Sony KD-43X720E - Slide Number 54

54
3-1. KD-55X7*E
3-1-1. Disassembly, Exploded View
REF.
NO.
DESCRIPTION PART NO.
KD-55X700E KD-55X705E KD-55X706E KD-55X720E KD-55X725E KD-55X727E
LA1 BR6 LA8 UC2 LA1 ECU LA8 AR4 CO1
1 AC COVER 4-297-989-01 • • • • • • • • •
2 LABEL, UNDER TERMINAL (CPN) 4-595-715-31 n/a n/a n/a
•
n/a n/a n/a n/a n/a
2 LABEL, UNDER TERMINAL (CPN) 4-595-715-21 • • • n/a • • • • •
3 REAR COVER (L CPN) A 4-696-594-01
•
n/a n/a
•
•
n/a n/a n/a n/a
3 REAR COVER (L CPN) A A-2182-150-A n/a
•
n/a n/a n/a n/a n/a n/a n/a
3 REAR COVER (L CPN) A 4-696-594-21 n/a n/a • n/a n/a • • • •
4 BRACKET, UNDER (FRE) 4-595-951-51 n/a n/a n/a
•
n/a n/a n/a n/a n/a
4 BRACKET, UNDER (FRE) 4-595-951-61 n/a
•
n/a n/a n/a n/a n/a n/a n/a
4 BRACKET, UNDER (FRE) 4-595-951-41 • n/a • n/a • • • • •
5 BRACKET, SIDE (FRE) 4-690-594-61
•
n/a n/a
•
•
n/a n/a n/a n/a
5 BRACKET, SIDE (FRE) A-2186-058-A n/a
•
n/a n/a n/a n/a n/a n/a n/a
5 BRACKET, SIDE (FRE) 4-690-594-51 n/a n/a • n/a n/a • • • •
6 SPEAKER BOX ASSY L 1-858-963-72
•
•
•
•
•
•
•
•
•
7 SPEAKER BOX ASSY R 1-858-963-82
•
•
•
•
•
•
•
•
•
8 SWITCH UNIT (3M-P-B3) 1-474-647-41 • n/a • • • • • • •
8 SWITCH UNIT (3M-P-B3) KIT A-2186-185-A n/a
•
n/a n/a n/a n/a n/a n/a n/a
9 SPACER(29)+C 4-691-335-01
•
n/a
•
•
•
•
•
•
•
9 SPACER(29)+C A-2188-444-A n/a • n/a n/a n/a n/a n/a n/a n/a
10 CARD, WIRELESS LAN 1-458-959-12
•
•
•
•
•
•
•
n/a
•
10 CARD, WIRELESS LAN 1-458-959-13 n/a n/a n/a n/a n/a n/a n/a
•
n/a
11 MOUNTED PWB E-T-CON (55) 1-897-152-11 • • • • • • • • •
12 GL71-STATIC CONVERTER(TV) 1-474-684-11
•
•
•
•
•
•
•
•
•
13 SHEET, INSULATION (FRE L) 4-691-111-11
•
•
•
•
•
•
•
•
•
14 UNIVERSAL SIL-TU SUT-RA243ZP 8-594-302-70 • n/a n/a • • n/a n/a n/a n/a
14 UNIVERSAL SIL-TU SUT-RT243ZP 8-594-308-30 n/a
•
•
n/a n/a
•
•
•
n/a
14 UNIVERSAL SIL-TU SUT-DB251ZP 8-594-325-00 n/a n/a n/a n/a n/a n/a n/a n/a •
15 COMPL_SVC_BB8_UC_PSU A-2183-093-A n/a n/a n/a • n/a n/a n/a n/a n/a
15 COMPL_SVC_BB8_BZ_PSU A-2183-107-A n/a
•
n/a n/a n/a n/a n/a n/a n/a
15 COMPL_SVC_BB8_MX_PSU A-2183-111-A • n/a n/a n/a • n/a n/a n/a n/a
15 COMPL_SVC_BB8_SA_PSU A-2183-103-A n/a n/a
•
n/a n/a n/a
•
n/a n/a
15 COMPL_SVC_BB8_CRECU_PSU A-2185-514-A n/a n/a n/a n/a n/a
•
n/a n/a n/a
15 COMPL_SVC_BB8_COL_PSU A-2183-105-A n/a n/a n/a n/a n/a n/a n/a n/a •
15 COMPL_SVC_BB8_AR_PSU A-2188-860-A n/a n/a n/a n/a n/a n/a n/a
•
n/a
16 SHEET, THERMAL(BM) 4-549-186-02
•
•
•
•
•
•
•
•
•
17 LCD PANEL(W55QWSEB) 1-812-343-11 n/a • n/a • n/a n/a n/a n/a n/a
17 LCD PANEL(W55QWSES) 1-812-342-11 • n/a • n/a • • • • •
STAND
51 STAND BASE (L FRE) A, N 4-595-696-72 n/a n/a n/a • n/a n/a n/a n/a n/a
51 STAND BASE (L FRE) A, N A-2182-157-A n/a
•
n/a n/a n/a n/a n/a n/a n/a
51 STAND BASE (L FRE) A, N 4-595-696-33 • n/a • n/a • • • • •
SMART CORE ASSY
71 PANEL, ORNAMENT (FRE) 4-596-101-01 • • • • • • • • •
72 GUIDE, LIGHT (FRE) 4-596-102-01
•
•
•
•
•
•
•
•
•
73 CASE, BOTTOM (FRE) 4-596-103-02
•
•
•
•
•
•
•
•
•
74 COVER, TOP (CPN) 4-690-016-01 • • • • • • • • •
75 HKZ MOUNT A-2179-172-A
•
n/a
•
•
•
•
•
•
•
75 HKZ BR MOUNT A-2186-086-A n/a
•
n/a n/a n/a n/a n/a n/a n/a
!
!
