KDF-46E2000/46E2010/50E2000/50E2010/55E2000/55E2010
KDF-46E2000/46E2010/50E2000/50E2010/55E2000/55E2010
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
VD3612 6-500-701-01 DIODE PGB1010603NR
VD3613 6-500-701-01 DIODE PGB1010603NR
VD3614 6-500-701-01 DIODE PGB1010603NR
VD3615 6-500-701-01 DIODE PGB1010603NR
VD3616 6-500-701-01 DIODE PGB1010603NR
VD3617 6-500-701-01 DIODE PGB1010603NR
VD3618 6-500-701-01 DIODE PGB1010603NR
VD3619 6-500-701-01 DIODE PGB1010603NR
CRYSTAL
X2000 1-813-049-21 VIBRATOR, CRYSTAL
X3000 1-795-753-21 VIBRATOR, CERAMIC
X3001 1-781-696-21 VIBRATOR, CRYSTAL
X3002 1-813-113-11 VIBRATOR, CRYSTAL
X3200 1-813-373-11 OSCILLATOR, CRYSTAL
X3400 1-813-114-21 VIBRATOR, CRYSTAL
X3500 1-813-546-21 QUARTZ CRYSTAL OSCILLATOR
X3600 1-813-267-11 VIBRATOR, CRYSTAL
X3601 1-767-984-21 VIBRATOR, CRYSTAL
X7300 1-813-760-21 QUARTZ CRYSTAL UNIT
X7301 1-813-759-21 QUARTZ CRYSTAL UNIT
G
A-1175-974-A G BOARD, COMPLETE
4-382-854-01 SCREW (M3X8), P, SW (+)
CAPACITOR
C6002 1-161-964-91 CERAMIC 0.0047µF 250V
C6003 1-161-964-91 CERAMIC 0.0047µF 250V
C6006 1-126-971-11 ELECT 470µF 20% 50V
C6008 1-137-852-31 ELECT 3300µF 20% 16V
C6009 1-128-950-31 ELECT 1000µF 20% 16V
C6020 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C6021 1-126-967-11 ELECT 47µF 20% 50V
C6022 1-126-962-11 ELECT 3.3µF 20% 50V
C6023 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C6024 1-100-831-91 CERAMIC CHIP 0.001µF 2% 50V
C6026 1-126-964-11 ELECT 10µF 20% 50V
C6028 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C6029 1-136-497-81 FILM 0.1µF 5% 50V
C6030 1-107-888-11 ELECT 47µF 20% 25V
C6032 1-107-824-11 CERAMIC 220pF 5% 1KV
C6033 1-107-824-11 CERAMIC 220pF 5% 1KV
C6034 1-165-954-11 FILM 56000pF 3% 800V
C6035 1-126-969-11 ELECT 220µF 20% 50V
C6036 1-126-963-11 ELECT 4.7µF 20% 50V
C6037 1-164-143-11 CERAMIC 0.001µF 10% 1KV
C6039 1-126-963-11 ELECT 4.7µF 20% 50V
C6040 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C6041 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C6044 1-126-940-11 ELECT 330µF 20% 25V
!
C6045 1-165-530-31 MYLAR 0.47µF 10 0V
C6049 1-137-852-31 ELECT 3300µF 20% 16V
C6052 1-137-190-91 FILM 0.22µF 5% 50V
C6054 1-126-935-11 ELECT 470µF 20% 16V
C6055 1-126-933-11 ELECT 100µF 20% 16V
C6056 1-126-947-11 ELECT 47µF 20% 35V
C6057 1-126-933-11 ELECT 100µF 20% 16V
C6060 1-126-933-11 ELECT 100µF 20% 16V
C6065 1-119-940-51 ELECT 4700µF 20% 50V
!
C6077 1-131-940-11 ELECT 1200µF 20% 250V
!
C6078 1-131-940-11 ELECT 1200µF 20% 250V
C6083 1-100-933-11 ELECT 47µF 20% 450V
C6084 1-100-933-11 ELECT 47µF 20% 450V
C6085 1-161-830-00 CERAMIC 0.0047µF 500V
!
C6274 1-165-530-31 MYLAR 0.47µF 10 0V
!
C6279 1-119-888-51 CERAMIC 2200pF 20% 250V
!
C6280 1-119-888-51 CERAMIC 2200pF 20% 250V
!
C6286 1-165-530-31 MYLAR 0.47µF 10 0V
C6292 1-126-947-11 ELECT 47µF 20% 35V
C6323 1-126-935-11 ELECT 470µF 20% 16V
C6500 1-128-548-11 ELECT 4700µF 20% 25V
C6501 1-126-947-11 ELECT 47µF 20% 35V
C6502 1-100-597-91 CERAMIC CHIP 0.1µF 10% 25V
C6800 1-126-935-11 ELECT 470µF 20% 16V
C6801 1-126-935-11 ELECT 470µF 20% 16V
C6802 1-128-992-21 ELECT CHIP 47µF 20% 25V
C6803 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C6804 1-128-992-21 ELECT CHIP 47µF 20% 25V
C6805 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C6806 1-128-992-21 ELECT CHIP 47µF 20% 25V
C6807 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C6808 1-128-992-21 ELECT CHIP 47µF 20% 25V
C6809 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C6812 1-165-675-21 ELECT CHIP 150µF 20% 10V
C6813 1-128-992-21 ELECT CHIP 47µF 20% 25V
BG
