— 73 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
NOTE: The components identifi ed by shading
and ! mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es par un trame et une
marque ! sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES
COMMON PARTS LISTING FV SERIES
R639 1-249-421-11 CARBON 2.2K 5% 1/4W
R640 1-249-417-11 CARBON 1K 5% 1/4W
! R641 1-216-369-00 METAL OXIDE 1 5% 2W
R642 1-216-089-91 RES-CHIP 47K 5% 1/10W
R643 1-249-419-11 CARBON 1.5K 5% 1/4W
R644 1-247-843-11 CARBON 3.3K 5% 1/4W
R645 1-215-898-11 METAL OXIDE 10K 5% 2W
R646 VARIANT (SEE VARIANT PARTS LIST)
R648 1-216-398-11 METAL OXIDE 5.6 5% 3W
R649 1-249-417-11 CARBON 1K 5% 1/4W
R650 1-216-387-11 METAL OXIDE 0.68 5% 3W
R651 1-249-429-11 CARBON 10K 5% 1/4W
R653 1-216-049-11 RES-CHIP 1K 5% 1/10W
R655 1-216-049-11 RES-CHIP 1K 5% 1/10W
R656 1-249-429-11 CARBON 10K 5% 1/4W
R658 1-216-387-11 METAL OXIDE 0.68 5% 3W
R659 1-215-857-71 METAL OXIDE 10 5% 1W
R660 VARIANT (SEE VARIANT PARTS LIST)
R661 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R662 VARIANT (SEE VARIANT PARTS LIST)
R663 1-216-081-00 RES-CHIP 22K 5% 1/10W
R664 1-216-398-11 METAL OXIDE 5.6 5% 3W
R2003 1-249-425-11 CARBON 4.7K 5% 1/4W
RELAY
! RY601 1-755-198-11 RELAY
! RY602 1-755-266-11 RELAY, AC POWER
SWITCH
SW501 1-572-707-11 SWITCH LEVER
SW502 1-572-707-11 SWITCH LEVER
TRANSFORMER
! T501 1-437-195-11 TRANSFORMER, HORIZONTAL DRIVE
! T503 1-426-981-11 TRANSFORMER, FERRITE (PMT)
! T504 1-431-693-11 TRANSFORMER, HORIZONTAL LINEAR
! T505 1-453-310-11 FBT ASSY NX-4521//X4J4
T602 VARIANT (SEE VARIANT PARTS LIST)
T603 VARIANT (SEE VARIANT PARTS LIST)
! T604 1-431-852-11 TRANSFORMER, CONVERTER (SRT)
THERMISTOR
TH501 1-800-193-00 THERMISTOR
! TH601 1-803-586-11 THERMISTOR, NTC
THERMISTOR
! THP601 1-803-540-11 THERMISTOR
TUNER
! TU101 8-598-542-20 TUNER, FSS BTF-WA412
VARISTOR
VDR601 VARIANT (SEE VARIANT PARTS LIST)
