Sony KDF-46E2000 - Page 128

128
KDF-46E2000/46E2010/50E2000/50E2010/55E2000/55E2010
KDF-46E2000/46E2010/50E2000/50E2010/55E2000/55E2010
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
K
A-1175-422-A K BOARD, COMPLETE
4-382-854-01 SCREW (M3X8), P, SW (+)
CAPACITOR
C2500 1-126-767-11 ELECT 1000µF 20% 16V
C2501 1-126-947-11 ELECT 47µF 20% 35V
C2502 1-126-964-11 ELECT 10µF 20% 50V
C2503 1-126-935-11 ELECT 470µF 20% 16V
C2506 1-126-935-11 ELECT 470µF 20% 16V
C2507 1-126-960-11 ELECT 1µF 20% 50V
C2509 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2510 1-104-666-11 ELECT 220µF 20% 25V
C2511 1-128-550-11 ELECT 2200µF 20% 50V
C2512 1-136-497-81 FILM 0.1µF 5% 50V
C2513 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C2514 1-126-960-11 ELECT 1µF 20% 50V
C2515 1-126-960-11 ELECT 1µF 20% 50V
C2516 1-126-964-11 ELECT 10µF 20% 50V
C2517 1-126-964-11 ELECT 10µF 20% 50V
C2520 1-136-497-81 FILM 0.1µF 5% 50V
C2521 1-136-497-81 FILM 0.1µF 5% 50V
C2522 1-128-550-11 ELECT 2200µF 20% 50V
C2523 1-128-550-11 ELECT 2200µF 20% 50V
C2524 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C2525 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C2528 1-126-767-11 ELECT 1000µF 20% 16V
CONNECTOR
* CN2500 1-580-838-11 PIN, CONNECTOR (PC BOARD) 4P
* CN2501 1-793-660-11 PIN, CONNECTOR (PC BOARD)
* CN2502 1-564-509-11 PLUG, CONNECTOR 6P
DIODE
D2504 8-719-083-85 DIODE UDZSTE-1722B
D2505 8-719-083-85 DIODE UDZSTE-1722B
D2506 6-500-335-01 DIODE MC2838-T112-1
D2507 8-719-000-07 DIODE MC2836
D2508 8-719-000-07 DIODE MC2836
D2509 8-719-000-07 DIODE MC2836
D2510 6-500-335-01 DIODE MC2838-T112-1
D2511 6-500-335-01 DIODE MC2838-T112-1
D2513 6-500-335-01 DIODE MC2838-T112-1
FERRITE BEAD
FB2500 1-414-229-11 FERRITE 0µH
FB2501 1-414-229-11 FERRITE 0µH
IC
IC2500 8-759-246-70 IC TA8216HQ
IC LINK
PS2500 1-532-984-11 IC LINK 2A 50V
TRANSISTOR
Q2500 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q2501 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q2502 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q2503 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q2504 8-729-600-22 TRANSISTOR 2SA1235-F
RESISTOR
R2500 1-216-864-11 SHORT CHIP
R2501 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2502 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2503 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2504 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2505 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2506 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2509 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2510 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2511 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2512 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R2513 1-216-813-11 METAL CHIP 220 5% 1/10W
R2514 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2515 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2516 1-216-813-11 METAL CHIP 220 5% 1/10W
R2517 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2518 1-249-385-11 CARBON 2.2 5% 1/4W
R2519 1-249-385-11 CARBON 2.2 5% 1/4W
R2520 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2521 1-216-833-11 METAL CHIP 10K 5% 1/10W
K
