8-4
S MIC Chassis
Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
C1298 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
C1299 1-163-093-00 CERAMIC CHIP 10PF 5% 50V
C1300 1-126-160-11 ELECT 1µF 20% 50V
C1301 1-126-160-11 ELECT 1µF 20% 50V
C1302 1-126-160-11 ELECT 1µF 20% 50V
C1303 1-126-160-11 ELECT 1µF 20% 50V
C1400 1-163-141-00 CERAMIC CHIP 0.001µF 5% 50V
C1401 1-163-141-00 CERAMIC CHIP 0.001µF 5% 50V
C1402 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C1403 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1404 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
<FILTER>
CFM101 1-464-880-11 FILTER BLOCK, COM (CFB-2)
<CONNECTOR>
CN101 1-506-480-11 PIN, CONNECTOR 15P
CN102 * 1-564-506-11 PLUG, CONNECTOR 3P
CN103 * 1-565-503-11 CONNECTOR, BOARD TO BOARD 12P
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
CN104 * 1-564-011-11 PIN, CONNECTOR 12P
CN105 * 1-564-509-11 PLUG, CONNECTOR 6P
CN106 1-506-473-11 PIN, CONNECTOR 8P
CN107 1-506-478-11 PIN, CONNECTOR 13P
CN108 * 1-564-506-11 PLUG, CONNECTOR 3P
<TRAP MODULE>
CTR101 1-236-366-11 MODULE, TRAP
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
CTR101 1-236-369-11 MODULE, TRAP (PVM-9045PM)
CTR102 1-236-365-11 MODULE, TRAP
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
<DIODE>
D102 8-719-404-49 DIODE MA111 (PVM-9045PM)
D103 8-719-404-49 DIODE MA111
D104 8-719-404-49 DIODE MA111
D105 8-719-404-49 DIODE MA111
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
D106 8-719-404-49 DIODE MA111
D107 8-719-404-49 DIODE MA111
D108 8-719-404-49 DIODE MA111
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
D109 8-719-404-49 DIODE MA111
D110 8-719-404-49 DIODE MA111
D111 8-719-404-49 DIODE MA111
D112 8-719-404-49 DIODE MA111
D113 8-719-404-49 DIODE MA111
D116 8-719-404-49 DIODE MA111
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
D117 8-719-404-49 DIODE MA111
D120 8-719-404-49 DIODE MA111
D121 8-719-404-49 DIODE MA111
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
D122 8-719-404-49 DIODE MA111
D123 8-719-404-49 DIODE MA111
D125 8-719-404-49 DIODE MA111
D126 8-719-404-49 DIODE MA111
D127 8-719-404-49 DIODE MA111
D128 8-719-801-78 DIODE 1SS184
D129 8-719-404-49 DIODE MA111
D130 8-719-800-76 DIODE 1SS226
D131 8-719-800-76 DIODE 1SS226
D132 8-719-800-76 DIODE 1SS226
D133 8-719-404-49 DIODE MA111
D134 8-719-404-49 DIODE MA111
D135 8-719-404-49 DIODE MA111
D136 8-719-404-49 DIODE MA111
D137 8-719-404-49 DIODE MA111
D138 8-719-404-49 DIODE MA111
D139 8-719-404-49 DIODE MA111
D144 8-719-404-49 DIODE MA111
D145 8-719-404-49 DIODE MA111
D146 8-719-404-49 DIODE MA111
D147 8-719-404-49 DIODE MA111
D148 8-719-404-49 DIODE MA111
D149 8-719-404-49 DIODE MA111
D150 8-719-404-49 DIODE MA111
D151 8-719-404-49 DIODE MA111
D152 8-719-404-49 DIODE MA111
D153 8-719-977-20 DIODE DTZ8.2B
D154 8-719-404-49 DIODE MA111
D155 8-719-404-49 DIODE MA111
D156 8-719-404-49 DIODE MA111
D157 8-719-901-83 DIODE 1SS83
D158 8-719-901-83 DIODE 1SS83
D159 8-719-901-83 DIODE 1SS83
D160 8-719-404-49 DIODE MA111
D161 8-719-404-49 DIODE MA111
D162 8-719-404-49 DIODE MA111
D170 8-719-404-49 DIODE MA111
D185 8-719-104-34 DIODE 1S2836
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
D186 8-719-801-78 DIODE 1SS184
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
D187 8-719-800-76 DIODE 1SS226
D188 8-719-800-76 DIODE 1SS226
D191 8-719-104-34 DIODE 1S2836
D285 8-719-404-49 DIODE MA111
D289 8-719-404-49 DIODE MA111
D341 8-719-404-49 DIODE MA111
D342 8-719-104-34 DIODE 1S2836
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
D343 8-719-800-76 DIODE 1SS226
D344 8-719-105-99 DIODE RD6.2M-B1
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
D345 8-719-901-83 DIODE 1SS83
D346 8-719-901-83 DIODE 1SS83
D347 8-719-901-83 DIODE 1SS83
D348 8-719-800-76 DIODE 1SS226
D349 8-719-800-76 DIODE 1SS226
D350 8-719-800-76 DIODE 1SS226
D390 8-719-800-76 DIODE 1SS226
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
D393 8-719-404-49 DIODE MA111
[B]
