— 89 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
VARIANT PARTS LISTING
The parts on this page belong to the following model(s) only:
MA BOARD VARIANT PARTS LIST
(KV-32FS13/34FS13C)
* A-1304-203-A MA (VAR) MOUNTED PC BOARD
CAPACITOR
C380 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C381 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C382 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C389 1-104-760-11 CERAMIC CHIP 0.047µF 10% 50V
RESISTOR
R277 1-216-133-91 RES-CHIP 3.3M 5% 1/10W
R398 1-216-109-00 RES-CHIP 330K 5% 1/10W
R399 1-216-689-11 RES-CHIP 39K 5% 1/10W
KV-32FS13/34FS13C
MA
