC 0.1uF 20% 50V
C138 1-126-933-11ELECT 100uF 20% 10V
C139 1-128-551-11ELECT 22uF 20% 25V
C140 1-164-159-11CERAMIC 0.1uF 20% 50V
(MY,SP,KR,HK,CH)
C402 1-162-600-11CERAMIC 0.0047uF30% 16V
C403 1-162-290-31CERAMIC 470PF 10% 50V
C405 1-126-301-11ELECT 1uF 20% 50V
C406 1-137-399-11FILM 0.1uF 5% 50V
C407 1-126-964-11ELECT 10uF 20% 50V
C409 1-126-964-11ELECT 10uF 20% 50V
C411 1-126-301-11ELECT 1uF 20% 50V
C421 1-126-964-11ELECT 10uF 20% 50V
C422 1-126-964-11ELECT 10uF 20% 50V
C423 1-126-933-11ELECT 100uF 20% 10V
C424 1-164-159-11CERAMIC 0.1uF 20% 50V
(MY,SP,KR,HK,CH)
C425 1-164-159-11CERAMIC 0.1uF 20% 50V
(MY,SP,KR,HK,CH)
C426 1-164-159-11CERAMIC 0.1uF 20% 50V
(MY,SP,KR,HK,CH)
C427 1-126-935-11ELECT 470uF 20% 16V
C428 1-126-933-11ELECT 100uF 20% 16V
C429 1-126-933-11ELECT 100uF 20% 10V
C452 1-162-600-11CERAMIC 0.0047uF30% 16V
C453 1-162-290-31CERAMIC 470PF 10% 50V
C455 1-126-301-11ELECT 1uF 20% 50V
C456 1-137-399-11FILM 0.1uF 5% 50V
C457 1-126-964-11ELECT 10uF 20% 50V
C459 1-126-964-11ELECT 10uF 20% 50V
C461 1-126-301-11ELECT 1uF 20% 50V
C702 1-126-961-11ELECT 2.2uF 20% 50V
C752 1-126-961-11ELECT 2.2uF 20% 50V
C813 1-126-967-11ELECT 47uF 20% 10V
C853 1-126-944-11ELECT 3300uF 20% 25V
C854 1-126-944-11ELECT 3300uF 20% 25V
C861 1-126-768-11ELECT 2200uF 20% 16V
C862 1-126-933-11ELECT 100uF 20% 10V
C863 1-126-967-11ELECT 47uF 20% 10V
C867 1-126-967-11ELECT 47uF 20% 10V
C868 1-126-923-11ELECT 220uF 20% 10V
C869 1-126-967-11ELECT 47uF 20% 10V
C870 1-164-159-11CERAMIC 0.1uF 20% 50V
(MY,SP,KR.HK,CH)
C871 1-164-159-11CERAMIC 0.1uF 20% 50V
(MY,SP,KR,HK,CH)
C872 1-126-929-11ELECT 4700uF 20% 6.3V
C873 1-126-933-11ELECT 100uF 20% 10V
C876 1-126-933-11ELECT 100uF 20% 10V
< CONNECTOR >
* CN111 1-568-935-11PIN, CONNECTOR 8P
* CN112 1-568-936-11PIN, CONNECTOR 9P
* CNB108 1-764-017-31HOUSING,CONNECTOR(PC BOARD)17P
(SYSTEM CONT
R
< JACK >
CNJ106 1-770-721-11CONNECTOR, BOARD TO BOARD 4P
< CONNECTOR >
CNP105 1-770-393-11PIN, CONNECTOR (PC BOARD) 9P
CNS101 1-569-060-11SOCKET, CONNECTOR 11P
CNS102 1-568-440-11SOCKET, CONNECTOR 17P
CNS103 1-568-443-11SOCKET, CONNECTOR 13P
CNS104 1-569-324-11SOCKET, CONNECTOR 21P
< DIODE >
D110 8-719-987-63DIODE 1N4148M
D855 8-719-110-08DIODE RD8.2ES-B2 (MY,SP,KR,HK,CH)
D858 8-719-110-08DIODE RD8.2ES-B2 (MY,SP,KR,HK,CH)
D901 8-719-024-99DIODE 11ES2-NTA2B (MY,SP,KR,HK,CH)
D902 8-719-024-99DIODE 11ES2-NTA2B (MY,SP,KR,HK,CH)
D903 8-719-024-99DIODE 11ES2-NTA2B (MY,SP,KR,HK,CH)
D904 8-719-024-99DIODE 11ES2-NTA2B (MY,SP,KR,HK,CH)
< TERMINAL >
* EH01 1-537-738-21TERMINAL, EARTH
< IC >
IC101 8-759-482-60IC uPD780016YGF-016-3BA
IC103 8-759-165-82IC PST600E-T
IC107 8-749-921-12IC GP1F32T (OPTICAL DIGITAL OUT)
IC401 8-759-363-21IC HA12203NT
IC402 8-759-822-09IC LB1641
MAINLEAF SWITCH
