— 72 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
A component identifi ed by this
X
symbol indicates that it
has been carefully factory-selected to satisfy regulations
regarding X-ray radiation. Should replacement be required,
replace only with the value originally used.
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
COMMON PARTS LISTING FV SERIES
R505 1-249-401-11 CARBON 47 5% 1/4W
!
R506 1-215-883-11 METAL OXIDE 33 5% 2W
!
R507 1-260-328-11 CARBON 1K 5% 1/2W
R508 1-249-433-11 CARBON 22K 5% 1/4W
!
R509 1-215-891-11 METAL OXIDE 680 5% 2W
R510 1-249-411-11 CARBON 330 5% 1/4W
R511 1-249-377-11 CARBON 0.47 5% 1/4W
R512 1-215-910-00 METAL OXIDE 68 5% 3W
!
R513 1-215-907-11 METAL OXIDE 22 5% 3W
R514 1-216-683-11 METAL CHIP 22K 0.50% 1/10W
R516 1-249-425-11 CARBON 4.7K 5% 1/4W
R517 1-215-445-00 METAL 10K 1% 1/4W
R518 1-249-427-11 CARBON 6.8K 5% 1/4W
R519 1-249-427-11 CARBON 6.8K 5% 1/4W
!
R520 1-215-884-11 METAL OXIDE 47 5% 2W
!
R521 1-249-413-11 CARBON 470 5% 1/4W
R522 1-249-417-11 CARBON 1K 5% 1/4W
R523 1-216-073-91 RES-CHIP 10K 5% 1/10W
R524 1-249-429-11 CARBON 10K 5% 1/4W
!
R525 1-208-804-11 METAL CHIP 8.2K 0.50% 1/10W
R526 1-208-814-91 METAL CHIP 22K 0.50% 1/10W
R528 1-215-429-00 METAL 2.2K 1% 1/4W
R529 1-216-109-00 RES-CHIP 330K 5% 1/10W
R530 1-216-077-91 RES-CHIP 15K 5% 1/10W
R532 1-215-437-00 METAL 4.7K 1% 1/4W
R533 1-215-457-00 METAL 33K 1% 1/4W
R534 1-215-458-00 METAL 36K 1% 1/4W
R535 1-249-441-11 CARBON 100K 5% 1/4W
!
R536 1-214-798-21 METAL 1.8 1% 1/2W
!
R538 1-215-889-00 METAL OXIDE 330 5% 2W
!
R539 1-249-385-11 CARBON 2.2 5% 1/4W
R540 1-215-445-00 METAL 10K 1% 1/4W
R541 1-249-429-11 CARBON 10K 5% 1/4W
R543 1-247-887-00 CARBON 220K 5% 1/4W
!
R544 1-249-377-11 CARBON 0.47 5% 1/4W
R545 1-215-873-00 METAL OXIDE 4.7K 5% 1W
!
R546 1-249-377-11 CARBON 0.47 5% 1/4W
R547 1-216-455-21 METAL OXIDE 560 5% 2W
R548 1-216-377-11 METAL OXIDE 4.7 5% 2W
!
R549 1-260-288-11 CARBON 0.47 5% 1/2W
!
R550 1-260-288-11 CARBON 0.47 5% 1/2W
R551 1-215-907-11 METAL OXIDE 22 5% 3W
!
R553 1-216-363-00 METAL OXIDE 0.33 5% 2W
!
R554 1-249-429-11 CARBON 10K 5% 1/4W
!
R555 1-247-895-91 CARBON 470K 5% 1/4W
!
R556 1-249-417-11 CARBON 1K 5% 1/4W
!
R557 1-247-895-91 CARBON 470K 5% 1/4W
!
R558 1-216-097-11 RES-CHIP 100K 5% 1/10W
!
R559 1-216-073-91 RES-CHIP 10K 5% 1/10W
!
R560 1-215-879-11 METAL OXIDE 47K 5% 1W
!
R561 1-249-406-11 CARBON 120 5% 1/4W
!
R562 1-208-808-11 METAL CHIP 12K 0.50% 1/10W
!
R563 1-249-433-11 CARBON 22K 5% 1/4W
!X
R564 1-208-836-11 METAL CHIP 180K 0.50% 1/10W
!
R565 1-249-429-11 CARBON 10K 5% 1/4W
!
R566 1-216-073-91 RES-CHIP 10K 5% 1/10W
!
R567 1-216-073-91 RES-CHIP 10K 5% 1/10W
!
R568 1-215-882-00 METAL OXIDE 22 5% 2W
R569 1-214-798-21 METAL 1.8 1% 1/2W
R570 1-249-433-11 CARBON 22K 5% 1/4W
R571 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R572 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R601 VARIANT (SEE VARIANT PARTS LIST)
!
R602 1-249-389-11 CARBON 4.7 5% 1/4W
R603 1-215-485-00 METAL 470K 1% 1/4W
R607 1-215-859-00 METAL OXIDE 22 5% 1W
R608 1-240-205-11 CARBON 22M 5% 1/2W
R609 1-216-049-11 RES-CHIP 1K 5% 1/10W
R610 1-216-073-91 RES-CHIP 10K 5% 1/10W
R611 1-216-089-91 RES-CHIP 47K 5% 1/10W
R612 1-216-045-00 RES-CHIP 680 5% 1/10W
!
R613 1-219-512-11 CARBON 2.2M 5% 1/2W
R614 1-249-413-11 CARBON 470 5% 1/4W
R615 VARIANT (SEE VARIANT PARTS LIST)
!
R616 1-260-302-51 CARBON 6.8 5% 1/2W
R617 1-216-009-91 RES-CHIP 22 5% 1/10W
R618 1-249-440-11 CARBON 82K 5% 1/4W
R619 1-249-437-11 CARBON 47K 5% 1/4W
R620 1-249-417-11 CARBON 1K 5% 1/4W
!
R621 1-240-251-11 CEMENTED 6.8 5% 10W
R622 1-249-441-11 CARBON 100K 5% 1/4W
!
R623 1-260-324-11 CARBON 470 5% 1/2W
!
R624 1-249-429-11 CARBON 10K 5% 1/4W
R625 1-249-437-11 CARBON 47K 5% 1/4W
!
R626 1-202-933-61 FUSIBLE 0.1 10% 1/2W
R627 VARIANT (SEE VARIANT PARTS LIST)
R628 VARIANT (SEE VARIANT PARTS LIST)
R629 VARIANT (SEE VARIANT PARTS LIST)
R630 1-249-421-11 CARBON 2.2K 5% 1/4W
R631 VARIANT (SEE VARIANT PARTS LIST)
!
R632 1-217-611-00 METAL 0.1 10% 2W
R633 1-249-415-11 CARBON 680 5% 1/4W
R634 1-216-073-91 RES-CHIP 10K 5% 1/10W
R635 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R637 VARIANT (SEE VARIANT PARTS LIST)
R638 VARIANT (SEE VARIANT PARTS LIST)
A
To Next Page
