8-11
S MIC Chassis
Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
RV205 1-241-765-11 RES, ADJ, CARBON 22K
RV1400 1-237-036-11 RES, ADJ, CERMET 10K
RV1401 1-237-036-11 RES, ADJ, CERMET 10K
<MODULE>
SEP101 1-808-654-11 MODULE
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
SEP101 1-809-347-11 MODULE (PVM-9045PM)
<CRYSTAL>
X1400 1-527-722-00 VIBRATOR, CRYSTAL
X1401 1-527-523-00 OSCILLATOR CRYSTAL (PVM-9045PM)
X1401 1-577-259-11 VIBRATOR, CRYSTAL
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
***************************************************************
* A-1190-333-A MOUNTED PWB, PA
*******************
<CAPACITOR>
C815 1-126-964-11 ELECT 10µF 20% 50V
C816 1-117-228-11 FILM 2.2µF 10% 450V
C817 1-117-228-11 FILM 2.2µF 10% 450V
<CONNECTOR>
CN806 1-695-915-11 TAB (CONTACT)
CN807 * 1-564-506-11 PLUG, CONNECTOR 3P
CN808 * 1-564-506-11 PLUG, CONNECTOR 3P
CN809 * 1-560-123-00 PLUG, CONNECTOR (2.5MM) 3P
<DIODE>
D815 8-719-911-19 DIODE 1SS119-25
<TRANSISTOR>
Q815 8-729-906-24 TRANSISTOR 2SD835
Q816 8-729-140-96 TRANSISTOR 2SD774-34
<RESISTOR>
R815 1-215-929-11 METAL OXIDE 100K 5% 3W F
R816 1-249-429-11 CARBON 10K 5% 1/4W
R817 1-247-843-11 CARBON 3.3K 5% 1/4W
R818 1-202-846-00 SOLID 470K 10% 1/2W
<RELAY>
RY815 1-515-738-11 RELAY
***************************************************************
* A-1195-146-A P BOARD, COMPETE
********************
* 4-043-154-01 HOLDER, IC
4-382-854-01 SCREW (M3X8), P, SW (+)
4-879-937-00 SHEET, MICA
<CAPACITOR>
C801 1-126-971-11 ELECT 470µF 20% 35V
C802 1-102-228-00 CERAMIC 470PF 10% 500V
C803 1-102-228-00 CERAMIC 470PF 10% 500V
C804 1-107-638-11 ELECT 33µF 20% 160V
C806 1-124-480-11 ELECT 470µF 20% 25V
C807 1-102-228-00 CERAMIC 470PF 10% 500V
C808 1-137-150-11 MYLAR 0.01µF 10% 100V
C809 1-106-375-12 MYLAR 0.022µF 10% 100V
C810 1-162-318-11 CERAMIC 0.001µF 10% 500V
C811 ! 1-137-544-11 FILM 0.01µF 3% 600V
C812 ! 1-137-545-11 FILM 0.013µF 3% 600V
C813 1-107-385-11 MYLAR 0.056µF 5% 200V
C814 1-137-353-11 MYLAR 0.047µF 10% 100V
C815 1-124-910-11 ELECT 47µF 20% 50V
C816 1-107-675-11 ELECT 1µF 20% 160V
C818 1-102-228-00 CERAMIC 470PF 10% 500V
C819 1-162-116-00 CERAMIC 680PF 10% 2KV
C820 1-162-116-00 CERAMIC 680PF 10% 2KV
C821 1-162-116-00 CERAMIC 680PF 10% 2KV
C825 1-123-024-21 ELECT 33µF 160V
C880 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C883 1-129-720-00 FILM 0.033µF 5% 630V
<CONNECTOR>
CN801 * 1-564-595-11 PLUG, CONNECTOR 14P
CN802 * 1-508-766-00 PIN, CONNECTOR (5MM PITCH) 4P
CN803 * 1-564-508-11 PLUG, CONNECTOR 5P
CN810 1-695-915-11 TAB (CONTACT)
CN811 * 1-564-506-11 PLUG, CONNECTOR 3P
<DIODE>
D801 8-719-302-43 DIODE EL1Z
D802 8-719-302-43 DIODE EL1Z
D803 8-719-302-43 DIODE EL1Z
D804 8-719-979-85 DIODE EGP20G
D805 8-719-302-43 DIODE EL1Z
D806 8-719-302-43 DIODE EL1Z
D808 8-719-018-72 THYRISTOR CR02AM-4TB
D809 8-719-908-03 DIODE GP08D
D810 8-719-908-03 DIODE GP08D
D811 8-719-908-03 DIODE GP08D
D813 8-719-302-43 DIODE EL1Z
D814 8-719-901-19 DIODE V11N
<COIL>
L802 1-459-442-00 INDUCTOR 15µH
[B][PA][P]
To Next Page
