8-5
S MIC Chassis
Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
D1400 8-719-045-70 DIODE 1SV230TPH3
D1401 8-719-404-49 DIODE MA111
<DELAY LINE>
DL101 1-415-632-11 DELAY LINE, Y
DL102 1-415-633-11 DELAY LINE, Y
<IC>
IC101 8-759-432-78 IC MM1111XFBE
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
IC102 8-759-446-66 IC MM1113XFBE
IC103 8-759-446-66 IC MM1113XFBE
IC104 8-759-446-66 IC MM1113XFBE
IC105 8-759-432-78 IC MM1111XFBE
IC106 8-759-009-51 IC MC14538BF
IC107 8-759-473-08 IC BU4584BF-E2
IC108 8-759-932-67 IC BU4053BCF
IC109 8-759-473-07 IC BU4070BF-E2
IC110 8-759-932-67 IC BU4053BCF
IC111 8-759-932-67 IC BU4053BCF
IC112 8-759-231-53 IC TA7805S
IC113 8-759-631-08 IC M51279FP
IC114 8-759-208-09 IC TC4052BFHB
IC115 8-759-208-09 IC TC4052BFHB
IC116 8-759-008-67 IC MC14066BF
IC117 8-759-358-46 IC MM1114XFBE
IC118 8-759-358-46 IC MM1114XFBE
IC119 8-759-358-46 IC MM1114XFBE
IC120 8-759-008-67 IC MC14066BF
IC121 8-759-932-67 IC BU4053BCF
IC122 8-759-998-98 IC LM358D
IC123 8-759-998-98 IC LM358D
IC124 8-752-052-62 IC CXA1478S
IC125 8-759-008-67 IC MC14066BF
IC126 8-759-932-67 IC BU4053BCF
IC127 8-759-998-98 IC LM358D
IC128 8-759-998-98 IC LM358D
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
IC129 8-759-998-98 IC LM358D
IC1400 8-759-242-64 IC TC4W53F
IC1401 8-759-209-97 IC TC4S81F
<CHIP CONDUCTOR>
JR105 1-216-295-91 SHORT 0
JR110 1-216-295-91 SHORT 0
JR113 1-216-295-91 SHORT 0 (PVM-9045PM)
JR133 1-216-295-91 SHORT 0
JR138 1-216-295-91 SHORT 0
JR178 1-216-295-91 SHORT 0
<COIL>
L101 1-410-470-11 INDUCTOR 10µH
L102 1-410-090-41 INDUCTOR 18mH
L103 1-412-002-31 INDUCTOR CHIP 4.7µH
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
L104 1-412-002-31 INDUCTOR CHIP 4.7µH
L105 1-412-002-31 INDUCTOR CHIP 4.7µH
L106 1-410-470-11 INDUCTOR 10µH
L107 1-410-470-11 INDUCTOR 10µH
L112 1-408-613-31 INDUCTOR 68µH
L113 1-410-947-31 INDUCTOR CHIP 33µH
L114 1-410-947-31 INDUCTOR CHIP 3µH
L115 1-410-947-31 INDUCTOR CHIP 33µH
L116 1-412-011-31 INDUCTOR CHIP 27µH
L117 1-412-011-31 INDUCTOR CHIP 27µH
L118 1-412-011-31 INDUCTOR CHIP 27µH
L252 1-410-478-11 INDUCTOR 47µH
L300 1-410-482-31 INDUCTOR 100µH
L1400 1-410-196-11 INDUCTOR CHIP 2.2µH
<TRANSISTOR>
Q101 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q102 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q103 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q104 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q105 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q106 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q107 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q108 8-729-216-22 TRANSISTOR 2SA1162-G
Q109 1-801-806-11 TRANSISTOR DTC144EK-T147
Q112 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q113 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q114 8-729-216-22 TRANSISTOR 2SA1162-G
Q115 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q116 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q117 8-729-216-22 TRANSISTOR 2SA1162-G
Q118 8-729-120-28 TRANSISTOR 2SC1623-L5L6
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
Q119 8-729-216-22 TRANSISTOR 2SA1162-G
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
Q120 8-729-216-22 TRANSISTOR 2SA1162-G
Q121 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q122 8-729-216-22 TRANSISTOR 2SA1162-G
Q123 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q124 8-729-216-22 TRANSISTOR 2SA1162-G
Q125 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q126 1-801-806-11 TRANSISTOR DTC144EK-T147
Q127 8-729-216-22 TRANSISTOR 2SA1162-G
Q128 8-729-216-22 TRANSISTOR 2SA1162-G
Q129 1-801-806-11 TRANSISTOR DTC144EK-T147
Q130 8-729-216-22 TRANSISTOR 2SA1162-G
Q132 8-729-216-22 TRANSISTOR 2SA1162-G
Q134 1-801-806-11 TRANSISTOR DTC144EK-T147
Q136 8-729-907-26 TRANSISTOR IMX1
Q137 8-729-907-26 TRANSISTOR IMX1
Q138 8-729-907-26 TRANSISTOR IMX1
Q139 8-729-216-22 TRANSISTOR 2SA1162-G
Q140 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q141 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q142 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q143 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q144 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q145 8-729-120-28 TRANSISTOR 2SC1623-L5L6
