Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C652 1-162-286-21 CERAMIC 220PF 10% 50V
C653 1-162-286-21 CERAMIC 220PF 10% 50V
C654 1-162-286-21 CERAMIC 220PF 10% 50V
C655 1-162-286-21 CERAMIC 220PF 10% 50V
C656 1-162-286-21 CERAMIC 220PF 10% 50V
C690 1-164-159-21 CERAMIC 220PF 10% 50V
(AEP,UK,EE,CIS)
C692 1-164-159-21 CERAMIC 220PF 10% 50V
(AEP,UK,EE,CIS)
C693 1-164-159-21 CERAMIC 220PF 10% 50V
(AEP,UK,EE,CIS)
C695 1-164-159-21 CERAMIC 0.1uF 50V
C696 1-164-159-21 CERAMIC 0.1uF 50V
C697 1-162-294-31 CERAMIC 1000PF 10% 50V
C698 1-136-165-00 FILM 0.1uF 5% 50V
(AEP,UK,EE,CIS)
< CONNECTOR >
* CN601 1-568-836-11 SOCKET, CONNECTOR 17P
* CN602 1-568-947-11 PIN, CONNECTOR 9P
CN603 1-506-486-11 PIN, CONNECTOR 7P
* CN604 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D601 8-719-987-63 DIODE 1N4148M
D602 8-719-987-63 DIODE 1N4148M
D603 8-719-987-63 DIODE 1N4148M
D604 8-719-987-63 DIODE 1N4148M
D605 8-719-987-63 DIODE 1N4148M
D606 8-719-987-63 DIODE 1N4148M
D607 8-719-987-63 DIODE 1N4148M
D611 8-719-057-29 DIODE SML78423C-TP15 (TUNER/BAND)
D612 8-719-057-29 DIODE SML78423C-TP15 (TUNER/BAND)
D613 8-719-058-04 DIODE SEL5223S-TP15 (ENTER/NEXT)
D614 8-719-058-04 DIODE SEL5223S-TP15 (GROOVE)
D615 8-719-058-04 DIODE SEL5223S-TP15 (SUPER WOOFER)
D616 8-719-058-04 DIODE SEL5223S-TP15 (EFFECT)
D617 8-719-058-04 DIODE SEL5223S-TP15 (ENTER)
D618 8-719-058-04 DIODE SEL5223S-TP15 (FILE 1)
D619 8-719-058-04 DIODE SEL5223S-TP15 (FILE 2)
D620 8-719-058-04 DIODE SEL5223S-TP15 (FILE 3)
D621 8-719-058-04 DIODE SEL5223S-TP15 (FILE 4)
D622 8-719-058-04 DIODE SEL5223S-TP15 (FILE 5)
D623 8-719-058-04 DIODE SEL5223S-TP15 (P.FILE)
D624 8-719-058-04 DIODE SEL5223S-TP15 (MENU 2)
D625 8-719-058-04 DIODE SEL5223S-TP15 (MENU 1)
D626 8-719-058-04 DIODE SEL5223S-TP15 (DSP)
D627 8-719-058-04 DIODE SEL5223S-TP15 (PROLOGIC)
D629 8-719-058-04 DIODE SEL5223S-TP15 (PROLOGIC)
< FERRITE BEAD >
FB601 1-412-473-21 INDUCTOR 0UH
< FLUORESCENT INDICATOR >
FL601 1-517-617-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC601 8-759-466-89 IC TMP87CH75-6554
IC602 8-759-459-84 IC NJL56H400
< COIL >
L601 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q601 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q602 8-729-118-00 TRANSISTOR 2SB1116-L
Q603 8-729-118-00 TRANSISTOR 2SB1116-L
Q604 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q605 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q606 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q607 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q608 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q609 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q610 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q611 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q612 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q614 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q615 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q616 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q617 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q618 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q619 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q621 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q622 8-729-119-77 TRANSISTOR 2SA1175-FEK
< RESISTOR >
R601 1-247-843-11 CARBON 3.3K 5% 1/4W
R602 1-249-429-11 CARBON 10K 5% 1/4W
R603 1-247-903-00 CARBON 1M 5% 1/4W
R606 1-249-429-11 CARBON 10K 5% 1/4W
R607 1-249-429-11 CARBON 10K 5% 1/4W
R608 1-249-429-11 CARBON 10K 5% 1/4W
R609 1-249-429-11 CARBON 10K 5% 1/4W
R610 1-249-429-11 CARBON 10K 5% 1/4W
R611 1-247-843-11 CARBON 3.3K 5% 1/4W
R612 1-247-843-11 CARBON 3.3K 5% 1/4W
R613 1-249-401-11 CARBON 47 5% 1/4W F
R614 1-249-429-11 CARBON 10K 5% 1/4W
R615 1-249-429-11 CARBON 10K 5% 1/4W
R617 1-249-429-11 CARBON 10K 5% 1/4W
R621 1-249-421-11 CARBON 2.2K 5% 1/4W F
R622 1-249-437-11 CARBON 47K 5% 1/4W
R623 1-247-895-91 CARBON 470K 5% 1/4W
R624 1-249-421-11 CARBON 2.2K 5% 1/4W F
R625 1-249-437-11 CARBON 47K 5% 1/4W
R626 1-247-895-91 CARBON 470K 5% 1/4W
R627 1-249-421-11 CARBON 2.2K 5% 1/4W F
R628 1-249-437-11 CARBON 47K 5% 1/4W
R629 1-247-895-91 CARBON 470K 5% 1/4W
R631 1-249-437-11 CARBON 47K 5% 1/4W
R632 1-247-895-91 CARBON 470K 5% 1/4W
R633 1-247-897-11 CARBON 560K 5% 1/4W
R634 1-247-897-11 CARBON 560K 5% 1/4W
R635 1-247-897-11 CARBON 560K 5% 1/4W
R636 1-247-897-11 CARBON 560K 5% 1/4W
R637 1-247-895-91 CARBON 470K 5% 1/4W
R638 1-249-435-11 CARBON 33K 5% 1/4W
PANEL
