Sony HCD-XB8 - Page 43

— 79 —
• CD motor sectoin
IC201 TA8409S
1
2 3
4
5 6
7
8
9
HEAT
CUT OFF
BLOCK
STANDBY
BLOCK
VREF
BLOCK
IN2
VCC OUT2 NC GND
VS
OUT1 VREF IN1
• Power sectoin
IC301 uPC1237HA
1 2 3
4 5 6 7 8
OVER LOAD DET
F/F
OFFSET DET
LATCH/
AUTORESET
V
CC ON
MUTE
AC OFF
DET
V
CC
• Deck sectoin
IC402 LB1641
IC602 uPC1330HA
1
2
3
4
5
6
7 8 9
INVERTER
COMPARATER
SW R1 GND SW P1
CONT
GND
VCC
SW P2 GND
SW R2
1
2 3
4
5 6 7 8 9 10
GND
MOTOR
DRIVE
NOISE
FILTER
CLAMP
FWD.IN
REV.IN
VCC 1 VCC 2
NOISE
FILTER
MOTOR
DRIVE
MOTOR
DRIVE
MOTOR
DRIVE
T.S.D O.C.P
FWD/REV/STOP
CONTROL LOGIC
