Sony HR TRINITRON PVM-8045Q User Manual

8-21
S MIC Chassis
Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
Q1108 8-729-120-28 TRANSISTOR 2SC1623-L5L6
<RESISTOR>
R1101 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R1102 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R1103 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R1104 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1105 1-216-031-00 RES,CHIP 180 5% 1/10W
R1106 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R1107 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R1108 1-216-039-00 RES,CHIP 390 5% 1/10W
R1109 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R1110 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R1111 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1112 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R1113 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R1114 1-216-055-00 RES,CHIP 1.8K 5% 1/10W
R1115 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R1116 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R1117 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R1118 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1119 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1120 1-216-097-91 RES,CHIP 100K 5% 1/10W
R1121 1-216-121-91 RES,CHIP 1M 5% 1/10W
R1122 1-216-039-00 RES,CHIP 390 5% 1/10W
R1123 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1124 1-216-029-00 RES,CHIP 150 5% 1/10W
R1125 1-216-029-00 RES,CHIP 150 5% 1/10W
R1126 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R1127 1-216-043-91 RES,CHIP 560 5% 1/10W
R1128 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1129 1-216-091-00 RES,CHIP 56K 5% 1/10W
R1131 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1132 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1133 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1134 1-216-091-00 RES,CHIP 56K 5% 1/10W
<VARIABLE RESISTOR>
RV1101 1-241-763-11 RES, ADJ, CARBON 4.7K
RV1102 1-241-762-11 RES, ADJ, CARBON 2.2K
<TRANSFORMER>
T1101 1-404-584-11 COIL
***************************************************************
G BOARD (SOPS-1021)
**********************
4-812-134-11 RIVET,NYLON
<CAPACITOR>
C602 ! 1-136-889-11 FILM 0.22MF 20% 250V
C603 ! 1-161-741-51 CERAMIC 1000PF 10% 400V
C604 ! 1-161-741-51 CERAMIC 1000PF 10% 400V
C605 ! 1-161-741-51 CERAMIC 1000PF 10% 400V
C608 1-162-599-12 CERAMIC 4700PF 20% 400V
C609 1-162-599-12 CERAMIC 4700PF 20% 400V
C610 1-125-724-11 ELECT 100MF 20% 400V
C611 1-136-206-11 FILM 0.33MF 10% 630V
C612 1-107-909-11 ELECT 47MF 20% 50V
C613 1-136-169-00 FILM 0.22MF 5% 50V
C614 1-136-169-00 FILM 0.22MF 5% 50V
C615 1-130-471-00 FILM 0.001MF 5% 50V
C616 1-130-479-91 FILM 4700PF 5% 50V
C651 1-161-825-11 CERAMIC 220PF 10% 500V
C652 1-111-065-11 ELECT 680MF 20% 25V
C653 1-126-969-11 ELECT 220MF 20% 35V
C654 1-130-483-91 FILM 0.01MF 5% 50V
<CONNECTOR>
CN610 * 1-560-436-00 PIN,CONNECTOR 3P
CN651 * 1-564-518-11 PLUG,CONNECTOR 3P
<DIODE>
D601 ! 8-719-510-22 DIODE D3SB60
D602 8-719-911-19 DIODE 1SS119-25
D603 8-719-970-87 DIODE ERA38-06
D604 8-719-970-87 DIODE ERA38-06
D605 8-719-110-53 DIODE RD20ESB3
D651 ! 9-907-820-01 DIODE ESAC39M
<IC>
IC601 1-809-086-12 IC CH-1018
IC651 8-759-908-15 IC TL431CLP
<COIL>
L601 ! 1-424-616-11 L.F.T
L602 ! 1-424-574-11 L.F.T
L651 1-424-255-11 COIL, CHOCKE (MOLDE) 10µH
L652 1-424-615-21 COIL,CHOKE
<PHOTO COUPLER>
PH601 8-719-159-90 PHOTO COUPLER PS2652-P
<TRANSISTOR>
Q601 8-729-322-18 TRANSISTOR 2SK1402A
<RESISTOR>
R601 1-216-411-11 METAL OXIDE 1.5 5% 5W F
R602 1-216-411-11 METAL OXIDE 1.5 5% 5W F
R603 1-215-904-11 METAL OXIDE 100K 5% 2W F
R604 1-215-904-11 METAL OXIDE 100K 5% 2W F
R605 1-212-865-00 FUSIBLE 22 5% 1/4W F
R606 1-249-404-00 CARBON 82 5% 1/4W
[S][G]
