Sony HCD-VX90AV - Page 77

– 107 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
C599 1-104-665-11 ELECT 100uF 20% 10V
C901 1-136-165-00 FILM 0.1uF 5% 50V
C902 1-126-939-11 ELECT 10000uF 20% 16V
C903 1-126-934-11 ELECT 220uF 20% 16V
C904 1-126-924-11 ELECT 330uF 20% 10V
C905 1-104-664-11 ELECT 47uF 20% 16V
C906 1-136-165-00 FILM 0.1uF 5% 50V
C907 1-128-548-11 ELECT 4700uF 20% 25V
C908 1-126-964-11 ELECT 10uF 20% 50V
C909 1-126-916-11 ELECT 1000uF 20% 6.3V
C912 1-126-964-11 ELECT 10uF 20% 50V
C913 1-104-665-11 ELECT 100uF 20% 10V
C914 1-126-964-11 ELECT 10uF 20% 50V
C915 1-126-933-11 ELECT 100uF 20% 16V
C916 1-126-964-11 ELECT 10uF 20% 50V
C917 1-126-767-11 ELECT 1000uF 20% 16V
C918 1-104-664-11 ELECT 47uF 20% 16V
C919 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C920 1-126-933-11 ELECT 100uF 20% 16V
C921 1-126-964-11 ELECT 10uF 20% 50V
C922 1-126-916-11 ELECT 1000uF 20% 6.3V
C923 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C924 1-104-656-11 ELECT 2200uF 20% 6.3V
C925 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C926 1-126-916-11 ELECT 1000uF 20% 6.3V
C931 1-126-961-11 ELECT 2.2uF 20% 50V
C951 1-136-165-00 FILM 0.1uF 5% 50V
C952 1-126-768-11 ELECT 2200uF 20% 16V
C953 1-126-934-11 ELECT 220uF 20% 16V
C954 1-126-924-11 ELECT 330uF 20% 10V
C956 1-136-165-00 FILM 0.1uF 5% 50V
< CONNECTOR >
CN101 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
CN111 1-784-601-11 SOCKET, CONNECTOR (NON ZIF) 13P
(E,EA,MY,SP,IA)
CN112 1-785-334-11 PIN, CONNECTOR (LIGHT ANGLE) 8P
CN113 1-785-335-11 PIN, CONNECTOR (LIGHT ANGLE) 9P
* CN121 1-568-832-11 SOCKET, CONNECTOR 13P (TH)
CN121 1-568-834-11 SOCKET, CONNECTOR 15P (E,EA,MY,SP,IA)
CN131 1-568-834-11 SOCKET, CONNECTOR 15P
* CN132 1-568-836-11 SOCKET, CONNECTOR 17P
* CN141 1-568-839-11 SOCKET, CONNECTOR 23P
CN151 1-770-726-11 CONNECTOR, BOARD TO BOARD 6P
CN152 1-778-982-11 CONNECTOR, BOARD TO BOARD 13P
* CN171 1-564-518-11 PLUG, CONNECTOR 3P
* CN301 1-568-449-11 HOUSING, CONNECTOR(PC BOARD)3P
< DIODE >
D141 8-719-988-61 DIODE 1SS355TE-17
D371 8-719-988-61 DIODE 1SS355TE-17
D372 8-719-988-61 DIODE 1SS355TE-17
D373 8-719-988-61 DIODE 1SS355TE-17
D374 8-719-988-61 DIODE 1SS355TE-17
D501 8-719-988-61 DIODE 1SS355TE-17
D502 8-719-988-61 DIODE 1SS355TE-17
D503 8-719-988-61 DIODE 1SS355TE-17
D504 8-719-988-61 DIODE 1SS355TE-17
D505 8-719-988-61 DIODE 1SS355TE-17
D506 8-719-988-61 DIODE 1SS355TE-17
D507 8-719-988-61 DIODE 1SS355TE-17
D508 8-719-988-61 DIODE 1SS355TE-17
D509 8-719-988-61 DIODE 1SS355TE-17
D510 8-719-988-61 DIODE 1SS355TE-17
D512 8-719-988-61 DIODE 1SS355TE-17
D901 8-719-073-81 DIODE EC21QS06-TE12L
D902 8-719-073-81 DIODE EC21QS06-TE12L
D903 8-719-073-81 DIODE EC21QS06-TE12L
D904 8-719-073-81 DIODE EC21QS06-TE12L
D905 8-719-988-61 DIODE 1SS355TE-17
D906 8-719-158-15 DIODE RD5.6S-B
D907 8-719-988-61 DIODE 1SS355TE-17
D908 8-719-200-82 DIODE 11ES2
D909 8-719-200-82 DIODE 11ES2
D910 8-719-200-82 DIODE 11ES2
D911 8-719-200-82 DIODE 11ES2
D912 8-719-056-88 DIODE UDZ-TE-17-11B
D913 8-719-200-82 DIODE 11ES2
D914 8-719-988-61 DIODE 1SS355TE-17
D915 8-719-210-33 DIODE EC10DS2
D916 8-719-210-33 DIODE EC10DS2
D918 8-719-210-33 DIODE EC10DS2
D931 8-719-988-61 DIODE 1SS355TE-17
D932 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC101 8-759-571-54 IC M62493FP
IC201 8-759-571-51 IC M62464FP
IC301 8-759-495-26 IC HA12215
IC421 8-749-923-04 IC TOTX178
IC501 8-759-588-91 IC M30622MA-A09FP
IC502 8-759-635-63 IC M51943BSL
IC901 8-759-231-53 IC TA7805S
IC902 8-759-604-86 IC M5F7807L
IC903 8-759-604-32 IC M5F7810
IC904 8-759-701-79 IC NJM7812FA
IC905 8-759-231-53 IC TA7805S
< JACK >
J101 1-774-411-11 JACK, PIN 6P (VIDEO (AUDIO)/MD IN, OUT)
J102 1-779-599-11 JACK, PIN 6P (DVD INPUT)
J191 1-774-785-11 JACK, PIN 1P (WOOFER OUT)
< COIL >
L411 1-408-619-31 INDUCTOR 220uH
L421 1-410-482-31 INDUCTOR 100uH
L501 1-410-470-11 INDUCTOR 10uH
< TRANSISTOR >
Q111 8-729-900-36 TRANSISTOR DTC124ES
Q112 8-729-119-78 TRANSISTOR 2SC403SP-51
Q113 8-729-119-78 TRANSISTOR 2SC403SP-51
Q114 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q161 8-729-900-36 TRANSISTOR DTC124ES
