8-20
S MIC Chassis
Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
<RESISTOR>
R001 1-247-713-11 CARBON 1K 5% 1/4W
R004 1-216-081-00 RES,CHIP 22K 5% 1/10W
R006 1-216-049-91 RES,CHIP 1K 5% 1/10W
R007 1-216-049-91 RES,CHIP 1K 5% 1/10W
R008 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R009 1-216-049-91 RES,CHIP 1K 5% 1/10W
R010 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
<VARIABLE RESISTOR>
RV001 1-225-385-11 RES, VAR, CARBON 20K
RV002 1-225-385-11 RES, VAR, CARBON 20K
RV003 1-225-385-11 RES, VAR, CARBON 20K
RV004 1-225-385-11 RES, VAR, CARBON 20K
RV005 1-225-385-11 RES, VAR, CARBON 20K
RV006 1-225-385-11 RES, VAR, CARBON 20K
RV007 1-226-773-11 RES, ADJ, METAL GLAZE 22K
RV008 1-226-773-11 RES, ADJ, METAL GLAZE 22K
RV009 1-226-773-11 RES, ADJ, METAL GLAZE 22K
RV010 1-226-773-11 RES, ADJ, METAL GLAZE 22K
RV011 1-226-773-11 RES, ADJ, METAL GLAZE 22K
RV012 1-226-773-11 RES, ADJ, METAL GLAZE 22K
<SWITCH>
S001 1-554-419-00 SWITCH, PUSH (1 KEY)
S002 1-554-419-00 SWITCH, PUSH (1 KEY)
S003 1-554-419-00 SWITCH, PUSH (1 KEY)
S004 1-554-419-00 SWITCH, PUSH (1 KEY)
S005 1-554-419-00 SWITCH, PUSH (1 KEY)
S006 1-554-419-00 SWITCH, PUSH (1 KEY)
S007 1-572-522-11 SWITCH, PUSH (1 KEY)
S008 1-554-419-00 SWITCH, PUSH (1 KEY)
***************************************************************
*1-641-724-11 PC BOARD, X
*************
<CONNECTOR>
CN21 * 1-564-518-11 PLUG, CONNECTOR 3P
<DIODE>
D21 8-719-023-78 DIODE SEL3810DLC05
D22 8-719-023-78 DIODE SEL3810DLC05
D23 8-719-023-78 DIODE SEL3810DLC05
***************************************************************
* A-1394-917-A S BOARD, COMPLETE
*********************
<CAPACITOR>
C1101 1-163-119-00 CERAMIC CHIP 120PF 5% 50V
C1102 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1103 1-124-589-11 ELECT 47µF 20% 16V
C1104 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C1105 1-163-248-11 CERAMIC CHIP 75PF 5% 50V
C1106 1-163-101-00 CERAMIC CHIP 22PF 5% 50V
C1107 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1108 1-163-119-00 CERAMIC CHIP 120PF 5% 50V
C1109 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C1110 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C1111 1-163-018-00 CERAMIC CHIP 0.0056µF 10% 50V
C1112 1-126-160-11 ELECT 1µF 20% 50V
C1113 1-163-119-00 CERAMIC CHIP 120PF 5% 50V
C1114 1-163-103-00 CERAMIC CHIP 27PF 5% 50V
C1115 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1116 1-163-248-11 CERAMIC CHIP 75PF 5% 50V
C1117 1-124-589-11 ELECT 47µF 20% 16V
C1118 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1119 1-163-020-00 CERAMIC CHIP 0.0082µF 10% 50V
C1120 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C1121 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C1122 1-163-222-11 CERAMIC CHIP 5PF 0.25PF 50V
C1123 1-163-097-00 CERAMIC CHIP 15PF 5% 50V
C1130 1-163-097-00 CERAMIC CHIP 15PF 5% 50V
C1131 1-163-097-00 CERAMIC CHIP 15PF 5% 50V
<CONNECTOR>
CN1101* 1-565-488-11 CONNECTOR, BOARD TO BOARD 12P
<DIODE>
D1101 8-719-404-49 DIODE MA111
D1102 8-719-404-49 DIODE MA111
<IC>
IC1101 8-752-056-67 IC CXA1214P
<COIL>
L1101 1-408-605-31 INDUCTOR 15µH
L1102 1-404-496-00 COIL
L1103 1-404-496-00 COIL
L1104 1-408-605-31 INDUCTOR 15µH
L1110 1-412-008-31 INDUCTOR CHIP 15µH
L1111 1-412-008-31 INDUCTOR CHIP 15µH
<TRANSISTOR>
Q1101 8-729-216-22 TRANSISTOR 2SA1162-G
Q1102 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1103 8-729-216-22 TRANSISTOR 2SA1162-G
Q1104 8-729-216-22 TRANSISTOR 2SA1162-G
Q1105 1-801-806-11 TRANSISTOR DTC144EK-T147
Q1106 1-801-806-11 TRANSISTOR DTC144EK-T147
Q1107 8-729-109-44 TRANSISTOR 2SK94-X4
[HA][X][S]
