Sony KD-43X720E - Slide Number 6

6
Reference 43” 49” 55” Remarks
13 14 17
4-167-019-22
SCREW, +PSW M3X8
2 2 2
7-685-647-79
SCREW +BVTP 3X10 TYPE2 IT-3
*Rear cover can be dissembled without detach stand
*Removed AC COVER and AC CORD – only for 55”
Step1 : Ensure all screws are removed.
Screw type and quantity to dissemble RC
Step2 : Take out the rear cover
43” , 49” 55”
