Sony HR TRINITRON PVM-8045Q User Manual

8-17
S MIC Chassis
Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
IC506 8-759-209-54 IC TC4S01F
IC507 8-759-209-69 IC TC4S11F
IC831 8-759-473-06 IC BU4011BF-E2
IC832 8-759-473-07 IC BU4070BF-E2
IC833 8-759-009-51 IC MC14538BF
IC1601 8-759-510-73 IC BA10393F-E2
<CHIP CONDUCTOR>
JR507 1-216-295-91 SHORT 0
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
JR510 1-216-295-91 SHORT 0
JR518 1-216-295-91 SHORT 0
JR601 1-216-295-91 SHORT 0
JR602 1-216-295-91 SHORT 0
<COIL>
L501 1-414-502-41 INDUCTOR 33mH
L502 1-410-665-31 INDUCTOR 15µH
L503 1-424-625-11 INDUCTOR 381.4µH
L506 1-412-530-31 INDUCTOR 27µH
L1601 1-459-155-00 COIL (WITH CORE) 45µH
L1602 1-402-785-11 INDUCTOR 600µH
L1603 1-410-397-21 FERRITE 1.1µH
<TRANSISTOR>
Q501 1-801-806-11 TRANSISTOR DTC144EKA-T146
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
Q502 1-801-806-11 TRANSISTOR DTC144EKA-T146
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
Q503 8-729-901-06 TRANSISTOR DTA144EK
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
Q504 1-801-806-11 TRANSISTOR DTC144EKA-T146
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
Q505 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q508 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q509 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q512 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q513 8-729-216-22 TRANSISTOR 2SA1162-G
Q514 8-729-216-22 TRANSISTOR 2SA1162-G
Q515 8-729-313-42 TRANSISTOR 2SD1134-C
Q518 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q519 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q532 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q569 8-729-907-26 TRANSISTOR IMX1
Q570 8-729-901-00 TRANSISTOR DTC124EK
Q571 8-729-901-00 TRANSISTOR DTC124EK
Q576 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q579 8-729-920-48 TRANSISTOR IMH2
Q599 8-729-920-48 TRANSISTOR IMH2
Q600 8-729-901-00 TRANSISTOR DTC124EK
Q601 8-729-901-00 TRANSISTOR DTC124EK
Q833 8-729-216-22 TRANSISTOR 2SA1162-G
Q834 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q835 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q836 8-729-255-12 TRANSISTOR 2SC2551-O
Q1601 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1602 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1603 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1604 8-729-216-22 TRANSISTOR 2SA1162-G
Q1605 8-729-119-80 TRANSISTOR 2SC2688-LK
Q1606 8-729-133-42 TRANSISTOR 2SC2334-L
Q1607 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1608 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1609 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1610 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1611 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1612 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1613 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1614 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1615 8-729-216-22 TRANSISTOR 2SA1162-G
Q1616 8-729-216-22 TRANSISTOR 2SA1162-G
Q1617 8-729-216-22 TRANSISTOR 2SA1162-G
Q1618 8-729-216-22 TRANSISTOR 2SA1162-G
Q1619 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1620 8-729-120-28 TRANSISTOR 2SC1623-L5L6
<RESISTOR>
R501 1-216-089-91 RES,CHIP 47K 5% 1/10W
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
R502 1-216-089-91 RES,CHIP 47K 5% 1/10W
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
R503 1-249-437-11 CARBON 47K 5% 1/4W F
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
R504 1-216-073-00 RES,CHIP 10K 5% 1/10W
R505 1-249-393-11 CARBON 10 5% 1/4W F
R506 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R507 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R508 1-216-085-00 RES,CHIP 33K 5% 1/10W
R509 1-216-687-11 METAL CHIP 33K 0.50% 1/10W
R510 1-216-683-11 METAL CHIP 22K 0.50% 1/10W
R511 1-216-675-11 METAL CHIP 10K 0.50% 1/10W
R512 1-218-761-11 METAL CHIP 240K 0.50% 1/10W
R513 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R514 1-218-754-11 METAL CHIP 120K 0.50% 1/10W
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
R515 1-216-081-00 RES,CHIP 22K 5% 1/10W
R516 1-216-073-00 RES,CHIP 10K 5% 1/10W
R517 1-218-762-11 METAL CHIP 270K 0.50% 1/10W
R518 1-249-422-11 CARBON 2.7K 5% 1/4W F
R519 1-216-085-00 RES,CHIP 33K 5% 1/10W
R520 1-216-677-11 METAL CHIP 12K 0.50% 1/10W
R521 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R522 1-216-107-00 RES,CHIP 270K 5% 1/10W
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
R523 1-216-081-00 RES,CHIP 22K 5% 1/10W
R524 1-216-049-91 RES,CHIP 1K 5% 1/10W
R525 1-216-434-11 METAL OXIDE 1.8K 5% 1W F
R526 1-216-079-00 RES,CHIP 18K 5% 1/10W
R527 1-249-437-11 CARBON 47K 5% 1/4W F
R528 1-216-073-00 RES,CHIP 10K 5% 1/10W
R529 1-216-073-00 RES,CHIP 10K 5% 1/10W
R530 1-216-089-91 RES,CHIP 47K 5% 1/10W
R531 1-216-089-91 RES,CHIP 47K 5% 1/10W
(PVM-8042Q, 8045Q, 9042QM, 9045QM)
R532 1-216-097-91 RES,CHIP 100K 5% 1/10W
[D]
