– 68 –
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
AEP : AC adaptor is attached
7AEP : AC adaptor is not attached
Les composants identifiés par une
marque ! sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference num-
ber, please include the board.
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number specified.
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3683-029-A ANTENNA BOARD, COMPLETE
***********************
< CAPACITOR >
C1 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C2 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C6 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C7 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C8 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C9 1-104-908-11 TANTAL. CHIP 47uF 20% 4V
C10 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C11 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< DIODE >
D1 8-719-421-40 DIODE MA77
D2 8-719-421-40 DIODE MA77
D5 8-713-101-57 DIODE 1T369-M20-T8A
D6 8-713-101-57 DIODE 1T369-M20-T8A
D7 8-713-101-57 DIODE 1T369-M20-T8A
D8 8-713-101-57 DIODE 1T369-M20-T8A
D9 8-719-988-61 DIODE 1SS355TE-17
D10 8-719-988-61 DIODE 1SS355TE-17
D11 8-719-988-61 DIODE 1SS355TE-17
D12 8-719-988-61 DIODE 1SS355TE-17
D13 8-719-988-61 DIODE 1SS355TE-17
D14 8-719-800-76 DIODE 1SS226
< JACK >
J1 1-569-215-11 JACK (FROM ANTENNA CONTROLLER)
J2 1-573-996-11 JACK, SMALL (WATERPROOF)
(FROM ANTENNA CONTROLLER)
< JUMPER RESISTOR >
JC1 1-216-864-11 METAL CHIP 0 5% 1/16W
JC2 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L1 1-408-412-00 INDUCTOR 18uH
L2 1-410-658-31 INDUCTOR CHIP 220uH
L3 1-412-979-21 INDUCTOR 1uH
< TRANSISTOR >
Q1 8-729-402-55 TRANSISTOR 2SB1218A-R
Q2 8-766-002-46 TRANSISTOR SGM2016AP-T7
< RESISTOR >
R1 1-216-813-11 METAL CHIP 220 5% 1/16W
R2 1-216-845-11 METAL CHIP 100K 5% 1/16W
R3 1-216-813-11 METAL CHIP 220 5% 1/16W
R4 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5 1-216-845-11 METAL CHIP 100K 5% 1/16W
R6 1-216-845-11 METAL CHIP 100K 5% 1/16W
R7 1-216-837-11 METAL CHIP 22K 5% 1/16W
R8 1-216-805-11 METAL CHIP 47 5% 1/16W
R9 1-216-813-11 METAL CHIP 220 5% 1/16W
R10 1-216-809-11 METAL CHIP 100 5% 1/16W
< TRANSFORMER >
T1 1-426-357-11 TRANSFORMER, RF
**************************************************************
* A-3683-030-A CONTROL BOARD, COMPLETE
*************************
< CAPACITOR >
C901 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C902 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C903 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< DIODE >
D901 8-719-812-41 LED TLR124 (POWER)
D902 8-719-800-76 DIODE 1SS226
< IC >
IC901 8-759-568-84 IC S-80815ANNP-EDC-T2
< COIL >
L901 1-410-658-31 INDUCTOR CHIP 220uH
L902 1-410-658-31 INDUCTOR CHIP 220uH
ANTENNA CONTROL
