HT-NT3
66
Pin No. Pin Name I/O Description
AG14 RDQ0 I/O Two-way data bus with the SD-RAM
AG16 RDQS0 O Data strobe signal (positive) output to the SD-RAM
AG17 RCLK0 O Clock signal (positive) output to the SD-RAM
AG18 RDQS1_ O Data strobe signal (negative) output to the SD-RAM
AG19,
AG20
RDQ7, RDQ4 I/O Two-way data bus with the SD-RAM
AG21 to
AG23
NFD7, NFD4, NFD2 I/O Two-way data bus with the NAND fl ash
AG25 GPIO8 O VBUS on/off control signal output terminal for WLAN/BT COMBO card "H": VBUS on
AG26 VCLK O Serial data transfer clock signal output to the system controller
AG27 VDATA I Serial data input from the system controller
AG28 LCDRD O Serial data output to the system controller
AH1 to AH3
RDQ18, RDQ19,
RDQ24
I/O Two-way data bus with the SD-RAM
AH4 RDQM3 O Data mask signal output to the SD-RAM
AH5 RDQS2_ O Data strobe signal (negative) output to the SD-RAM
AH6 RCLK1_ O Clock signal (negative) output to the SD-RAM
AH7 RDQS3 O Data strobe signal (positive) output to the SD-RAM
AH8 RDQ23 I/O Two-way data bus with the SD-RAM
AH10,
AH11
RA0, RA7 O Address signal output to the SD-RAM
AH13 RCKE O Clock enable signal output to the SD-RAM
AH14 RDQ2 I/O Two-way data bus with the SD-RAM
AH16 RDQS0_ O Data strobe signal (negative) output to the SD-RAM
AH17 RCLK0_ O Clock signal (negative) output to the SD-RAM
AH18 RDQS1 O Data strobe signal (positive) output to the SD-RAM
AH19 RDQM0 O Data mask signal output to the SD-RAM
AH20 RDQ6 I/O Two-way data bus with the SD-RAM
AH22,
AH23
NFD5, NFD3 I/O Two-way data bus with the NAND fl ash
AH25 OPWRSB O Power control signal output to the system controller
AH26 UATXD - Not used
AH27 VSTB - Not used
AH28 IR - Not used
