8-22
S MIC Chassis
Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark
R607 1-260-128-91 CARBON 270K 5% 1/2W
R608 1-260-128-91 CARBON 270K 5% 1/2W
R609 1-215-904-51 METAL OXIDE 100K 5% 2W F
R610 1-216-341-11 METAL OXIDE 0.22 10% 1/2W
R611 1-249-395-11 CARBON 15 5% 1/4W
R612 1-249-399-11 CARBON 33 5% 1/4W
R613 1-215-904-51 METAL OXIDE 100K 5% 2W F
R614 1-247-815-91 CARBON 220 5% 1/4W
R620 1-218-265-11 METAL GRAZE 8.2M 5% 1W
R651 1-215-886-11 METAL OXIDE 100 5% 2W F
R652 1-215-886-11 METAL OXIDE 100 5% 2W F
R653 1-260-107-11 CARBON 4.7K 5% 1/2W
R654 1-260-107-11 CARBON 4.7K 5% 1/2W
R655 1-249-435-11 CARBON 33K 5% 1/4W
R656 1-249-435-11 CARBON 33K 5% 1/4W
R657 1-249-420-11 CARBON 1.8K 5% 1/4W
R658 1-249-435-11 CARBON 33K 5% 1/4W
<VALIABLE RESISTOR>
RV651 ! RES,ADJ,CARBON 1K
<TRANSFORMER>
T601 1-450-760-12 TRANSFORMER, CONVERTER
***************************************************************
ACCESSORIES AND PACKING MATERIALS
*****************************************
1-690-871-11 CABLE (MINI DIN) 8P
2-990-241-02 HOLDER (A), PLUG
2-990-242-01 HOLDER (B), PLUG
3-865-058-11 OPERATING INSTRUCTIONS
(PVM-8042Q, 8045Q)
(ENGLISH, FRENCH, SPANISH)
3-865-058-21 OPERATING INSTRUCTIONS
(PVM-9042Q, 9045QM)
(ENGLISH, FRENCH, GERMAN,
ITALIAN, SPANISH, CHINESE)
3-865-341-11 OPERATING INSTRUCTIONS
(PVM-9045PM) (ENGLISH)
4-034-835-01 PLATE, TALLY
! 1-765-718-11 CORD SET, POWER (125V/10.0A)
(PVM-8042Q, 8045Q, 9045PM)
! 1-782-929-11 CORD, POWER SUPPLY (BS 3P)
(250V/10.0A) (PVM-9042QM, 9045QM)
* 4-034-955-01 CUSHION (UPPER) (ASSY)
* 4-034-956-01 CUSHION (LOWER) (ASSY)
* 4-384-927-11 BAG, PROTECTION
***************************************************************
MISCELLANEOS
****************
! 1-413-720-21 SWITCHING REGULATOR
! 1-416-882-11 COIL, DEMAGNETIC
! 1-451-319-22 DEFLECTION YOKE (Y9FXC)
! 8-737-154-05 PICTURE TUBE SD-167
(PVM-8042Q, 9042QM (AEP))
! 8-737-651-05 PICTURE TUBE 09FX
(PVM-8045Q, 9042QM (AUS),
9045QM (AEP), 9045QM (AUS),
9045PM (BRZ))
[G]
