Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 75 —
R601 1-249-409-11 CARBON 220 5% 1/4W F
R602 1-249-409-11 CARBON 220 5% 1/4W F
R608 1-249-409-11 CARBON 220 5% 1/4W F
R609 1-249-433-11 CARBON 22K 5% 1/4W
R611 1-249-409-11 CARBON 220 5% 1/4W F
R612 1-249-409-11 CARBON 220 5% 1/4W F
! R621 1-212-851-00 FUSIBLE 5.6 5% 1/4W F
! R622 1-212-851-00 FUSIBLE 5.6 5% 1/4W F
R623 1-249-432-11 CARBON 18K 5% 1/4W
R624 1-249-432-11 CARBON 18K 5% 1/4W
R625 1-249-429-11 CARBON 10K 5% 1/4W
< VARIABLE RESISTOR >
RV301 1-238-598-11 RES, ADJ, CARBON 2.2K (B DECK PB LEVEL L)
RV311 1-238-598-11 RES, ADJ, CARBON 2.2K (A DECK PB LEVEL L)
RV341 1-241-768-11 RES, ADJ, CARBON 220K (REC BIAS L)
RV401 1-238-598-11 RES, ADJ, CARBON 2.2K (B DECK PB LEVEL R)
RV411 1-238-598-11 RES, ADJ, CARBON 2.2K (A DECK PB LEVEL R)
RV441 1-241-768-11 RES, ADJ, CARBON 220K(REC BIAS R)
< TRANSFORMER >
T621 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
************************************************************
* A-4699-697-A BD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C102 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C103 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C105 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C106 1-164-346-11 CERAMIC CHIP 1uF 16V
C107 1-164-346-11 CERAMIC CHIP 1uF 16V
C108 1-163-035-00 CERAMIC CHIP 0.047uF 50V
C109 1-163-145-00 CERAMIC CHIP 0.0015uF 5% 50V
C110 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C111 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C112 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C113 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C115 1-126-607-11 ELECT CHIP 47uF 20% 4V
C116 1-126-607-11 ELECT CHIP 47uF 20% 4V
C117 1-126-209-11 ELECT CHIP 100uF 20% 4V
C118 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C119 1-163-091-00 CERAMIC CHIP 8PF 50V
C120 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C121 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C123 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C124 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C125 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C140 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C141 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C151 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C153 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C154 1-164-336-11 CERAMIC CHIP 0.33uF 25V
C156 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C157 1-163-145-00 CERAMIC CHIP 0.0015uF 5% 50V
C159 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C161 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C162 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
< CONNECTOR >
CN101 1-770-706-11 CONNECTOR, FFC/FPC 23P
CN102 1-770-425-11 CONNECTOR, FFC/FPC 16P
< IC >
IC101 8-752-369-78 IC CXD2545Q
IC102 8-759-455-91 IC BA6392FP-E2
IC103 8-752-072-45 IC CXA1821M-T6
IC104 8-759-271-86 IC TC7SH04FU
< TRANSISTOR >
Q101 8-729-010-08 TRANSISTOR MSB710-R
Q102 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q103 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R101 1-216-077-00 METAL CHIP 15K 5% 1/10W
R102 1-216-097-91 RES, CHIP 100K 5% 1/10W
R103 1-216-077-00 METAL CHIP 15K 5% 1/10W
R104 1-216-085-00 METAL CHIP 33K 5% 1/10W
R105 1-216-097-91 RES, CHIP 100K 5% 1/10W
R106 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R107 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R108 1-216-073-00 METAL CHIP 10K 5% 1/10W
R109 1-216-121-91 RES, CHIP 1M 5% 1/10W
R110 1-216-025-91 RES, CHIP 100 5% 1/10W
R112 1-216-049-91 RES, CHIP 1K 5% 1/10W
R123 1-216-073-00 METAL CHIP 10K 5% 1/10W
R124 1-216-097-91 RES, CHIP 100K 5% 1/10W
R125 1-216-033-00 METAL CHIP 220 5% 1/10W
R126 1-216-033-00 METAL CHIP 220 5% 1/10W
R127 1-216-033-00 METAL CHIP 220 5% 1/10W
R131 1-216-037-00 METAL CHIP 330 5% 1/10W
R134 1-216-049-91 RES, CHIP 1K 5% 1/10W
R141 1-216-089-91 RES, CHIP 47K 5% 1/10W
R142 1-216-081-00 METAL CHIP 22K 5% 1/10W
R143 1-216-103-00 METAL CHIP 180K 5% 1/10W
R144 1-216-103-00 METAL CHIP 180K 5% 1/10W
R146 1-216-073-00 METAL CHIP 10K 5% 1/10W
R147 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R148 1-216-001-00 METAL CHIP 10 5% 1/10W
R149 1-216-003-11 RES, CHIP 12 5% 1/10W
R150 1-216-025-91 RES, CHIP 100 5% 1/10W
R151 1-216-025-91 RES, CHIP 100 5% 1/10W
R152 1-216-073-00 METAL CHIP 10K 5% 1/10W
R153 1-216-073-00 METAL CHIP 10K 5% 1/10W
R154 1-216-025-91 RES, CHIP 100 5% 1/10W
R155 1-216-025-91 RES, CHIP 100 5% 1/10W
R156 1-216-025-91 RES, CHIP 100 5% 1/10W
R158 1-216-109-00 METAL CHIP 330K 5% 1/10W
R159 1-216-097-91 RES, CHIP 100K 5% 1/10W
AUDIO BD
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
