— 87 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
VARIANT PARTS LISTING
The parts on this page belong to the following model(s) only:
MA BOARD VARIANT PARTS LIST (KV-27FS13)
* A-1304-200-A MA (VAR) MOUNTED PC BOARD
CAPACITOR
C380 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C381 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C382 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C389 1-115-185-11 CERAMIC CHIP 0.033µF 10% 50V
RESISTOR
R277 1-216-129-00 RES-CHIP 2.2M 5% 1/10W
R398 1-216-091-00 RES-CHIP 56K 5% 1/10W
R399 1-216-109-00 RES-CHIP 330K 5% 1/10W
KV-27FS13
MA
