48
Board
Name
Board PWB (A side) Detail
BB8
3.6.5 USB Port 2 – No Detection / Cannot Play / No picture / No Sound – Checking Point
C7029
Have 5V?
USB (B-board Checking) – Checking 5V Points [USB Port 2]
