Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 79 —
* 1-658-577-11 MOTOR (TURN) BOARD
*******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 20% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-983-66 DIODE MTZJ-T-72-3.6B
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R706 1-249-411-11 CARBON 330 5% 1/4W
R707 1-249-401-11 CARBON 47 5% 1/4W F
************************************************************
* 1-669-418-11 REGULATOR BOARD
*****************
7-685-646-79 SCREW +BVTP 3 × 8 TYPE2 N-S
< CAPACITOR >
C850 1-164-159-11 CERAMIC 0.1uF 50V
C851 1-164-159-11 CERAMIC 0.1uF 50V
C852 1-164-159-11 CERAMIC 0.1uF 50V
C855 1-164-159-11 CERAMIC 0.1uF 50V
C865 1-104-664-11 ELECT 47uF 20% 25V
C866 1-104-664-11 ELECT 47uF 20% 25V
< DIODE >
D851 8-719-911-19 DIODE 1SS119
D852 8-719-911-19 DIODE 1SS119
< IC >
IC851 8-759-231-58 IC TA7812S
IC852 8-759-231-53 IC TA7805S
IC853 8-759-604-86 IC M5F7807L
IC854 8-759-231-53 IC TA7805S
************************************************************
* 1-658-576-11 SENSOR BOARD
*************
< IC >
IC702 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
IC703 8-749-924-30 IC PHOTO REFLECTOR GP2S28
< RESISTOR >
R701 1-249-416-11 CARBON 820 5% 1/4W F
R702 1-249-407-11 CARBON 150 5% 1/4W F
************************************************************
* 1-669-422-11 TC (A) BOARD
************
< RESISTOR >
R209 1-249-415-11 CARBON 680 5% 1/4W F
R210 1-249-417-11 CARBON 1K 5% 1/4W F
R211 1-249-419-11 CARBON 1.5K 5% 1/4W F
< SWITCH >
S260 1-762-750-11 SWITCH, TACTILE (DECK A STOP)
S261 1-762-750-11 SWITCH, TACTILE (DECK A REV)
S262 1-762-750-11 SWITCH, TACTILE (DECK A PLAY)
************************************************************
* 1-669-423-11 TC (B) BOARD
************
< JACK >
CNJ105 1-770-396-11 HOUSING, CONNECTOR(PC BOARD)3P
< RESISTOR >
R201 1-249-401-11 CARBON 47 5% 1/4W F
R202 1-249-403-11 CARBON 68 5% 1/4W F
< SWITCH >
S251 1-762-750-11 SWITCH, TACTILE (DECK A PLAY)
S252 1-762-750-11 SWITCH, TACTILE (DECK A REV)
S253 1-762-750-11 SWITCH, TACTILE (DECK A STOP)
************************************************************
* 1-669-419-11 TC LED BOARD
************
< DIODE >
D201 8-719-071-42 DIODE SEL5723C-TP15 (DECK B PLAY)
D202 8-719-071-42 DIODE SEL5723C-TP15 (DECK B REV)
D203 8-719-071-41 DIODE SELS5923C-TP15 (PAUSE)
D204 8-719-071-44 DIODE SELS5223C-TP15 (REC)
D205 8-719-071-42 DIODE SEL5723C-TP15 (DECK A PLAY)
D206 8-719-071-42 DIODE SEL5723C-TP15 (DECK A REV)
< TRANSISTOR >
Q201 8-729-029-21 TRANSISTOR DTA114ESA
Q202 8-729-029-21 TRANSISTOR DTA114ESA
Q203 8-729-029-21 TRANSISTOR DTA114ESA
Q204 8-729-029-21 TRANSISTOR DTA114ESA
Q205 8-729-029-21 TRANSISTOR DTA114ESA
Q206 8-729-029-21 TRANSISTOR DTA114ESA
< RESISTOR >
R221 1-249-407-11 CARBON 150 5% 1/4W F
R222 1-249-407-11 CARBON 150 5% 1/4W F
R223 1-249-407-11 CARBON 150 5% 1/4W F
R224 1-249-407-11 CARBON 150 5% 1/4W F
R225 1-249-407-11 CARBON 150 5% 1/4W F
R226 1-249-407-11 CARBON 150 5% 1/4W F
************************************************************
MOTOR (TURN) REGULATOR SENSOR TC (A) TC (B) TC LED
