– 114 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
SENSOR
S638 1-762-875-21 SWITCH, KEYBOARD (TIMER SELECT)
S639 1-762-875-21 SWITCH, KEYBOARD (P. FILE MEMORY)
S640 1-762-875-21 SWITCH, KEYBOARD (GEQ CONTROL)
S641 1-762-875-21 SWITCH, KEYBOARD (FILE SELECT)
S642 1-762-875-21 SWITCH, KEYBOARD (EFFECT)
S643 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S644 1-762-875-21 SWITCH, KEYBOARD (CD ^)
S645 1-762-875-21 SWITCH, KEYBOARD (p)
S646 1-762-875-21 SWITCH, KEYBOARD (TAPE B ()
S647 1-762-875-21 SWITCH, KEYBOARD (TAPE B 9)
S648 1-762-875-21 SWITCH, KEYBOARD (TAPE A ()
S649 1-762-875-21 SWITCH, KEYBOARD (TAPE A 9)
S650 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S651 1-762-875-21 SWITCH, KEYBOARD (CLOCK TIMER SET)
< VIBRATOR >
X601 1-781-312-11 VIBRATOR, CERAMIC (12.5MHz)
**************************************************************
* 1-658-576-11 SENSOR BOARD
************
< IC >
IC702 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
IC703 8-749-924-30 IC PHOTO REFLECTOR GP2S28
< RESISTOR >
R701 1-249-416-11 CARBON 820 5% 1/4W F
R702 1-249-407-11 CARBON 150 5% 1/4W F
**************************************************************
* 1-672-369-11 TRANS BOARD
************
< CAPACITOR >
C971 1-128-563-11 ELECT 100uF 20% 100V
C972 1-126-960-11 ELECT 1uF 20% 50V
C973 1-126-948-11 ELECT 100uF 20% 35V
< CONNECTOR >
CN951 1-564-321-00 PIN, CONNECTOR 2P
* CN952 1-564-527-11 PLUG, CONNECTOR 12P
CN971 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE)3P
< DIODE >
D971 8-719-200-82 DIODE 11ES2
D972 8-719-936-43 DIODE HZS27-3LTD
D973 8-719-109-63 DIODE RD3.0ESB2
< FUSE >
! F951 1-532-504-31 FUSE (T4AL/250V)(E,EA,MY,SP,IA)
! F951 1-532-505-31 FUSE (T5AL/250V)(TH)
! F952 1-532-388-31 FUSE (T2AL/250V)(E,EA,MY,SP,IA)
! F952 1-532-465-31 FUSE (T3.15AL/250V)(TH)
! F953 1-532-464-31 FUSE (T2.5AL/250V)
! F961 1-532-504-31 FUSE (T4AL/250V)(E,EA,MY,SP,IA)
! F961 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG)(T8AL/250V)
(TH)
! F962 1-532-504-31 FUSE (T4AL/250V)(E,EA,MY,SP,IA)
! F962 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG)(T8AL/250V)
(TH)
< FUSE HOLDER >
FH901 1-533-217-31 HOLDER, FUSE
FH902 1-533-217-31 HOLDER, FUSE
FH903 1-533-217-31 HOLDER, FUSE
FH911 1-533-217-31 HOLDER, FUSE
FH912 1-533-217-31 HOLDER, FUSE
FH951 1-533-217-31 HOLDER, FUSE
FH952 1-533-217-31 HOLDER, FUSE
FH953 1-533-217-31 HOLDER, FUSE
FH961 1-533-217-31 HOLDER, FUSE
FH962 1-533-217-31 HOLDER, FUSE
< TRANSISTOR >
Q971 8-729-048-52 TRANSISTOR 2SA1932(TP)
< RESISTOR >
! R951 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
(E,EA,MY,SP,IA)
! R951 1-219-122-91 FUSIBLE 0.33 5% 1/4W F
(TH)
! R952 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
(E,EA,MY,SP,IA)
! R952 1-219-122-91 FUSIBLE 0.33 5% 1/4W F
(TH)
! R953 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
R971 1-216-479-11 METAL OXIDE 560 5% 3W F
R972 1-249-429-11 CARBON 10K 5% 1/4W
R973 1-249-429-11 CARBON 10K 5% 1/4W
R974 1-247-807-31 CARBON 100 5% 1/4W
R975 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
! S951 1-771-291-11 SWITCH, POWER (VOLTAGE SELECTOR)
**************************************************************
A-4724-729-A VIDEO BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C102 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C103 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C104 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C201 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C202 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V
C203 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C301 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C302 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C303 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C304 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C305 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
PANEL
TRANS
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
VIDEO
To Next Page
