8-16
S MIC Chassis
Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
C563 1-137-353-11 MYLAR 0.047µF 10% 100V
C564 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C567 1-107-906-11 ELECT 10µF 20% 50V
C568 1-130-736-11 FILM 0.01µF 5% 50V
C569 1-136-479-11 FILM 0.001µF 5% 50V
C570 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C571 1-126-971-11 ELECT 470µF 20% 50V
C572 1-101-004-00 CERAMIC 0.01µF 50V
C574 1-136-481-11 MYLAR 0.0022µF 10% 100V
C575 1-136-481-11 MYLAR 0.0022µF 10% 100V
C578 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C831 1-107-906-11 ELECT 10µF 20% 50V
C832 1-107-906-11 ELECT 10µF 20% 50V
C833 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C834 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
C835 1-163-209-00 CERAMIC CHIP 0.0015µF 5% 50V
C836 1-126-964-11 ELECT 10µF 20% 50V
C837 1-163-209-00 CERAMIC CHIP 0.0015µF 5% 50V
C838 1-136-495-11 FILM 0.068µF 5% 50V
C839 1-136-481-11 MYLAR 0.0022µF 10% 100V
C840 1-163-209-00 CERAMIC CHIP 0.0015µF 5% 50V
C841 1-163-209-00 CERAMIC CHIP 0.0015µF 5% 50V
C843 1-107-901-11 ELECT 0.47µF 20% 50V
C844 1-107-901-11 ELECT 0.47µF 20% 50V
C845 1-107-888-11 ELECT 47µF 20% 25V
C846 1-107-906-11 ELECT 10µF 20% 50V
C847 1-126-965-11 ELECT 22µF 20% 50V
C848 1-131-351-00 TANTALUM 4.7µF 10% 35V
C849 1-164-182-11 CERAMIC CHIP 0.0033µF 10% 50V
C1601 1-126-964-11 ELECT 10µF 20% 50V
C1602 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C1603 1-111-108-11 ELECT 18µF 20% 50V
C1604 1-115-842-11 ELECT 0.001F 20% 50V
C1605 1-126-972-11 ELECT 1000µF 20% 50V
C1606 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1607 1-126-964-11 ELECT 10µF 20% 50V
C1608 1-126-965-11 ELECT 22µF 20% 50V
C1609 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1610 1-126-963-11 ELECT 4.7µF 20% 50V
C1611 1-104-668-11 ELECT 33µF 20% 35V
C1612 1-136-257-00 FILM 0.0039µF 5% 50V
C1613 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C1614 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1615 1-107-901-11 ELECT 0.47µF 20% 50V
C1620 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C1621 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C1641 1-163-035-00 CERAMIC CHIP 0.047µF 50V
C1642 1-126-964-11 ELECT 10µF 20% 50V
C1643 1-126-964-11 ELECT 10µF 20% 50V
<CONNECTOR>
CN501 * 1-564-506-11 PLUG, CONNECTOR 3P
CN502 * 1-564-011-11 PIN, CONNECTOR 12P
CN504 * 1-564-508-11 PLUG, CONNECTOR 5P
CN505 * 1-564-509-11 PLUG, CONNECTOR 6P
CN507 * 1-564-511-11 PLUG, CONNECTOR 8P
CN508 * 1-580-837-11 PIN, CONNECTOR (PC BOARD) 3P
CN509 * 1-564-506-11 PLUG, CONNECTOR 3P
CN600 * 1-564-001-11 PIN, CONNECTOR 2P
<DIODE>
D501 8-719-404-49 DIODE MA111
D502 8-719-404-49 DIODE MA111
D503 8-719-404-49 DIODE MA111
D504 8-719-404-49 DIODE MA111
D506 8-719-908-03 DIODE GP08D
D507 8-719-404-49 DIODE MA111
D508 8-719-404-49 DIODE MA111
D511 8-719-404-49 DIODE MA111
D512 8-719-404-49 DIODE MA111
D514 8-719-404-49 DIODE MA111
D520 8-719-800-76 DIODE 1SS226
D521 8-719-800-76 DIODE 1SS226
D831 8-719-404-49 DIODE MA111
D832 8-719-404-49 DIODE MA111
D833 8-719-404-49 DIODE MA111
D834 8-719-404-49 DIODE MA111
D835 8-719-109-89 DIODE RD5.6ESB2
D836 8-719-977-69 DIODE DTZ24B
D848 8-719-800-76 DIODE 1SS226
D1601 8-719-105-99 DIODE RD6.2M-B1
D1603 8-719-977-61 DIODE DTZ20B
D1606 8-719-981-00 DIODE ERC81-004
D1607 8-719-981-00 DIODE ERC81-004
D1608 8-719-978-24 DIODE DTZ-TT11-5.6A
D1609 8-719-977-49 DIODE DTZ15B
D1610 8-719-404-49 DIODE MA111
D1612 8-719-404-49 DIODE MA111
D1615 8-719-404-49 DIODE MA111
D1617 8-719-977-49 DIODE DTZ15B
D1618 8-719-977-49 DIODE DTZ15B
D1620 8-719-801-78 DIODE 1SS184
D1621 8-719-510-12 DIODE D10SC4M
D1622 8-719-801-78 DIODE 1SS184
D1623 8-719-801-78 DIODE 1SS184
D1626 8-719-404-49 DIODE MA111
D1627 8-719-404-49 DIODE MA111
D1628 8-719-404-49 DIODE MA111
D1635 8-719-404-49 DIODE MA111
D1699 8-719-404-49 DIODE MA111
<FUSE>
F1601 ! 1-532-777-21 FUSE, MICRO (SECONDARY) 1.25A/125V
F1602 ! 1-532-747-11 FUSE, GLASS TUBE (H.B.C) 5A/125V
(PVM-8042Q, 8045Q, 9045PM)
F1602 ! 1-576-232-11 FUSE, (H.B.C.) 5A/250V
(PVM-9042QM, 9045QM)
<IC>
IC501 8-759-909-70 IC CX23025
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
IC502 8-759-100-60 IC UPC1377C
IC503 8-759-801-98 IC LA7830
IC504 8-759-231-58 IC TA7812S
IC505 8-759-009-51 IC MC14538BF
[D]
