— 74 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
NOTE: The components identifi ed by shading
and ! mark are critical for safety. Replace only
with part number specifi ed.
A component identifi ed by this X symbol indicates that it
has been carefully factory-selected to satisfy regulations
regarding X-ray radiation. Should replacement be required,
replace only with the value originally used.
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
VARIANT PARTS LISTING
The parts on this page belong to the following model(s) only:
A BOARD VARIANT PARTS LIST (KV-27FS13)
* A-1299-502-A A COMPLETE PC BOARD
CAPACITOR
! C507 1-117-717-11 FILM 17000pF 3% 1.2KV
! C511 1-115-522-11 FILM 1µF 5% 250V
C514 1-109-844-11 FILM 0.68µF 5% 250V
! C520 1-129-722-00 FILM 0.047µF 5% 630V
C530 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C548 1-104-710-11 ELECT 22µF 160V
C550 1-107-846-11 FILM 0.1µF 5% 250V
! C555 1-117-629-11 FILM 2700pF 3% 1.2KV
! C607 1-136-311-11 MYLAR 0.47µF 20% 125V
! C612 1-128-717-11 ELECT 680µF 20% 250V
C625 1-135-412-51 ELECT 1000µF 20% 25V
C630 1-127-795-51 CERAMIC 3300pF 20% 250V
C631 1-113-924-11 CERAMIC 4700pF 20% 250V
C658 1-135-412-51 ELECT 1000µF 20% 25V
FERRITE BEAD
FB605 1-412-911-11 FERRITE 0µH
IC
IC502 8-759-980-58 IC TDA8172
! IC601 8-749-018-43 IC STR-F6426
COIL
L505 1-406-978-11 INDUCTOR 150µH
TRANSISTOR
! Q502 8-729-046-07 TRANSISTOR 2SD2578-YB
RESISTOR
R436 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R437 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R438 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R490 1-208-798-11 METAL CHIP 4.7K 1% 1/10W
! R513 1-215-907-11 METAL OXIDE 22 5% 3W
R514 1-216-683-11 METAL CHIP 22K 1% 1/10W
R518 1-249-427-11 CARBON 6.8K 5% 1/4W
R519 1-249-427-11 CARBON 6.8K 5% 1/4W
R529 1-216-109-00 RES-CHIP 330K 5% 1/10W
R530 1-216-077-91 RES-CHIP 15K 5% 1/10W
R533 1-215-457-00 METAL 33K 1% 1/4W
R534 1-215-458-00 METAL 36K 1% 1/4W
!X R564 1-208-836-11 METAL CHIP 180K 1% 1/10W
! R601 1-219-513-11 CARBON 4.7M 5% 1/2W
! R626 1-220-926-11 FUSIBLE 0.47 10% 1/2W
R627 1-215-483-00 METAL 390K 1% 1/4W
! R632 1-216-361-00 METAL OXIDE 0.22 5% 2W
R638 1-249-399-11 CARBON 33 5% 1/4W
! R641 1-216-362-11 METAL OXIDE 0.27 5% 2W
R646 1-249-419-11 CARBON 1.5K 5% 1/4W
! R660 1-215-924-00 METAL OXIDE 15K 5% 3W
TRANSFORMER
! T504 1-431-693-11 TRANSFORMER, HORIZONTAL LINEAR
! T505 1-453-310-11 FBT ASSY NX-4521//X4J4
! T602 1-435-617-11 TRANSFORMER, LINE FILTER
! T603 1-433-806-21 TRANSFORMER, REGULAT
THERMISTOR
! THP601 1-803-540-11 THERMISTOR
VARISTOR
! VDR601 1-803-585-11 VARISTOR ENE271D-10A
A
KV-27FS13
