Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< COIL >
L401 1-420-872-00 COIL, AIR-CORE (AEP,UK,EE,CIS)
L402 1-420-872-00 COIL, AIR-CORE (AEP,UK,EE,CIS)
L403 1-420-872-00 COIL, AIR-CORE (AEP,UK,EE,CIS)
L404 1-420-872-00 COIL, AIR-CORE (AEP,UK,EE,CIS)
< TRANSISTOR >
Q111 8-729-900-80 TRANSISTOR DTC114ES (AEP,UK,EE,CIS)
Q112 8-729-900-80 TRANSISTOR DTC114ES (AEP,UK,EE,CIS)
Q113 8-729-040-20 TRANSISTOR RT1P137L-TP (AEP,UK,EE,CIS)
Q201 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q251 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q301 8-729-900-89 TRANSISTOR DTC144ES
Q323 8-729-900-63 TRANSISTOR DTA124ES
Q331 8-729-900-89 TRANSISTOR DTC144ES
Q401 8-729-900-80 TRANSISTOR DTC114ES
Q402 8-729-904-39 TRANSISTOR DTC114TS
Q403 8-729-040-20 TRANSISTOR RT1P137L-TP
Q404 8-729-040-20 TRANSISTOR RT1P137L-TP
Q405 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
! R101 1-219-122-91 FUSIBLE 0.33 5% 1/4W F
! R103 1-216-449-51 METAL OXIDE 56 5% 2W F
(AEP,UK,EE,CIS)
R111 1-249-429-11 CARBON 10K 5% 1/4W
(AEP,UK,EE,CIS)
R201 1-249-417-11 CARBON 1K 5% 1/4W F
R202 1-249-437-11 CARBON 47K 5% 1/4W
R203 1-249-413-11 CARBON 470 5% 1/4W F
R204 1-249-437-11 CARBON 47K 5% 1/4W
R206 1-260-107-11 CARBON 4.7K 5% 1/2W
R208 1-260-107-11 CARBON 4.7K 5% 1/2W
! R209 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R210 1-217-156-00 METAL PLATE 0.22 10% 5W
R211 1-249-417-11 CARBON 1K 5% 1/4W F
R212 1-249-431-11 CARBON 15K 5% 1/4W F
R213 1-249-441-11 CARBON 100K 5% 1/4W
R215 1-260-103-11 CARBON 2.2K 5% 1/2W
R216 1-260-103-11 CARBON 2.2K 5% 1/2W
R218 1-260-076-11 CARBON 10 5% 1/2W
R227 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R250 1-217-637-00 FUSIBLE 1 5% 1/4W F
R251 1-249-417-11 CARBON 1K 5% 1/4W F
R252 1-249-437-11 CARBON 47K 5% 1/4W
R253 1-249-413-11 CARBON 470 5% 1/4W F
R254 1-249-437-11 CARBON 47K 5% 1/4W
R256 1-260-107-11 CARBON 4.7K 5% 1/2W
R258 1-260-107-11 CARBON 4.7K 5% 1/2W
! R259 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R260 1-217-156-00 METAL PLATE 0.22 10% 5W
R261 1-249-417-11 CARBON 1K 5% 1/4W F
R262 1-249-431-11 CARBON 15K 5% 1/4W F
R263 1-249-441-11 CARBON 100K 5% 1/4W
R268 1-260-076-11 CARBON 10 5% 1/2W
R272 1-260-093-11 CARBON 330 5% 1/2W
R273 1-260-093-11 CARBON 330 5% 1/2W
R274 1-260-093-11 CARBON 330 5% 1/2W
R275 1-260-093-11 CARBON 330 5% 1/2W
R301 1-249-441-11 CARBON 100K 5% 1/4W
R302 1-247-854-11 CARBON 9.1K 5% 1/4W
R303 1-247-854-11 CARBON 9.1K 5% 1/4W
R304 1-249-429-11 CARBON 10K 5% 1/4W
R305 1-249-419-11 CARBON 1.5K 5% 1/4W F
R306 1-249-441-11 CARBON 100K 5% 1/4W
R307 1-247-863-91 CARBON 22K 5% 1/4W
R308 1-247-863-91 CARBON 22K 5% 1/4W
R309 1-247-791-91 CARBON 22 5% 1/4W
R310 1-249-437-11 CARBON 47K 5% 1/4W
R311 1-249-429-11 CARBON 10K 5% 1/4W
R312 1-249-429-11 CARBON 10K 5% 1/4W
R314 1-249-439-11 CARBON 68K 5% 1/4W
R315 1-249-439-11 CARBON 68K 5% 1/4W
R316 1-249-437-11 CARBON 47K 5% 1/4W
R317 1-249-437-11 CARBON 47K 5% 1/4W
R331 1-247-890-11 CARBON 300K 5% 1/4W
R332 1-249-429-11 CARBON 10K 5% 1/4W
R333 1-249-431-11 CARBON 15K 5% 1/4W
R334 1-249-417-11 CARBON 1K 5% 1/4W F
R401 1-249-429-11 CARBON 10K 5% 1/4W
! R405 1-215-886-11 METAL OXIDE 100 5% 2W F
(E,MX,AR,AUS,PX,SAF)
! R405 1-216-453-00 METAL OXIDE 270 5% 2W F
(AEP,UK,EE,CIS)
! R407 1-215-886-11 METAL OXIDE 100 5% 2W F
(E,MX,AR,AUS,PX,SAF)
! R407 1-216-453-00 METAL OXIDE 270 5% 2W F
(AEP,UK,EE,CIS)
R408 1-249-437-11 CARBON 47K 5% 1/4W
R409 1-249-440-11 CARBON 82K 5% 1/4W
R410 1-249-437-11 CARBON 47K 5% 1/4W
R411 1-249-437-11 CARBON 47K 5% 1/4W
R412 1-249-389-11 CARBON 4.7 5% 1/4W F
(AEP,UK,EE,CIS)
R413 1-249-389-11 CARBON 4.7 5% 1/4W F
(AEP,UK,EE,CIS)
R414 1-249-389-11 CARBON 4.7 5% 1/4W F
(AEP,UK,EE,CIS)
R415 1-249-389-11 CARBON 4.7 5% 1/4W F
(AEP,UK,EE,CIS)
R416 1-249-389-11 CARBON 4.7 5% 1/4W F
(AEP,UK,EE,CIS)
R417 1-249-389-11 CARBON 4.7 5% 1/4W F
(AEP,UK,EE,CIS)
R418 1-249-393-11 CARBON 10 5% 1/4W F
(AEP,UK,EE,CIS)
R419 1-249-389-11 CARBON 4.7 5% 1/4W F
(AEP,UK,EE,CIS)
R420 1-249-389-11 CARBON 4.7 5% 1/4W F
(AEP,UK,EE,CIS)
R421 1-249-393-11 CARBON 10 5% 1/4W F
(AEP,UK,EE,CIS)
R422 1-249-389-11 CARBON 4.7 5% 1/4W F
(AEP,UK,EE,CIS)
R423 1-249-389-11 CARBON 4.7 5% 1/4W F
(AEP,UK,EE,CIS)
POWER
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number speci-
fied.
