— 107 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R748 1-247-807-31 CARBON 100 5% 1/4W
R755 1-247-807-31 CARBON 100 5% 1/4W
R756 1-247-807-31 CARBON 100 5% 1/4W
R757 1-247-807-31 CARBON 100 5% 1/4W
R758 1-247-807-31 CARBON 100 5% 1/4W
R759 1-247-807-31 CARBON 100 5% 1/4W
R760 1-247-807-31 CARBON 100 5% 1/4W
R761 1-247-807-31 CARBON 100 5% 1/4W
R762 1-247-807-31 CARBON 100 5% 1/4W
R765 1-247-807-31 CARBON 100 5% 1/4W
R766 1-247-807-31 CARBON 100 5% 1/4W
R767 1-247-807-31 CARBON 100 5% 1/4W
R768 1-247-807-31 CARBON 100 5% 1/4W
R773 1-247-807-31 CARBON 100 5% 1/4W
R774 1-247-807-31 CARBON 100 5% 1/4W
R776 1-247-807-31 CARBON 100 5% 1/4W
R777 1-247-807-31 CARBON 100 5% 1/4W
R794 1-247-807-31 CARBON 100 5% 1/4W
R795 1-247-807-31 CARBON 100 5% 1/4W
R796 1-247-807-31 CARBON 100 5% 1/4W
R797 1-247-807-31 CARBON 100 5% 1/4W
R798 1-249-425-31 CARBON 4.7K 5% 1/4W F
R801 1-247-807-11 CARBON 100 5% 1/4W F
R802 1-249-435-11 CARBON 33K 5% 1/4W
R811 1-247-807-11 CARBON 100 5% 1/4W F
R812 1-249-435-11 CARBON 33K 5% 1/4W
R856 1-249-417-11 CARBON 1K 5% 1/4W F
R858 1-249-417-11 CARBON 1K 5% 1/4W F
R861 1-247-891-00 CARBON 330K 5% 1/4W
R862 1-249-441-11 CARBON 100K 5% 1/4W
R869 1-249-429-11 CARBON 10K 5% 1/4W
R870 1-247-843-11 CARBON 3.3K 5% 1/4W
R877 1-249-437-11 CARBON 47K 5% 1/4W
R901 1-247-895-91 CARBON 470K 5% 1/4W
R902 1-249-417-11 CARBON 1K 5% 1/4W F
R906 1-249-417-11 CARBON 1K 5% 1/4W F
R907 1-249-429-11 CARBON 10K 5% 1/4W
R910 1-215-883-11 CARBON 33 5% 2W F
(AEP,UK,EE,CIS)
R910 1-216-447-51 CARBON 27 5% 2W F
(E,MX,AR,AUS,PX,SAF)
R911 1-215-883-11 CARBON 33 5% 2W F
(AEP,UK,EE,CIS)
R911 1-216-447-51 CARBON 27 5% 2W F
(E,MX,AR,AUS,PX,SAF)
R912 1-249-417-11 CARBON 1K 5% 1/4W F
R942 1-247-863-91 CARBON 22K 5% 1/4W F
R943 1-249-425-11 CARBON 4.7K 5% 1/4W F
R944 1-247-815-91 CARBON 220 5% 1/4W
R945 1-247-815-91 CARBON 220 5% 1/4W
R946 1-260-092-11 CARBON 270 5% 1/2W
(AEP,UK,EE,CIS)
R946 1-260-093-11 CARBON 150 5% 1/2W
(E,MX,AR,AUS,PX,SAF)
R951 1-249-417-11 CARBON 1K 5% 1/4W F
R952 1-249-425-11 CARBON 4.7K 5% 1/4W F
R953 1-247-807-31 CARBON 100 5% 1/4W
R954 1-249-437-11 CARBON 47K 5% 1/4W
R955 1-249-437-11 CARBON 47K 5% 1/4W
PANELMAIN
R956 1-249-429-11 CARBON 10K 5% 1/4W
R961 1-249-421-11 CARBON 2.2K 5% 1/4W F
R962 1-249-432-11 CARBON 18K 5% 1/4W
R963 1-249-425-11 CARBON 4.7K 5% 1/4W F
< VARIABLE RESISTOR >
RV301 1-238-598-11 RES, ADJ, CARBON 2.2K
RV351 1-238-598-11 RES, ADJ, CARBON 2.2K
< VIBRATOR >
X601 1-579-125-11 VIBRATOR, CERAMIC (8MHz)
X701 1-579-233-11 VIBRATOR, CERAMIC (5MHz)
X702 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
**************************************************************
* A-4392-684-A PANEL BOARD, COMPLETE (AEP,UK,EE,CIS)
**********************************
* A-4392-685-A PANEL BOARD, COMPLETE
**********************
(E,MX,AR,AUS,PX,SAF)
* 4-986-870-11 HOLDER, FL TUBE
< CAPACITOR >
C601 1-126-967-11 ELECT 47uF 20% 50V
C602 1-162-306-11 CERAMIC 0.01uF 20% 16V
C603 1-126-963-11 ELECT 4.7uF 20% 50V
C604 1-126-960-11 ELECT 1uF 20% 50V
C606 1-126-960-11 ELECT 1uF 20% 50V
C608 1-124-584-00 ELECT 100uF 20% 10V
C610 1-162-306-11 CERAMIC 0.01uF 20% 16V
C611 1-162-306-11 CERAMIC 0.01uF 20% 16V
C612 1-126-967-11 ELECT 47uF 20% 50V
C613 1-164-159-21 CERAMIC 0.1uF 50V
C621 1-126-960-11 ELECT 1uF 20% 50V
C622 1-136-161-00 FILM 0.047uF 5% 50V
C623 1-126-957-11 ELECT 0.22uF 20% 50V
C624 1-126-957-11 ELECT 0.22uF 20% 50V
C625 1-162-306-11 CERAMIC 0.01uF 20% 16V
C626 1-126-957-11 ELECT 0.22uF 20% 50V
C627 1-136-159-00 FILM 0.033uF 5% 50V
C628 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C629 1-126-957-11 ELECT 0.22uF 20% 50V
C630 1-162-293-31 CERAMIC 820PF 10% 50V
C631 1-126-957-11 ELECT 0.22uF 20% 50V
C632 1-126-957-11 ELECT 0.22uF 20% 50V
C641 1-162-286-21 CERAMIC 220PF 10% 50V
C642 1-162-286-21 CERAMIC 220PF 10% 50V
C643 1-162-286-21 CERAMIC 220PF 10% 50V
C644 1-162-286-21 CERAMIC 220PF 10% 50V
C645 1-162-286-21 CERAMIC 220PF 10% 50V
C646 1-162-286-21 CERAMIC 220PF 10% 50V
C647 1-162-286-21 CERAMIC 220PF 10% 50V
C648 1-162-286-21 CERAMIC 220PF 10% 50V
C649 1-162-286-21 CERAMIC 220PF 10% 50V
C650 1-162-286-21 CERAMIC 220PF 10% 50V
C651 1-162-286-21 CERAMIC 220PF 10% 50V
