Sony KDF-46E2000 - Page 129

129
KDF-46E2000/46E2010/50E2000/50E2010/55E2000/55E2010
KDF-46E2000/46E2010/50E2000/50E2010/55E2000/55E2010
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
R2523 1-216-813-11 METAL CHIP 220 5% 1/10W
R2524 1-216-813-11 METAL CHIP 220 5% 1/10W
R2525 1-216-864-11 SHORT CHIP
R2526 1-216-864-11 SHORT CHIP
R2527 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R2528 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R2529 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2530 1-216-864-11 SHORT CHIP
R2531 1-216-864-11 SHORT CHIP
R2532 1-216-864-11 SHORT CHIP
R2533 1-216-864-11 SHORT CHIP
R2534 1-216-864-11 SHORT CHIP
R2535 1-216-864-11 SHORT CHIP
S2
A-1177-121-A S2 BOARD, MOUNTED
CAPACITOR
C160 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C161 1-165-908-11 CERAMIC CHIP 1µF 10% 10V
C162 1-162-915-11 CERAMIC CHIP 10pF 0.50pF 50V
C163 1-162-915-11 CERAMIC CHIP 10pF 0.50pF 50V
CONNECTOR
* CN160 1-820-182-11 HEADER ASSEMBLY (PRINT PWB)
IC
IC160 6-707-223-01 IC LM75BIM-5/NOPB
RESISTOR
R161 1-216-801-11 METAL CHIP 22 5% 1/10W
R162 1-216-801-11 METAL CHIP 22 5% 1/10W
R165 1-216-833-11 METAL CHIP 10K 5% 1/10W
R166 1-216-864-11 SHORT CHIP
R167 1-216-864-11 SHORT CHIP
T1
A-1177-122-A T1 BOARD, MOUNTED
CONNECTOR
* CN150 1-820-180-11 HEADER ASSEMBLY (PRINT PWB)
SWITCH
S150 1-786-591-11 SWITCH, MICRO
T2
A-1177-123-A T2 BOARD, MOUNTED
CONNECTOR
* CN155 1-820-297-11 HEADER ASSEMBLY (PRINT PWB)
SWITCH
S155 1-786-591-11 SWITCH, MICRO
U
A-1175-421-A U BOARD, COMPLETE
CAPACITOR
C8400 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8401 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8402 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8403 1-124-779-00 ELECT CHIP 10µF 20% 16V
C8404 1-127-573-11 CERAMIC CHIP 1µF 10% 16V
C8405 1-127-573-11 CERAMIC CHIP 1µF 10% 16V
C8406 1-126-193-11 ELECT CHIP 1µF 20% 50V
C8407 1-126-193-11 ELECT CHIP 1µF 20% 50V
C8408 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8409 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C8410 1-127-573-11 CERAMIC CHIP 1µF 10% 16V
C8411 1-124-779-00 ELECT CHIP 10µF 20% 16V
C8417 1-165-908-11 CERAMIC CHIP 1µF 10% 10V
C8418 1-165-908-11 CERAMIC CHIP 1µF 10% 10V
C8419 1-125-889-91 CERAMIC CHIP 2.2µF 10% 10V
KS2T1T2U
