Sony KDF-46E2000 - Page 123

123
KDF-46E2000/46E2010/50E2000/50E2010/55E2000/55E2010
KDF-46E2000/46E2010/50E2000/50E2010/55E2000/55E2010
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
C6814 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C6815 1-128-992-21 ELECT CHIP 47µF 20% 25V
C6816 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C6817 1-128-992-21 ELECT CHIP 47µF 20% 25V
C6818 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C6819 1-128-992-21 ELECT CHIP 47µF 20% 25V
C6820 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C6823 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C6824 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C6825 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C6826 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C6827 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C6828 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C6829 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C6830 1-128-991-21 ELECT CHIP 10µF 20% 50V
C6913 1-128-992-21 ELECT CHIP 47µF 20% 25V
C6915 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
CONNECTOR
* CN6002 1-793-660-11 PIN, CONNECTOR (PC BOARD)
*
!
CN6010 1-580-843-11 PIN, CONNECTOR (POWER)
CN6013 1-695-915-11 TAB (CONTACT)
* CN6018 1-793-660-11 PIN, CONNECTOR (PC BOARD)
CN6800 1-819-473-11 HEADER ASSEMBLY (FOR PWB)
* CN6801 1-508-742-11 PIN, CONNECTOR 3P
* CN6802 1-508-742-11 PIN, CONNECTOR 3P
CN6803 1-820-184-11 HEADER ASSEMBLY (PRINT PWB)
* CN6804 1-820-188-11 HEADER ASSEMBLY (PRINT PWB) 11P
* CN6904 1-820-295-11 HEADER ASSEMBLY (FOR PWB)
DIODE
!
D6000 8-719-510-53 DIODE D4SB60L
D6011 8-719-979-64 DIODE UF4005/23
D6014 6-500-335-01 DIODE MC2838-T112-1
D6015 6-500-567-31 DIODE 10ERB20-TB3
D6018 8-719-032-12 DIODE D1NS6
D6020 8-719-057-96 DIODE D10SC6M-4012
D6021 8-719-057-96 DIODE D10SC6M-4012
D6027 6-500-335-01 DIODE MC2838-T112-1
D6028 6-500-335-01 DIODE MC2838-T112-1
D6029 8-719-060-89 DIODE D4SBS6-F
D6032 6-501-223-01 DIODE S3G
D6033 6-501-223-01 DIODE S3G
D6034 8-719-064-49 DIODE D4SBL40
D6039 6-500-335-01 DIODE MC2838-T112-1
D6297 6-500-335-01 DIODE MC2838-T112-1
D6300 8-719-948-45 DIODE ERA22-08
D6302 6-500-335-01 DIODE MC2838-T112-1
D6307 6-500-335-01 DIODE MC2838-T112-1
D6500 8-719-511-40 DIODE S1VB40
D6501 6-500-335-01 DIODE MC2838-T112-1
D6503 6-500-335-01 DIODE MC2838-T112-1
D6800 6-500-335-01 DIODE MC2838-T112-1
D6801 6-500-335-01 DIODE MC2838-T112-1
D6802 6-500-335-01 DIODE MC2838-T112-1
D6803 6-500-335-01 DIODE MC2838-T112-1
D6804 6-500-335-01 DIODE MC2838-T112-1
D6805 6-500-335-01 DIODE MC2838-T112-1
D6806 6-500-335-01 DIODE MC2838-T112-1
D6807 6-500-335-01 DIODE MC2838-T112-1
D6808 6-500-335-01 DIODE MC2838-T112-1
D6809 6-500-335-01 DIODE MC2838-T112-1
D6811 6-500-335-01 DIODE MC2838-T112-1
D6812 8-719-069-55 DIODE UDZSTE-175.6B
FUSE
!
F6000 1-532-506-32 FUSE 6.3A 250V
FERRITE BEAD
FB6000 1-410-396-41 FERRITE 0.45µH
FB6001 1-410-396-41 FERRITE 0.45µH
FB6002 1-410-396-41 FERRITE 0.45µH
FB6003 1-412-911-11 FERRITE 0µH
FB6004 1-412-911-11 FERRITE 0µH
FB6800 1-414-921-11 FERRITE 0µH
FUSE HOLDER
!
FH6000 1-533-223-11 FUSE HOLDER 0A 0V
!
FH6001 1-533-223-11 FUSE HOLDER 0A 0V
IC
!
IC6000 6-705-810-01 IC MCZ3001DB
!
IC6001 6-709-499-01 IC RT9H301C-T112-1
IC6002 8-759-701-56 IC NJM78M05FA
IC6003 6-705-466-01 IC BA90BC0T
IC6007 6-708-388-01 IC KA278RA05CYDTU
G
