8-6
S MIC Chassis
Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
Q146 8-729-255-12 TRANSISTOR 2SC2551-O
Q147 8-729-255-12 TRANSISTOR 2SC2551-O
Q148 8-729-216-22 TRANSISTOR 2SA1162-G
Q149 8-729-200-17 TRANSISTOR 2SA1091-O
Q150 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q151 8-729-216-22 TRANSISTOR 2SA1162-G
Q152 8-729-200-17 TRANSISTOR 2SA1091-O
Q153 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q154 8-729-216-22 TRANSISTOR 2SA1162-G
Q155 8-729-200-17 TRANSISTOR 2SA1091-O
Q157 8-729-326-11 TRANSISTOR 2SC2611
Q158 8-729-326-11 TRANSISTOR 2SC2611
Q159 8-729-326-11 TRANSISTOR 2SC2611
Q160 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q161 8-729-216-22 TRANSISTOR 2SA1162-G
Q164 1-801-806-11 TRANSISTOR DTC144EK-T147
Q165 8-729-216-22 TRANSISTOR 2SA1162-G
Q166 8-729-216-22 TRANSISTOR 2SA1162-G
Q167 8-729-216-22 TRANSISTOR 2SA1162-G
Q168 8-729-216-22 TRANSISTOR 2SA1162-G
Q170 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q171 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q172 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q173 8-729-216-22 TRANSISTOR 2SA1162-G
Q174 8-729-216-22 TRANSISTOR 2SA1162-G
Q175 8-729-216-22 TRANSISTOR 2SA1162-G
Q176 8-729-216-22 TRANSISTOR 2SA1162-G
Q177 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q178 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q179 1-801-806-11 TRANSISTOR DTC144EK-T147
Q189 8-729-907-26 TRANSISTOR IMX1
Q190 8-729-216-22 TRANSISTOR 2SA1162-G
Q191 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q192 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q193 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q194 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q195 8-729-216-22 TRANSISTOR 2SA1162-G
Q196 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q197 8-729-216-22 TRANSISTOR 2SA1162-G
Q198 8-729-216-22 TRANSISTOR 2SA1162-G
Q199 8-729-216-22 TRANSISTOR 2SA1162-G
Q200 8-729-901-06 TRANSISTOR DTA144EK
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
Q201 8-729-216-22 TRANSISTOR 2SA1162-G
Q202 8-729-216-22 TRANSISTOR 2SA1162-G
Q203 8-729-216-22 TRANSISTOR 2SA1162-G
Q204 8-729-216-22 TRANSISTOR 2SA1162-G
Q205 8-729-216-22 TRANSISTOR 2SA1162-G
Q206 8-729-216-22 TRANSISTOR 2SA1162-G
Q208 8-729-216-22 TRANSISTOR 2SA1162-G
Q209 8-729-255-12 TRANSISTOR 2SC2551-O
Q210 8-729-255-12 TRANSISTOR 2SC2551-O
Q211 8-729-255-12 TRANSISTOR 2SC2551-O
Q212 8-729-141-53 TRANSISTOR 2SK94-X2X3X4
Q299 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1400 8-729-141-53 TRANSISTOR 2SK94-X2X3X4
Q1401 8-729-141-53 TRANSISTOR 2SK94-X2X3X4
<RESISTOR>
R101 1-216-089-91 RES,CHIP 47K 5% 1/10W
R102 1-216-025-91 RES,CHIP 100 5% 1/10W
R103 1-216-091-00 RES,CHIP 56K 5% 1/10W
R104 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R105 1-216-025-91 RES,CHIP 100 5% 1/10W
R106 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R107 1-216-025-91 RES,CHIP 100 5% 1/10W
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
R108 1-216-113-00 RES,CHIP 470K 5% 1/10W
R109 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R110 1-216-049-91 RES,CHIP 1K 5% 1/10W
R111 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R112 1-216-049-91 RES,CHIP 1K 5% 1/10W
R113 1-249-401-11 CARBON 47 5% 1/4W F
R114 1-216-045-00 RES,CHIP 680 5% 1/10W
R115 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R117 1-216-073-00 RES,CHIP 10K 5% 1/10W
R118 1-216-025-91 RES,CHIP 100 5% 1/10W
R119 1-216-647-11 METAL CHIP 680 0.50% 1/10W
R120 1-216-647-11 METAL CHIP 680 0.50% 1/10W
R121 1-216-025-91 RES,CHIP 100 5% 1/10W
R122 1-216-083-00 RES,CHIP 27K 5% 1/10W
R123 1-216-073-00 RES,CHIP 10K 5% 1/10W
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
R124 1-216-073-00 RES,CHIP 10K 5% 1/10W
R125 1-216-083-00 RES,CHIP 27K 5% 1/10W
R126 1-216-093-00 RES,CHIP 68K 5% 1/10W
R127 1-216-037-00 RES,CHIP 330 5% 1/10W
R128 1-216-083-00 RES,CHIP 27K 5% 1/10W
R129 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R130 1-216-097-91 RES,CHIP 100K 5% 1/10W
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
R131 1-216-089-91 RES,CHIP 47K 5% 1/10W
R132 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R133 1-216-079-00 RES,CHIP 18K 5% 1/10W
R134 1-216-645-11 METAL CHIP 560 0.50% 1/10W
R135 1-216-645-11 METAL CHIP 560 0.50% 1/10W
R136 1-216-091-00 RES,CHIP 56K 5% 1/10W
R137 1-216-045-00 RES,CHIP 680 5% 1/10W
R138 1-216-657-11 METAL CHIP 1.8K 0.50% 1/10W
R139 1-216-079-00 RES,CHIP 18K 5% 1/10W
R140 1-216-653-11 METAL CHIP 1.2K 0.50% 1/10W
R141 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R142 1-216-073-00 RES,CHIP 10K 5% 1/10W
R143 1-216-085-00 RES,CHIP 33K 5% 1/10W
R145 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R146 1-216-037-00 RES,CHIP 330 5% 1/10W
R147 1-216-089-91 RES,CHIP 47K 5% 1/10W
R148 1-216-671-11 METAL CHIP 6.8K 0.50% 1/10W
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
R155 1-216-655-11 METAL CHIP 1.5K 0.50% 1/10W
R157 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R158 1-216-677-11 METAL CHIP 12K 0.50% 1/10W
R160 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R161 1-216-089-91 RES,CHIP 47K 5% 1/10W
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
R163 1-216-073-00 RES,CHIP 10K 5% 1/10W
R164 1-216-677-11 METAL CHIP 12K 0.50% 1/10W
