8-12
S MIC Chassis
Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
L803 1-422-613-11 COIL, AIR CORE 0.68µH
L805 ! 1-460-225-11 COIL, HORIZONTAL LINEARITY 48.80
L807 1-406-987-21 INDUCTOR 4.7mH
L810 1-412-529-11 INDUCTOR 22µH
<NEON LAMP>
NL801 1-519-108-99 LAMP, NEON
<TRANSISTOR>
Q801 8-729-195-82 TRANSISTOR 2SC2958-L
Q802 8-729-201-62 TRANSISTOR 2SC2555-2
<RESISTOR>
R801 1-249-383-11 CARBON 1.5 5% 1/4W F
R802 1-249-377-11 CARBON 0.47 5% 1/4W F
R803 1-216-049-91 RES,CHIP 1K 5% 1/10W
R804 1-249-419-11 CARBON 1.5K 5% 1/4W F
R805 1-215-892-11 METAL OXIDE 1K 5% 2W F
R807 1-216-425-11 METAL OXIDE 56 5% 1W F
R808 1-202-846-00 SOLID 470K 20% 1/2W
R809 1-216-089-91 RES,CHIP 47K 5% 1/10W
R810 1-249-421-11 CARBON 2.2K 5% 1/4W F
R811 1-216-049-91 RES,CHIP 1K 5% 1/10W
R813 1-249-414-11 CARBON 560 5% 1/4W F
R814 1-249-377-11 CARBON 0.47 5% 1/4W F
R817 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
<VARIABLE RESISTOR>
RV801 1-223-102-00 RES, ADJ, WIREWOUND 120
<TRANSFORMER>
T801 1-437-082-31 HDT
T802 ! 1-439-526-12 TRANSFORMER ASSY, FLYBACK
***************************************************************
* A-1241-055-A MOUNTED PWB, FA
(PVM-8042Q, 8045Q, 9045PM)
* A-1241-070-A MOUNTED PWB, FA
(PVM-9042QM, 9045QM)
*************************************
1-533-223-11 CLIP, FUSE
* 1-641-723-11 PC BOARD, FA
<CAPACITOR>
C601 ! 1-136-889-11 FILM 0.22µF 20% 250V
<CONNECTOR>
CN601 * 1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P
CN602 * 1-508-765-00 PIN, CONNECTOR (5MM PITCH) 3P
CN603 * 1-564-507-11 PLUG, CONNECTOR 4P
<FUSE>
F601 ! 1-532-745-11 FUSE, GLASS TUBE 3.15A/125V
(PVM-8042Q, 8045Q, 9045PM)
F601 ! 1-576-230-11 FUSE (H.B.C) 3.15A/250V
(PVM-9042QM, PVM-9045QM)
<RESISTOR>
R602 ! 1-202-887-91 SOLID 1.5M 20% 1/2W
<SWITCH>
S601 ! 1-692-049-11 SWITCH, PUSH (AC POWER) (1KEY)
(3.0A/250V)
(PVM-8042Q, 8045Q, 9045PM)
S601 ! 1-692-050-11 SWITCH, PUSH (AC POWER) (1KEY)
(PVM-9042QM, 9045QM)
***************************************************************
* A-1275-162-A QA COMPLETE
***************
1-537-408-21 TERMINAL BOARD, INPUT/OUTPUT
1-537-410-11 TERMINAL BOARD, INPUT/OUTPUT
<CAPACITOR>
C401 1-126-514-11 ELECT 22µF 20% 16V
C402 1-126-514-11 ELECT 22µF 20% 16V
C403 1-126-514-11 ELECT 22µF 20% 16V
C404 1-126-514-11 ELECT 22µF 20% 16V
C405 1-126-514-11 ELECT 22µF 20% 16V
C406 1-126-514-11 ELECT 22µF 20% 16V
C407 1-126-514-11 ELECT 22µF 20% 16V
C408 1-115-867-11 ELECT 0.1µF 20% 50V
C409 1-126-514-11 ELECT 22µF 20% 16V
C410 1-126-514-11 ELECT 22µF 20% 16V
C411 1-126-514-11 ELECT 22µF 20% 16V
C412 1-126-514-11 ELECT 22µF 20% 16V
C413 1-126-514-11 ELECT 22µF 20% 16V
C414 1-126-791-11 ELECT 10µF 20% 16V
C415 1-126-791-11 ELECT 10µF 20% 16V
C416 1-126-791-11 ELECT 10µF 20% 16V
C417 1-126-791-11 ELECT 10µF 20% 16V
C418 1-126-791-11 ELECT 10µF 20% 16V
C419 1-126-791-11 ELECT 10µF 20% 16V
C420 1-126-791-11 ELECT 10µF 20% 16V
C421 1-102-125-00 CERAMIC 0.0047µF 10% 50V
C422 1-115-868-11 ELECT 0.22µF 20% 50V
C423 1-126-791-11 ELECT 10µF 20% 16V
C424 1-126-791-11 ELECT 10µF 20% 16V
C425 1-137-397-11 FILM 0.047µF 5% 100V
C426 1-128-499-11 ELECT 220µF 20% 16V
C427 1-128-499-11 ELECT 220µF 20% 16V
C428 1-107-909-11 ELECT 47µF 20% 16V
C429 1-126-514-11 ELECT 22µF 20% 16V
C430 1-163-033-91 CERAMIC CHIP 0.022µF 50V
[P][FA][QA]
