– 28 –
3-6. CABINET (FRONT), REEL ASSY
3-7. CABINET (REAR), REEL BOARD, CONTROL BOARD
2
Cabinet (rear)
1
Remove three solders
(Cord with plug)
1
Remove two solders
(From battery terminals
1
Remove four solders
(From reel board)
Reel board
Control board
5
1
4
Cabinet (rear) ASSY
Cabinet (front)
Reel board
Surface of contacts
Reel ASSY
Lid, Battery case
2
Screws (M 1.7)
3
Screw, Step
2
Screws (M 1.7)
Note on instalation :
Apply grease (J-2502-028-1)
to the surface of contacts on
the reel board.
<ANTENNA CONTROLLER SECTION>
