Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 78 —
R135 1-247-807-31 CARBON 100 5% 1/4W
R136 1-247-807-31 CARBON 100 5% 1/4W
R139 1-249-429-11 CARBON 10K 5% 1/4W
R140 1-249-429-11 CARBON 10K 5% 1/4W
R141 1-249-429-11 CARBON 10K 5% 1/4W
R142 1-249-429-11 CARBON 10K 5% 1/4W
R143 1-247-807-31 CARBON 100 5% 1/4W
R146 1-249-417-11 CARBON 1K 5% 1/4W F
R147 1-249-429-11 CARBON 10K 5% 1/4W
R148 1-249-429-11 CARBON 10K 5% 1/4W
R149 1-247-807-31 CARBON 100 5% 1/4W
R150 1-247-807-31 CARBON 100 5% 1/4W
R151 1-247-807-31 CARBON 100 5% 1/4W
R152 1-249-429-11 CARBON 10K 5% 1/4W
R153 1-249-419-11 CARBON 1.5K 5% 1/4W F
R154 1-249-419-11 CARBON 1.5K 5% 1/4W F
R155 1-249-427-11 CARBON 6.8K 5% 1/4W F
R156 1-249-427-11 CARBON 6.8K 5% 1/4W F
R157 1-249-429-11 CARBON 10K 5% 1/4W
R161 1-247-807-31 CARBON 100 5% 1/4W
R162 1-247-807-31 CARBON 100 5% 1/4W
R166 1-249-429-11 CARBON 10K 5% 1/4W
R168 1-247-807-31 CARBON 100 5% 1/4W
R301 1-249-435-11 CARBON 33K 5% 1/4W
R302 1-249-421-11 CARBON 2.2K 5% 1/4W F
R303 1-247-807-31 CARBON 100 5% 1/4W
R304 1-247-807-31 CARBON 100 5% 1/4W
R305 1-249-421-11 CARBON 2.2K 5% 1/4W F
R306 1-249-428-11 CARBON 8.2K 5% 1/4W F
R307 1-249-428-11 CARBON 8.2K 5% 1/4W F
R308 1-249-425-11 CARBON 4.7K 5% 1/4W F
R309 1-249-433-11 CARBON 22K 5% 1/4W
R311 1-247-903-00 CARBON 1M 5% 1/4W
R312 1-247-884-11 CARBON 160K 5% 1/4W
R313 1-249-441-11 CARBON 100K 5% 1/4W
R315 1-249-429-11 CARBON 10K 5% 1/4W
R316 1-249-432-11 CARBON 18K 5% 1/4W
R317 1-249-429-11 CARBON 10K 5% 1/4W
R318 1-249-429-11 CARBON 10K 5% 1/4W
R319 1-247-893-11 CARBON 390K 5% 1/4W
R321 1-249-422-11 CARBON 2.7K 5% 1/4W F
R322 1-249-428-11 CARBON 8.2K 5% 1/4W F
R324 1-247-876-11 CARBON 75K 5% 1/4W
R325 1-247-876-11 CARBON 75K 5% 1/4W
R326 1-249-417-11 CARBON 1K 5% 1/4W F
R327 1-249-437-11 CARBON 47K 5% 1/4W
R328 1-249-425-11 CARBON 4.7K 5% 1/4W F
R329 1-249-437-11 CARBON 47K 5% 1/4W
R330 1-249-425-11 CARBON 4.7K 5% 1/4W F
R331 1-249-437-11 CARBON 47K 5% 1/4W
R332 1-249-415-11 CARBON 680 5% 1/4W F
R333 1-249-421-11 CARBON 2.2K 5% 1/4W F
R334 1-249-415-11 CARBON 680 5% 1/4W F
R335 1-249-421-11 CARBON 2.2K 5% 1/4W F
R336 1-249-437-11 CARBON 47K 5% 1/4W
R337 1-249-417-11 CARBON 1K 5% 1/4W F
R338 1-249-411-11 CARBON 330 5% 1/4W
R339 1-249-437-11 CARBON 47K 5% 1/4W
R340 1-249-437-11 CARBON 47K 5% 1/4W
R341 1-249-417-11 CARBON 1K 5% 1/4W F
R342 1-249-411-11 CARBON 330 5% 1/4W
R343 1-249-437-11 CARBON 47K 5% 1/4W
R351 1-249-435-11 CARBON 33K 5% 1/4W
R352 1-249-421-11 CARBON 2.2K 5% 1/4W F
R353 1-247-807-31 CARBON 100 5% 1/4W
R354 1-247-807-31 CARBON 100 5% 1/4W
R355 1-249-421-11 CARBON 2.2K 5% 1/4W F
R356 1-249-428-11 CARBON 8.2K 5% 1/4W F
R357 1-249-428-11 CARBON 8.2K 5% 1/4W F
R358 1-249-425-11 CARBON 4.7K 5% 1/4W F
R359 1-249-435-11 CARBON 33K 5% 1/4W
R704 1-249-417-11 CARBON 1K 5% 1/4W F
R705 1-249-438-11 CARBON 56K 5% 1/4W
R706 1-249-417-11 CARBON 1K 5% 1/4W F
R754 1-249-417-11 CARBON 1K 5% 1/4W F
R755 1-249-438-11 CARBON 56K 5% 1/4W
R756 1-249-417-11 CARBON 1K 5% 1/4W F
R855 1-249-417-11 CARBON 1K 5% 1/4W F
R859 1-249-417-11 CARBON 1K 5% 1/4W F
! R861 1-212-853-00 FUSIBLE 6.8 5% 1/4W F
! R862 1-212-853-00 FUSIBLE 6.8 5% 1/4W F
< VARIABLE RESISTOR >
RV301 1-238-600-11 RES, ADJ, CARBON 10K (REC LEVEL L)
RV351 1-238-600-11 RES, ADJ, CARBON 10K (REC LEVEL R)
< VIBRATOR >
X101 1-760-489-11 VIBRATOR, CERAMIC 5MHz
************************************************************
* 1-658-578-11 MOTOR (SLIDE) BOARD
********************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 20% 16V
C804 1-162-306-11 CERAMIC 0.01uF 20% 16V
C805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D801 8-719-921-48 DIODE MTZJ-T-72-5.6C
D804 8-719-911-19 DIODE 1SS119
D805 8-719-911-19 DIODE 1SS119
< IC >
IC801 8-759-274-09 IC BA6286N
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W F
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY (OPEN/CLOSE DET)
************************************************************
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
MAIN MOTOR (SLIDE)
