— 109 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R641 1-249-419-11 CARBON 1.5K 5% 1/4W F
R642 1-249-401-11 CARBON 47 5% 1/4W F
R643 1-249-403-11 CARBON 68 5% 1/4W F
R644 1-247-807-31 CARBON 100 5% 1/4W
R645 1-249-407-11 CARBON 150 5% 1/4W F
R646 1-249-407-11 CARBON 150 5% 1/4W F
R647 1-247-815-91 CARBON 220 5% 1/4W
R648 1-249-411-11 CARBON 330 5% 1/4W
R649 1-249-413-11 CARBON 470 5% 1/4W F
R650 1-249-415-11 CARBON 680 5% 1/4W F
R651 1-249-417-11 CARBON 1K 5% 1/4W F
R652 1-249-419-11 CARBON 1.5K 5% 1/4W F
R653 1-249-421-11 CARBON 2.2K 5% 1/4W F
R654 1-247-843-11 CARBON 3.3K 5% 1/4W
R655 1-249-427-11 CARBON 6.8K 5% 1/4W F
R656 1-249-431-11 CARBON 15K 5% 1/4W
R657 1-249-419-11 CARBON 1.5K 5% 1/4W F
R658 1-249-401-11 CARBON 47 5% 1/4W F
R659 1-249-403-11 CARBON 68 5% 1/4W F
R660 1-247-807-31 CARBON 100 5% 1/4W
R661 1-249-407-11 CARBON 150 5% 1/4W F
R662 1-249-407-11 CARBON 150 5% 1/4W F
R663 1-249-419-11 CARBON 1.5K 5% 1/4W F
R664 1-249-401-11 CARBON 47 5% 1/4W F
R665 1-249-403-11 CARBON 68 5% 1/4W F
R666 1-247-807-31 CARBON 100 5% 1/4W
R667 1-249-407-11 CARBON 150 5% 1/4W F
R668 1-249-407-11 CARBON 150 5% 1/4W F
R669 1-249-419-11 CARBON 1.5K 5% 1/4W F
R670 1-249-401-11 CARBON 47 5% 1/4W F
R671 1-249-403-11 CARBON 68 5% 1/4W F
R672 1-247-807-31 CARBON 100 5% 1/4W
R673 1-249-407-11 CARBON 150 5% 1/4W F
R674 1-249-407-11 CARBON 150 5% 1/4W F
R675 1-247-815-91 CARBON 220 5% 1/4W
R676 1-249-411-11 CARBON 330 5% 1/4W
R677 1-249-413-11 CARBON 470 5% 1/4W F
R678 1-249-415-11 CARBON 680 5% 1/4W F
R679 1-249-419-11 CARBON 1.5K 5% 1/4W F
R681 1-249-429-11 CARBON 10K 5% 1/4W
R682 1-249-421-11 CARBON 2.2K 5% 1/4W F
R683 1-247-887-00 CARBON 220K 5% 1/4W
R684 1-249-429-11 CARBON 10K 5% 1/4W
R685 1-249-421-11 CARBON 2.2K 5% 1/4W F
R686 1-247-807-31 CARBON 100 5% 1/4W
R687 1-247-807-31 CARBON 100 5% 1/4W
R688 1-247-807-31 CARBON 100 5% 1/4W
R689 1-247-807-31 CARBON 100 5% 1/4W
R690 1-247-807-31 CARBON 100 5% 1/4W
R691 1-247-807-31 CARBON 100 5% 1/4W
R692 1-247-807-31 CARBON 100 5% 1/4W
R693 1-247-807-31 CARBON 100 5% 1/4W
R694 1-247-807-31 CARBON 100 5% 1/4W
R695 1-247-807-31 CARBON 100 5% 1/4W
R696 1-247-807-31 CARBON 100 5% 1/4W
R697 1-247-807-31 CARBON 100 5% 1/4W
R698 1-247-807-31 CARBON 100 5% 1/4W
R699 1-247-807-31 CARBON 100 5% 1/4W
R700 1-247-807-31 CARBON 100 5% 1/4W
R701 1-247-807-31 CARBON 100 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R704 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S601 1-554-303-21 SWITCH, TACTILE (ENTER/NEXT)
S602 1-554-303-21 SWITCH, TACTILE (TUNER MEMORY)
S603 1-554-303-21 SWITCH, TACTILE (TUNING MODE)
S604 1-554-303-21 SWITCH, TACTILE (TUNER/BAND)
S605 1-554-303-21 SWITCH, TACTILE (TUNING +)
S606 1-554-303-21 SWITCH, TACTILE (TUNING -)
S607 1-554-303-21 SWITCH, TACTILE (STEREO/MONO)
S608 1-554-303-21 SWITCH, TACTILE (PTY)(AEP,UK)
S609 1-554-303-21 SWITCH, TACTILE (FUNCTION)
S610 1-554-303-21 SWITCH, TACTILE (GROOVE)
S611 1-554-303-21 SWITCH, TACTILE (GEQ 4)
S612 1-554-303-21 SWITCH, TACTILE (GEQ “)
S613 1-554-303-21 SWITCH, TACTILE (GEQ ”)
S614 1-554-303-21 SWITCH, TACTILE (GEQ $)
S615 1-554-303-21 SWITCH, TACTILE (SUPER WOOFER)
S616 1-554-303-21 SWITCH, TACTILE (SUPER W MODE)
S619 1-554-303-21 SWITCH, TACTILE (GEQ CONTROL)
S620 1-554-303-21 SWITCH, TACTILE (ENTER)
S621 1-554-303-21 SWITCH, TACTILE (EFFECT)
S622 1-554-303-21 SWITCH, TACTILE (WAVE)
S623 1-554-303-21 SWITCH, TACTILE (KARAOKE PON/MPX)
S624 1-554-303-21 SWITCH, TACTILE (DSP)
S625 1-554-303-21 SWITCH, TACTILE (PROLOGIC)
S626 1-554-303-21 SWITCH, TACTILE (P FILE, MEMORY)
S627 1-554-303-21 SWITCH, TACTILE (SPECTRUM ANALYZER)
S628 1-554-303-21 SWITCH, TACTILE (DISPLAY/DEMO)
S629 1-554-303-21 SWITCH, TACTILE (POWER)
S630 1-554-303-21 SWITCH, TACTILE (t/TIMER SET)
S631 1-554-303-21 SWITCH, TACTILE (REC)
S632 1-554-303-21 SWITCH, TACTILE (DAILY 1)
S633 1-554-303-21 SWITCH, TACTILE (DAILY 2)
S634 1-554-303-21 SWITCH, TACTILE (SLEEP)
S701 1-467-869-11 ENCODER, ROTARY (VOLUME)
< VIBRATOR >
X601 1-579-125-11 VIBRATOR, CERAMIC (8MHz)
**************************************************************
* A-4392-678-A POWER BOARD, COMPLETE (AEP,UK,EE,CIS)
**********************************
* A-4392-679-A POWER BOARD, COMPLETE
**********************
(E,MX,AR,AUS,PX,SAF)
< CAPACITOR >
C101 1-130-781-00 FILM 0.22uF 10% 100V
C102 1-130-781-00 FILM 0.22uF 10% 100V
C103 1-136-169-00 FILM 0.22uF 5% 50V
C104 1-136-169-00 FILM 0.22uF 5% 50V
C105 1-162-294-31 CERAMIC 0.001uF 10% 50V
PANEL
POWER
