Sony HR TRINITRON PVM-8045Q User Manual

8-19
S MIC Chassis
Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
R1622 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1623 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1624 1-216-246-00 RES,CHIP 100K 5% 1/8W
R1625 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R1626 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1627 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1628 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1629 1-216-683-11 METAL CHIP 22K 0.50% 1/10W
R1630 1-216-683-11 METAL CHIP 22K 0.50% 1/10W
R1631 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1632 1-216-042-00 RES,CHIP 510 5% 1/10W
R1633 1-216-109-00 RES,CHIP 330K 5% 1/10W
R1634 1-216-099-00 RES,CHIP 120K 5% 1/10W
R1635 1-216-097-91 RES,CHIP 100K 5% 1/10W
R1636 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1640 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R1641 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1642 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1643 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R1644 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R1645 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1646 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1647 1-216-685-11 METAL CHIP 27K 0.50% 1/10W
R1648 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R1649 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R1650 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R1651 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R1652 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R1653 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R1654 1-216-681-11 METAL CHIP 18K 0.50% 1/10W
R1655 1-216-081-00 RES,CHIP 22K 5% 1/10W
R1656 1-216-643-11 METAL CHIP 470 0.50% 1/10W
R1657 1-216-081-00 RES,CHIP 22K 5% 1/10W
R1658 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R1659 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1660 1-216-649-11 METAL CHIP 820 0.50% 1/10W
R1661 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1691 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1692 1-216-081-00 RES,CHIP 22K 5% 1/10W
R1693 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R1694 1-216-081-00 RES,CHIP 22K 5% 1/10W
R1695 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R1696 1-216-073-00 RES,CHIP 10K 5% 1/10W
<VARIABLE RESISTOR>
RV501 1-238-019-11 RES, ADJ, CARBON 47K
RV502 1-241-765-11 RES, ADJ, CARBON 22K
RV503 1-241-763-11 RES, ADJ, CERMET 4.7K
RV504 1-224-250-XX RES, ADJ, METAL GLAZE 2.2K
RV505 1-241-759-11 RES, ADJ, CARBON 220
RV507 1-241-762-11 RES, ADJ, CARBON 2.2K
RV508 1-241-761-11 RES, ADJ, CARBON 1K
RV509 1-241-768-11 RES, ADJ, CARBON 220K
RV511 1-241-763-11 RES, ADJ, CARBON 4.7K
RV512 1-241-763-11 RES, ADJ, CARBON 4.7K
RV514 1-238-019-11 RES, ADJ, CARBON 47K
RV515 1-241-768-11 RES, ADJ, CARBON 220K
RV516 1-241-763-11 RES, ADJ, CERMET 4.7K
RV517 1-241-760-11 RES, ADJ, CARBON 470
RV518 1-241-763-11 RES, ADJ, CARBON 4.7K
RV831 1-228-997-00 RES, ADJ, METAL GLAZE 100K
RV832 1-241-764-11 RES, ADJ, CERMET 10K
RV833 ! RES, ADJ, METAL GLAZE 47K
RV1601! 1-241-762-11 RES, ADJ, CERMET 2.2K
RV1602 1-241-761-11 RES, ADJ, CARBON 1K
RV1603! RES, ADJ, METAL GLAZE 47K
<RELAY>
RY1601 1-755-022-11 RELAY, POWER
<TRANSFORMER>
T1601 1-437-216-11 TRANSFORMER, DRIVE
***************************************************************
* A-1372-542-A MOUNTED PWB, HA
*******************
* 4-348-208-00 HOLDER, LED
<CAPACITOR>
C001 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C002 1-163-038-91 CERAMIC CHIP 0.1µF 25V
<CONNECTOR>
CN001 1-506-478-11 PIN, CONNECTOR 13P
CN002 * 1-564-009-11 PIN, CONNECTOR 10P
CN003 * 1-564-004-11 PIN, CONNECTOR 5P
<DIODE>
D001 8-719-920-05 DIODE SLP281C-50
D002 8-719-109-68 DIODE RD3.6ESB1
D003 8-719-404-49 DIODE MA111
<IC>
IC001 8-759-209-69 IC TC4S11F
<CHIP CONDUCTOR>
JR003 1-216-295-91 SHORT 0
JR006 1-216-295-91 SHORT 0
JR007 1-216-295-91 SHORT 0
<TRANSISTOR>
Q001 8-729-120-28 TRANSISTOR 2SC1623-L5L6
[D][HA]
