Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 77 —
< IC >
IC1001 8-749-014-38 IC PHOTO INTERRUPTER SG-264
IC1002 8-749-014-38 IC PHOTO INTERRUPTER SG-264
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA
< RESISTOR >
R907 1-247-879-11 CARBON 100K 5% 1/4W
R1001 1-249-409-11 CARBON 220 5% 1/4W F
R1002 1-249-409-11 CARBON 220 5% 1/4W F
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-856-00 CARBON 11K 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K (TAPE SPEED(HIGH))
RV1002 1-241-785-11 RES, ADJ, CARBON 10K
(TAPE SPEED(NORMAL))
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY) (A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY) (B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (A HALF)
S1004 1-771-205-11 SWITCH, LEAF (A 120/70)
S1005 1-771-205-11 SWITCH, LEAF (REC A)
S1006 1-771-333-11 SWITCH, LEAF (B HALF)
S1008 1-771-205-11 SWITCH, LEAF (B 120/70)
S1009 1-771-205-11 SWITCH, LEAF (REC B)
************************************************************
* A-4414-710-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C001 1-164-159-11 CERAMIC 0.1uF 50V
C128 1-162-306-11 CERAMIC 0.01uF 20% 16V
C129 1-104-665-11 ELECT 100uF 20% 10V
C130 1-162-282-31 CERAMIC 100PF 10% 50V
C131 1-164-159-11 CERAMIC 0.1uF 50V
C132 1-164-159-11 CERAMIC 0.1uF 50V
C133 1-164-159-11 CERAMIC 0.1uF 50V
C134 1-164-159-11 CERAMIC 0.1uF 50V
C135 1-162-284-31 CERAMIC 150PF 10% 50V
C136 1-162-284-31 CERAMIC 150PF 10% 50V
C137 1-164-159-11 CERAMIC 0.1uF 50V
C138 1-104-665-11 ELECT 100uF 20% 10V
C139 1-128-551-11 ELECT 22uF 20% 25V
C140 1-164-159-11 CERAMIC 0.1uF 50V
C301 1-126-960-11 ELECT 1uF 20% 50V
C302 1-130-479-00 MYLAR 0.0047uF 5% 50V
C303 1-136-165-00 FILM 0.1uF 5% 50V
C304 1-136-165-00 FILM 0.1uF 5% 50V
C305 1-126-964-11 ELECT 10uF 20% 50V
C306 1-126-960-11 ELECT 1uF 20% 50V
C307 1-126-959-11 ELECT 0.47uF 20% 50V
C308 1-126-964-11 ELECT 10uF 20% 50V
C309 1-137-194-81 FILM 0.47uF 5% 50V
C310 1-162-290-31 CERAMIC 470PF 10% 50V
C311 1-126-964-11 ELECT 10uF 20% 50V
C312 1-126-959-11 ELECT 0.47uF 20% 50V
C313 1-162-294-31 CERAMIC 0.001uF 10% 50V
C314 1-126-964-11 ELECT 10uF 20% 50V
C315 1-126-963-11 ELECT 4.7uF 20% 50V
C316 1-104-665-11 ELECT 100uF 20% 10V
C317 1-104-665-11 ELECT 100uF 20% 10V
C331 1-164-159-11 CERAMIC 0.1uF 50V
C332 1-164-159-11 CERAMIC 0.1uF 50V
C333 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C334 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C335 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C336 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C351 1-126-960-11 ELECT 1uF 20% 50V
C352 1-130-479-00 MYLAR 0.0047uF 5% 50V
C353 1-136-165-00 FILM 0.1uF 5% 50V
C354 1-136-165-00 FILM 0.1uF 5% 50V
C355 1-126-964-11 ELECT 10uF 20% 50V
C356 1-126-960-11 ELECT 1uF 20% 50V
C357 1-126-959-11 ELECT 0.47uF 20% 50V
C358 1-126-964-11 ELECT 10uF 20% 50V
C359 1-137-194-81 FILM 0.47uF 5% 50V
C360 1-162-290-31 CERAMIC 470PF 10% 50V
C702 1-126-961-11 ELECT 2.2uF 20% 50V
C752 1-126-961-11 ELECT 2.2uF 20% 50V
C813 1-104-664-11 (CD OPTICAL DIGITAL OUT)
IC301 8-759-495-26 IC HA12215
< TRANSISTOR >
Q102 8-729-040-20 TRANSISTOR RT1P137L
Q103 8-729-029-66 TRANSISTOR DTC114ESA
Q104 8-729-040-20 TRANSISTOR RT1P137L
Q106 8-729-900-80 TRANSISTOR DTC114ES
Q331 8-729-116-56 TRANSISTOR 2SB1068-L
Q332 8-729-029-66 TRANSISTOR DTC114ESA
Q333 8-729-116-56 TRANSISTOR 2SB1068-L
Q334 8-729-029-66 TRANSISTOR DTC114ESA
Q335 8-729-029-66 TRANSISTOR DTC114ESA
Q336 8-729-116-56 TRANSISTOR 2SB1068-L
Q337 8-729-045-21 TRANSISTOR 2SD1513TP-LK
Q338 8-729-029-21 TRANSISTOR DTA114ESA
Q339 8-729-029-66 TRANSISTOR DTC114ESA
Q340 8-729-116-56 TRANSISTOR 2SB1068-L
Q341 8-729-045-21 TRANSISTOR 2SD1513TP-LK
Q342 8-729-029-21 TRANSISTOR DTA114ESA
Q343 8-729-029-66 TRANSISTOR DTC114ESA
Q852 8-729-018-60 TRANSISTOR 2SD2012-LC
Q855 8-729-018-59 TRANSISTOR 2SB1375-LC
< RESISTOR >
R130 1-247-807-31 CARBON 100 5% 1/4W
R131 1-247-807-31 CARBON 100 5% 1/4W
R132 1-247-807-31 CARBON 100 5% 1/4W
R133 1-247-807-31 CARBON 100 5% 1/4W
R134 1-247-807-31 CARBON 100 5% 1/4W
LEAF SW MAIN
