Board
Name
Board PWB (A side) Detail
BB8 board
(A side)
(3.3V)
CL1000
(1.8V)
CL1001
(12V)
CL1006
F1000
BB8 board
(A side)
Detail
CL1001
(1.8V)
CL1000
(3.3V)
F1000
CL1006
(12V)
