– 69 –
< TRANSISTOR >
Q901 8-729-402-32 TRANSISTOR 2SD1819A-R
Q902 8-729-800-71 TRANSISTOR 2SB815B7-TB
Q903 8-729-402-32 TRANSISTOR 2SD1819A-R
< RESISTOR >
R901 1-216-845-11 METAL CHIP 100K 5% 1/16W
R902 1-216-845-11 METAL CHIP 100K 5% 1/16W
R903 1-216-833-11 METAL CHIP 10K 5% 1/16W
R904 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R905 1-216-845-11 METAL CHIP 100K 5% 1/16W
R906 1-216-833-11 METAL CHIP 10K 5% 1/16W
R907 1-216-833-11 METAL CHIP 10K 5% 1/16W
R908 1-216-845-11 METAL CHIP 100K 5% 1/16W
**************************************************************
* A-3683-026-A KEY BOARD, COMPLETE
*******************
3-384-797-01 SCREW
< CAPACITOR >
C701 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
* CN701 1-766-598-11 HOUSING, FPC CONNECTOR(ZIF)24P
< RESISTOR >
R701 1-218-953-11 RES,CHIP 1K 5% 1/16W
R702 1-218-953-11 RES,CHIP 1K 5% 1/16W
R703 1-218-953-11 RES,CHIP 1K 5% 1/16W
R704 1-218-953-11 RES,CHIP 1K 5% 1/16W
R705 1-218-953-11 RES,CHIP 1K 5% 1/16W
R706 1-218-953-11 RES,CHIP 1K 5% 1/16W
R707 1-218-953-11 RES,CHIP 1K 5% 1/16W
R708 1-218-953-11 RES,CHIP 1K 5% 1/16W
R709 1-218-953-11 RES,CHIP 1K 5% 1/16W
R710 1-218-953-11 RES,CHIP 1K 5% 1/16W
R711 1-218-953-11 RES,CHIP 1K 5% 1/16W
R712 1-218-953-11 RES,CHIP 1K 5% 1/16W
R713 1-218-953-11 RES,CHIP 1K 5% 1/16W
R714 1-218-953-11 RES,CHIP 1K 5% 1/16W
R715 1-218-953-11 RES,CHIP 1K 5% 1/16W
R716 1-218-953-11 RES,CHIP 1K 5% 1/16W
R717 1-218-953-11 RES,CHIP 1K 5% 1/16W
R718 1-218-953-11 RES,CHIP 1K 5% 1/16W
R719 1-218-953-11 RES,CHIP 1K 5% 1/16W
R720 1-218-953-11 RES,CHIP 1K 5% 1/16W
R721 1-218-953-11 RES,CHIP 1K 5% 1/16W
R722 1-218-953-11 RES,CHIP 1K 5% 1/16W
R723 1-218-953-11 RES,CHIP 1K 5% 1/16W
R724 1-218-953-11 RES,CHIP 1K 5% 1/16W
R725 1-218-953-11 RES,CHIP 1K 5% 1/16W
R726 1-218-953-11 RES,CHIP 1K 5% 1/16W
R727 1-218-953-11 RES,CHIP 1K 5% 1/16W
R728 1-218-953-11 RES,CHIP 1K 5% 1/16W
R729 1-218-953-11 RES,CHIP 1K 5% 1/16W
R730 1-218-953-11 RES,CHIP 1K 5% 1/16W
R731 1-218-953-11 RES,CHIP 1K 5% 1/16W
R732 1-218-953-11 RES,CHIP 1K 5% 1/16W
R733 1-218-953-11 RES,CHIP 1K 5% 1/16W
R734 1-218-953-11 RES,CHIP 1K 5% 1/16W
R735 1-218-953-11 RES,CHIP 1K 5% 1/16W
R736 1-218-953-11 RES,CHIP 1K 5% 1/16W
R737 1-218-953-11 RES,CHIP 1K 5% 1/16W
R738 1-218-953-11 RES,CHIP 1K 5% 1/16W
< SWITCH >
S701 1-692-453-11 SWITCH, KEY BOARD (1)
S702 1-692-453-11 SWITCH, KEY BOARD (4)
S703 1-692-453-11 SWITCH, KEY BOARD (7)
S704 1-692-453-11 SWITCH, KEY BOARD (DIRECT)
S705 1-692-453-11 SWITCH, KEY BOARD (FM/AM)
S706 1-692-453-11 SWITCH, KEY BOARD (AM BAND LOCAL/
WORLD)
S707 1-692-453-11 SWITCH, KEY BOARD (MY)
S708 1-692-453-11 SWITCH, KEY BOARD (LABEL EDIT)
S709 1-692-453-11 SWITCH, KEY BOARD (2)
S710 1-692-453-11 SWITCH, KEY BOARD (5)
S711 1-692-453-11 SWITCH, KEY BOARD (8)
S712 1-692-453-11 SWITCH, KEY BOARD (0)
S713 1-692-453-11 SWITCH, KEY BOARD (STANDBY MEMORY a)
S714 1-692-453-11 SWITCH, KEY BOARD (BBC)
S715 1-692-453-11 SWITCH, KEY BOARD (DW)
S716 1-692-453-11 SWITCH, KEY BOARD (DST ERASE)
S717 1-692-453-11 SWITCH, KEY BOARD (3)
S718 1-692-453-11 SWITCH, KEY BOARD (6)
S719 1-692-453-11 SWITCH, KEY BOARD (9)
S720 1-692-453-11 SWITCH, KEY BOARD (DISPLAY EXE)
S721 1-692-453-11 SWITCH, KEY BOARD (STANDBY MEMORY b)
S722 1-692-453-11 SWITCH, KEY BOARD (VOA)
S723 1-692-453-11 SWITCH, KEY BOARD (OTH)
S724 1-692-453-11 SWITCH, KEY BOARD (TIME SET ENTER)
S725 1-692-453-11 SWITCH, KEY BOARD
(JOG/TUNE/SCAN
•
/1 +)
S726 1-692-453-11 SWITCH, KEY BOARD (TIME DIF /)
S727 1-692-453-11 SWITCH, KEY BOARD (TIME DIF ?)
S728 1-692-453-11 SWITCH, KEY BOARD
(JOG/TUNE/SCAN – 1?
•
)
S729 1-692-453-11 SWITCH, KEY BOARD (SYNC)
S730 1-692-453-11 SWITCH, KEY BOARD (SSB)
S731 1-692-453-11 SWITCH, KEY BOARD (POWER ON/OFF)
S732 1-692-453-11 SWITCH, KEY BOARD (SLEEP)
S733 1-572-922-11 SWITCH, SLIDE (HOLD c)
S734 1-572-921-11 SWITCH, KEY BOARD (RESET)
S735 1-692-453-11 SWITCH, KEY BOARD (LIGHT)
**************************************************************
* A-3683-027-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C102 1-115-156-11 CERAMIC CHIP 1uF 10V
C103 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C104 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
