Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< RELAY >
! RY101 1-755-195-11 RELAY (AEP,UK,EE,CIS)
RY401 1-755-142-11 RELAY
RY402 1-755-141-11 RELAY
< TERMINAL >
TM401 1-537-842-11 TERMINAL BOARD (FRONT SPEAKER)
TM402 1-537-510-11 TERMINAL BOARD (SPEAKER)(6P)
(SURROUND SPEAKER)
**************************************************************
* A-4392-662-A SURROUND BOARD, COMPLETE
*************************
(E,MX,AR,AUS,PX,SAF)
* A-4392-663-A SURROUND BOARD, COMPLETE (AEP,UK,EE,CIS)
*************************************
< CAPACITOR >
C601 1-126-963-11 ELECT 4.7uF 20% 50V
C602 1-162-292-31 CERAMIC 680PF 10% 50V
C603 1-162-286-21 CERAMIC 220PF 10% 50V
C604 1-126-967-11 ELECT 47uF 20% 50V
C605 1-126-967-11 ELECT 47uF 20% 50V
C606 1-126-968-11 ELECT 100uF 20% 50V
C608 1-126-965-11 ELECT 22uF 20% 50V
C610 1-130-493-00 MYLAR 0.068uF 5% 50V
C611 1-130-493-00 MYLAR 0.068uF 5% 50V
C613 1-161-494-00 CERAMIC 0.022uF 25V
(AEP,UK,EE,CIS)
C620 1-126-923-11 ELECT 220uF 20% 10V
C625 1-162-284-31 CERAMIC 150PF 10% 50V
C626 1-162-284-31 CERAMIC 150PF 10% 50V
(AEP,UK,EE,CIS)
C628 1-164-159-21 CERAMIC 0.1uF 50V
C651 1-126-963-11 ELECT 4.7uF 20% 50V
C652 1-162-292-31 CERAMIC 680PF 10% 50V
C653 1-162-286-21 CERAMIC 220PF 10% 50V
C654 1-126-967-11 ELECT 47uF 20% 50V
C655 1-126-967-11 ELECT 47uF 20% 50V
C656 1-126-968-11 ELECT 100uF 20% 50V
C660 1-130-493-00 MYLAR 0.068uF 5% 50V
C661 1-130-493-00 MYLAR 0.068uF 5% 50V
< CONNECTOR >
CN601 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
CN602 1-691-770-11 PLUG (MICRO CONNECTOR) 8P
CN603 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< DIODE >
D601 8-719-987-63 DIODE 1N4148M
D602 8-719-987-63 DIODE 1N4148M
D603 8-719-987-63 DIODE 1N4148M
D604 8-719-987-63 DIODE 1N4148M
D651 8-719-987-63 DIODE 1N4148M
< EARTH TERMINAL >
* EP601 1-537-738-21 TERMINAL, EARTH (AEP,UK,EE,CIS)
* EP602 1-537-738-21 TERMINAL, EARTH
< IC >
IC601 8-749-900-96 IC STK-4142MK2
< TRANSISTOR >
Q601 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q651 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q670 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q671 8-729-900-36 TRANSISTOR DTC124ES
< RESISTOR >
R601 1-249-417-11 CARBON 1K 5% 1/4W F
R602 1-249-437-11 CARBON 47K 5% 1/4W
R603 1-249-415-11 CARBON 680 5% 1/4W F
R604 1-249-437-11 CARBON 47K 5% 1/4W
R605 1-260-103-11 CARBON 2.2K 5% 1/2W
R606 1-260-103-11 CARBON 2.2K 5% 1/2W
! R609 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R610 1-217-151-00 METAL PLATE 0.22 10% 2W
R611 1-249-417-11 CARBON 1K 5% 1/4W F
R612 1-249-431-11 CARBON 15K 5% 1/4W
R613 1-249-441-11 CARBON 100K 5% 1/4W
R614 1-260-099-11 CARBON 1K 5% 1/2W
R616 1-260-099-11 CARBON 1K 5% 1/2W
R618 1-260-076-11 CARBON 10 5% 1/2W
R627 1-249-429-11 CARBON 10K 5% 1/4W
R628 1-247-881-00 CARBON 120K 5% 1/4W
R630 1-249-429-11 CARBON 10K 5% 1/4W
R642 1-249-429-11 CARBON 10K 5% 1/4W
! R644 1-217-637-00 FUSIBLE 1 5% 1/4W F
R651 1-249-417-11 CARBON 1K 5% 1/4W F
R652 1-249-437-11 CARBON 47K 5% 1/4W
R653 1-249-415-11 CARBON 680 5% 1/4W F
R654 1-249-437-11 CARBON 47K 5% 1/4W
R655 1-260-103-11 CARBON 2.2K 5% 1/2W
R656 1-260-103-11 CARBON 2.2K 5% 1/2W
! R659 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R660 1-217-151-00 METAL PLATE 0.22 10% 2W
R661 1-249-417-11 CARBON 1K 5% 1/4W F
R662 1-249-431-11 CARBON 15K 5% 1/4W
R663 1-249-441-11 CARBON 100K 5% 1/4W
R668 1-260-076-11 CARBON 10 5% 1/2W
R670 1-249-441-11 CARBON 100K 5% 1/4W
R671 1-249-441-11 CARBON 100K 5% 1/4W
R672 1-249-436-11 CARBON 39K 5% 1/4W (E)
R672 1-249-437-11 CARBON 47K 5% 1/4W
(AEP,UK,EE,CIS)
R672 1-249-441-11 CARBON 100K 5% 1/4W
(MX,AR,AUS,PX,SAF)
< THERMISTOR >
THP670 1-807-796-11 THERMISTOR
**************************************************************
POWER
SURROUND
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number speci-
fied.
