— 61 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
SECTION 7: ELECTRICAL PARTS LIST
PARTS LISTING TABLE OF CONTENTS
A BOARD COMMON PARTS LISTING FS SERIES: Parts common to all FS series models .................................................................................................................................. 62
A BOARD COMMON PARTS LISTING FV SERIES: Parts common to all FV series models .................................................................................................................................. 68
A BOARD VARIANTS PARTS LISTING - Parts that belong only to the model specifi ed:........................................................................................................................................ 74
Refer to the designated variant parts list when seeking a part indicated by an asterick (*) on the A Board Schematic or by the phrase “VARIANT (SEE VARIANT PARTS LIST)”
on the Common Parts Listing
Model Page
KV-27FS13 74
KV-27FS17 75
KV-32FS13 76
KV-32FS17/34FS17 77
KV-34FS13C 78
KV-27FV17 79
KV-29FV17 80
KV-29FV17C 81
MA BOARD COMMON PARTS LISTING FS SERIES: Parts common to all FS series models ............................................................................................................................... 82
MA BOARD VARIANTS PARTS LISTING: Parts that belong only to the model specifi ed: ..................................................................................................................................... 87
Refer to the designated variant parts list when seeking a part indicated by an asterick (*) on the MA Board Schematic or by the phrase “VARIANT (SEE VARIANT PARTS LIST)”
on the Common Parts Listing
Model Page
KV-27FS13 87
KV-27FS17 88
KV-32FS13/34FS13C 89
KV-32FS17/34FS17 90
MA BOARD COMPLETE PARTS LISTING FV SERIES: (KV-27FV17/29FV17/29FV17C ONLY) ............................................................................................................................ 91
BC BOARD COMPLETE PARTS LISTING: (KV-27FV17/29FV17/29FV17C ONLY) ................................................................................................................................................ 95
P BOARD COMPLETE PARTS LISTING: (KV-27FS17/27FV17/29FV17/29FV17C/32FS17/34FS17 ONLY)........................................................................................................... 97
CA BOARD COMPLETE PARTS LISTING: (ALL MODELS) ................................................................................................................................................................................... 98
VA BOARD COMPLETE PARTS LISTING: (ALL MODELS).................................................................................................................................................................................... 99
D BOARD COMPLETE PARTS LISTING: (ALL MODELS)...................................................................................................................................................................................... 99
HX BOARD COMPLETE PARTS LISTING: (ALL MODELS) ................................................................................................................................................................................. 101
HA BOARD COMPLETE PARTS LISTING: (KV-27FV17/29FV17/29FV17C ONLY) .............................................................................................................................................. 102
HB BOARD COMPLETE PARTS LISTING: (KV-27FV17/29FV17/29FV17C ONLY) .............................................................................................................................................. 102
K BOARD COMPLETE PARTS LISTING: (ALL MODELS):................................................................................................................................................................................... 102
ACCESSORIES AND PACKAGING MATERIAL: .................................................................................................................................................................................................. 104
REMOTE COMMANDER:...................................................................................................................................................................................................................................... 104
