Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 76 —
R160 1-216-295-91 SHORT 0
R161 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R162 1-216-101-00 METAL CHIP 150K 5% 1/10W
R171 1-216-025-91 RES, CHIP 100 5% 1/10W
R172 1-216-025-91 RES, CHIP 100 5% 1/10W
R173 1-216-025-91 RES, CHIP 100 5% 1/10W
R175 1-216-025-91 RES, CHIP 100 5% 1/10W
R176 1-216-073-00 METAL CHIP 10K 5% 1/10W
R177 1-216-073-00 METAL CHIP 10K 5% 1/10W
R178 1-216-073-00 METAL CHIP 10K 5% 1/10W
R179 1-216-025-91 RES, CHIP 100 5% 1/10W
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
************************************************************
* 1-669-420-11 CD (P) BOARD
************
< CONNECTOR >
CNL102 1-568-860-21 SOCKET, CONNECTOR 17P
< DIODE >
D221 8-719-071-41 DIODE SELS5923C-TP15 (PBC OFF)
D222 8-719-071-41 DIODE SELS5923C-TP15 (VCD)
D223 8-719-071-41 DIODE SELS5923C-TP15 (PBC)
D224 8-719-071-42 DIODE SEL5723C-TP15 (®)
D225 8-719-071-42 DIODE SEL5723C-TP15 (®)
D226 8-719-071-40 DIODE SMLS79723C-TP15 (1)
D227 8-719-071-40 DIODE SMLS79723C-TP15 (2)
D228 8-719-071-40 DIODE SMLS79723C-TP15 (3)
D229 8-719-071-42 DIODE SEL5723C-TP15 (PLAY)
D230 8-719-071-41 DIODE SELS5923C-TP15 (PAUSE)
< TRANSISTOR >
Q211 8-729-029-21 TRANSISTOR DTA114ESA
Q212 8-729-029-21 TRANSISTOR DTA114ESA
Q213 8-729-029-21 TRANSISTOR DTA114ESA
Q214 8-729-029-21 TRANSISTOR DTA114ESA
Q215 8-729-029-21 TRANSISTOR DTA114ESA
Q216 8-729-029-21 TRANSISTOR DTA114ESA
Q217 8-729-029-21 TRANSISTOR DTA114ESA
Q218 8-729-029-21 TRANSISTOR DTA114ESA
Q219 8-729-029-21 TRANSISTOR DTA114ESA
Q220 8-729-029-21 TRANSISTOR DTA114ESA
Q221 8-729-029-21 TRANSISTOR DTA114ESA
Q222 8-729-029-21 TRANSISTOR DTA114ESA
Q223 8-729-029-21 TRANSISTOR DTA114ESA
< RESISTOR >
R241 1-249-407-11 CARBON 150 5% 1/4W F
R242 1-249-407-11 CARBON 150 5% 1/4W F
R243 1-249-407-11 CARBON 150 5% 1/4W F
R244 1-249-407-11 CARBON 150 5% 1/4W F
R245 1-249-407-11 CARBON 150 5% 1/4W F
R246 1-249-407-11 CARBON 150 5% 1/4W F
R247 1-249-407-11 CARBON 150 5% 1/4W F
R248 1-249-407-11 CARBON 150 5% 1/4W F
R249 1-249-407-11 CARBON 150 5% 1/4W F
R250 1-249-407-11 CARBON 150 5% 1/4W F
R251 1-249-407-11 CARBON 150 5% 1/4W F
R252 1-249-407-11 CARBON 150 5% 1/4W F
R253 1-249-407-11 CARBON 150 5% 1/4W F
R261 1-249-401-11 CARBON 47 5% 1/4W F
R262 1-249-403-11 CARBON 68 5% 1/4W F
R263 1-247-807-31 CARBON 100 5% 1/4W
R264 1-249-407-11 CARBON 150 5% 1/4W F
R265 1-249-407-11 CARBON 150 5% 1/4W F
R266 1-249-409-11 CARBON 220 5% 1/4W F
R267 1-249-411-11 CARBON 330 5% 1/4W
R268 1-249-413-11 CARBON 470 5% 1/4W F
R269 1-249-415-11 CARBON 680 5% 1/4W F
R270 1-249-417-11 CARBON 1K 5% 1/4W F
< SWITCH >
S270 1-762-750-11 SWITCH, TACTILE (PLAY/PAUSE)
S271 1-762-750-11 SWITCH, TACTILE (STOP)
S272 1-762-750-11 SWITCH, TACTILE (OPEN/CLOSE)
S273 1-762-750-11 SWITCH, TACTILE (3)
S274 1-762-750-11 SWITCH, TACTILE (2)
S275 1-762-750-11 SWITCH, TACTILE (1)
S276 1-762-750-11 SWITCH, TACTILE (DISC SKIP/EX-CHANGE)
S277 1-762-750-11 SWITCH, TACTILE (PREV)
S278 1-762-750-11 SWITCH, TACTILE (RETURN)
S279 1-762-750-11 SWITCH, TACTILE (SELECT)
S280 1-762-750-11 SWITCH, TACTILE (NEXT)
************************************************************
* 1-658-575-11 CONNECTOR BOARD
*****************
< CONNECTOR >
* CN701 1-568-946-11 PIN, CONNECTOR 8P
CN702 1-750-413-11 CONNECTOR, FFC/FPC 8P
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R703 1-249-435-11 CARBON 33K 5% 1/4W
R704 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W F
************************************************************
* A-2007-732-A LEAF SW BOARD, COMPLETE
************************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20% 10V
< CONNECTOR >
CN1001 1-568-860-11 SOCKET, CONNECTOR 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS119
D1002 8-719-911-19 DIODE 1SS119
< CABLE >
* DM1001 1-784-581-11 HOLDER, CABLE (2.5MM PITCH) 4P
CD (P) CONNECTOR LEAF SWBD
