8-15
S MIC Chassis
Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
R1427 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1428 1-249-465-11 CARBON 47K 5% 1/4W
R1429 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1430 1-216-049-91 RES,CHIP 1K 5% 1/10W
<VARIABLE RESISTOR>
RV401 1-237-994-11 RES, VAR, CARBON 20K
<SWITCH>
S401 1-570-145-11 SWITCH, SLIDE
***************************************************************
* A-1331-183-B MOUNTED PWB, CA
*******************
1-251-244-11 SOCKET, CRT
1-641-720-11 PC BOARD, CA
* 4-376-132-11 COVER (REAR LID), CV VOL
* 4-376-133-11 COVER (MAIN), CV VOL
<CAPACITOR>
C701 1-162-114-00 CERAMIC 0.0047µF 10% 2KV
C710 1-161-830-00 CERAMIC 0.0047µF 99% 500V
<CONNECTOR>
CN701 * 1-564-509-11 PLUG, CONNECTOR 6P
CN702 * 1-508-784-00 PIN, CONNECTOR (5MM PITCH) 1P
CN703 * 1-564-508-11 PLUG, CONNECTOR 5P
<COIL>
L701 1-410-668-11 INDUCTOR 27µH
<RESISTOR>
R701 1-202-822-00 SOLID 2.2K 20% 1/2W
R702 1-202-822-00 SOLID 2.2K 20% 1/2W
R703 1-202-822-00 SOLID 2.2K 20% 1/2W
R704 1-202-838-00 SOLID 100K 20% 1/2W
R706 1-202-842-11 SOLID 220K 20% 1/2W
R707 1-202-838-00 SOLID 100K 10% 1/2W
<VARIABLE RESISTOR>
RV701 1-230-164-00 RES, ADJ, METAL GLAZE 55M
***************************************************************
* A-1346-787-A D BOARD, COMPLETE
(PVM-8042Q, 8045Q, 9042Q, 9045QM)
* A-1346-806-A D BOARD, COMPLETE (PVM-9045PM)
*************************************
1-533-189-11 HOLDER, FUSE
* 3-738-015-01 COVER, (DIA. 6) CARBON VR
4-382-854-01 SCREW (M3X8), P, SW (+)
4-382-854-11 SCREW (M3X10), P, SW (+)
<CAPACITOR>
C501 1-104-664-11 ELECT 47µF 20% 16V
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
C502 1-126-964-11 ELECT 10µF 20% 50V
C503 1-126-935-11 ELECT 470µF 20% 16V
C504 1-126-959-11 ELECT 0.47µF 20% 50V
C505 1-106-381-12 MYLAR 0.039µF 10% 100V
C506 1-126-960-11 ELECT 1µF 20% 50V
C507 1-137-150-11 MYLAR 0.01µF 10% 100V
C508 1-126-960-11 ELECT 1µF 20% 50V
C509 1-137-194-81 FILM 0.47µF 5% 50V
C510 1-136-161-00 FILM 0.047µF 5% 50V
C511 1-107-902-11 ELECT 1µF 20% 50V
C512 1-106-375-12 MYLAR 0.022µF 10% 100V
C513 1-106-375-12 MYLAR 0.022µF 10% 100V
C514 1-137-350-11 MYLAR 0.015µF 10% 100V
C515 1-126-961-11 ELECT 2.2µF 20% 50V
C516 1-126-961-11 ELECT 2.2µF 20% 50V
C517 1-130-480-00 FILM 0.0056µF 5% 50V
C518 1-163-245-11 CERAMIC CHIP 56PF 5% 50V
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
C519 1-126-963-11 ELECT 4.7µF 20% 50V
C520 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
C521 1-107-906-11 ELECT 10µF 20% 50V
C523 1-106-363-00 MYLAR 0.0068µF 10% 100V
C524 1-102-116-00 CERAMIC 680PF 10% 50V
C525 1-102-820-00 CERAMIC 330PF 5% 50V
C526 1-102-074-00 CERAMIC 0.001µF 10% 50V
C527 1-107-910-11 ELECT 100µF 20% 50V
C528 1-102-125-00 CERAMIC 0.0047µF 10% 50V
C529 1-107-909-11 ELECT 47µF 20% 50V
C530 1-163-097-00 CERAMIC CHIP 15PF 5% 50V
C531 1-131-370-00 TANTALUM 6.8µF 10% 16V
C532 1-107-914-11 ELECT 1000µF 20% 25V
C533 1-126-963-11 ELECT 4.7µF 20% 50V
C534 1-107-713-11 ELECT 4.7µF 20% 50V
C535 1-136-161-00 FILM 0.047µF 5% 50V
C536 1-126-963-11 ELECT 4.7µF 20% 50V
C537 1-107-894-11 ELECT 220µF 20% 35V
C538 1-126-967-11 ELECT 47µF 20% 50V
C539 1-136-113-00 FILM 2µF 5% 200V
C540 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C541 1-163-035-00 CERAMIC CHIP 0.047µF 50V
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
C542 1-126-935-11 ELECT 470µF 20% 16V
C545 1-126-933-11 ELECT 100µF 20% 16V
C546 1-126-964-11 ELECT 10µF 20% 50V
C547 1-126-964-11 ELECT 10µF 20% 50V
C548 1-126-964-11 ELECT 10µF 20% 50V
C549 1-126-964-11 ELECT 10µF 20% 50V
C550 1-126-964-11 ELECT 10µF 20% 50V
C551 1-126-963-11 ELECT 4.7µF 20% 50V
C552 1-101-004-00 CERAMIC 0.01µF 50V
C553 1-126-935-11 ELECT 470µF 20% 16V
[QA][CA][D]
