– 100 –
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
EA : Saudi Arabia model
SP : Singapore model
MY : Malaysia model
IA : Indonesia model
TH : Thai model
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
SECTION 9
ELECTRICAL PARTS LIST
Note:
When indicating parts by reference
number, please include the board
name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
3CH AMP
A-4417-794-A 3CH AMP BOARD, COMPLETE
***********************
< CAPACITOR >
C1001 1-126-963-11 ELECT 4.7uF 20% 50V
C1002 1-162-286-21 CERAMIC 220PF 10% 50V
C1003 1-162-282-31 CERAMIC 100PF 10% 50V
C1004 1-104-664-11 ELECT 47uF 20% 10V
C1005 1-128-560-11 ELECT 22uF 20% 100V
C1006 1-136-165-00 FILM 0.1uF 5% 50V
C1007 1-136-495-11 FILM 0.068uF 5% 50V
C1008 1-136-495-11 FILM 0.068uF 5% 50V
C1022 1-162-306-11 CERAMIC 0.01uF 20% 16V
C1051 1-126-963-11 ELECT 4.7uF 20% 50V
C1052 1-162-286-21 CERAMIC 220PF 10% 50V
C1053 1-162-282-31 CERAMIC 100PF 10% 50V
C1054 1-104-664-11 ELECT 47uF 20% 10V
C1055 1-128-560-11 ELECT 22uF 20% 100V
C1056 1-136-165-00 FILM 0.1uF 5% 50V
C1057 1-136-495-11 FILM 0.068uF 5% 50V
C1058 1-136-495-11 FILM 0.068uF 5% 50V
C1081 1-126-963-11 ELECT 4.7uF 20% 50V
C1082 1-162-286-21 CERAMIC 220PF 10% 50V
C1083 1-162-282-31 CERAMIC 100PF 10% 50V
C1084 1-104-664-11 ELECT 47uF 20% 10V
C1085 1-136-495-11 FILM 0.068uF 5% 50V
C1086 1-136-495-11 FILM 0.068uF 5% 50V
< CONNECTOR >
CN1001 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CN1002 1-691-772-11 PLUG (MICRO CONNECTOR) 10P
< DIODE >
D1001 8-719-991-33 DIODE 1SS133T-77
D1021 8-719-991-33 DIODE 1SS133T-77
D1051 8-719-991-33 DIODE 1SS133T-77
D1081 8-719-991-33 DIODE 1SS133T-77
< IC >
IC1001 8-749-015-54 IC STK408-040E
< TRANSISTOR >
Q1001 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q1021 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q1022 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1023 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q1024 8-729-119-78 TRANSISTOR 2SC403SP-51
Q1051 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q1081 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R1001 1-249-417-11 CARBON 1K 5% 1/4W F
R1002 1-249-438-11 CARBON 56K 5% 1/4W
R1003 1-249-412-11 CARBON 390 5% 1/4W F
R1004 1-249-438-11 CARBON 56K 5% 1/4W
! R1005 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R1006 1-217-151-00 METAL 0.22 10% 2W
R1007 1-249-417-11 CARBON 1K 5% 1/4W F
R1008 1-249-431-11 CARBON 15K 5% 1/4W
R1009 1-249-441-11 CARBON 100K 5% 1/4W
R1010 1-260-076-11 CARBON 10 5% 1/2W
R1020 1-247-863-91 CARBON 22K 5% 1/4W
R1021 1-249-435-11 CARBON 33K 5% 1/4W
R1022 1-247-863-91 CARBON 22K 5% 1/4W
R1023 1-249-439-11 CARBON 68K 5% 1/4W
R1024 1-249-441-11 CARBON 100K 5% 1/4W F
R1025 1-247-863-91 CARBON 22K 5% 1/4W
R1026 1-249-429-11 CARBON 10K 5% 1/4W
R1027 1-249-441-11 CARBON 100K 5% 1/4W F
! R1028 1-202-972-61 FUSIBLE 1 5% 1/4W F
R1029 1-249-441-11 CARBON 100K 5% 1/4W
R1030 1-249-441-11 CARBON 100K 5% 1/4W
R1031 1-249-437-11 CARBON 47K 5% 1/4W
R1051 1-249-417-11 CARBON 1K 5% 1/4W F
R1052 1-249-438-11 CARBON 56K 5% 1/4W
R1053 1-249-412-11 CARBON 390 5% 1/4W F
R1054 1-249-438-11 CARBON 56K 5% 1/4W
! R1055 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R1056 1-217-151-00 METAL 0.22 10% 2W
R1057 1-249-417-11 CARBON 1K 5% 1/4W F
R1058 1-249-431-11 CARBON 15K 5% 1/4W
R1059 1-249-441-11 CARBON 100K 5% 1/4W
R1060 1-260-076-11 CARBON 10 5% 1/2W
R1081 1-249-417-11 CARBON 1K 5% 1/4W F
R1082 1-249-438-11 CARBON 56K 5% 1/4W
R1083 1-249-442-11 CARBON 510 5% 1/4W
R1084 1-249-438-11 CARBON 56K 5% 1/4W
R1085 1-217-151-00 METAL 0.22 10% 2W
R1086 1-249-417-11 CARBON 1K 5% 1/4W F
R1087 1-249-431-11 CARBON 15K 5% 1/4W
R1088 1-249-441-11 CARBON 100K 5% 1/4W
R1089 1-260-076-11 CARBON 10 5% 1/2W
To Next Page
