— 71 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
NOTE: The components identifi ed by shading
and ! mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es par un trame et une
marque ! sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES
COMMON PARTS LISTING FV SERIES
L503 1-406-677-11 INDUCTOR 10mH
L504 1-412-533-21 INDUCTOR 47µH
L505 1-406-978-11 INDUCTOR 150µH
L506 1-406-677-11 INDUCTOR 10mH
L507 1-412-552-11 INDUCTOR 2.2mH
! L510 1-412-528-11 INDUCTOR 18µH
L603 1-412-529-11 INDUCTOR 22µH
L604 1-412-525-31 INDUCTOR 10µH
L605 1-412-529-11 INDUCTOR 22µH
PHOTO COUPLER
! PH601 8-749-010-64 PHOTO COUPLER PC123FY2
IC LINK
! PS401 1-532-686-21 LINK, IC 2.7A/150V
TRANSISTOR
Q101 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q201 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q205 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q206 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q401 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q402 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q410 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q411 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q501 8-729-140-50 TRANSISTOR 2SC3209LK-TP
! Q502 8-729-046-07 TRANSISTOR 2SD2578-YB
! Q503 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
! Q504 8-729-053-87 TRANSISTOR KTC4370A
! Q505 8-729-200-17 TRANSISTOR 2SA1091O-TPE2
! Q506 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
! Q507 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q601 8-729-922-37 TRANSISTOR 2SD2144S-TP-UVW
Q602 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
! Q603 8-729-119-76 TRANSISTOR 2SA1309A-QRSTA
Q604 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
! Q605 8-729-046-40 TRANSISTOR 2SK2663
Q606 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q607 8-729-922-37 TRANSISTOR 2SD2144S-TP-UVW
Q608 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q609 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
RESISTOR
R105 1-208-798-11 METAL CHIP 4.7K 0.50% 1/10W
R107 1-216-025-11 RES-CHIP 100 5% 1/10W
R108 1-216-025-11 RES-CHIP 100 5% 1/10W
R115 1-216-295-91 SHORT
R201 1-216-113-00 RES-CHIP 470K 5% 1/10W
R202 1-216-113-00 RES-CHIP 470K 5% 1/10W
R203 1-216-022-00 RES-CHIP 75 5% 1/10W
R204 1-216-081-00 RES-CHIP 22K 5% 1/10W
R205 1-216-085-91 RES-CHIP 33K 5% 1/10W
R208 1-215-924-00 METAL OXIDE 15K 5% 3W
R210 1-216-022-00 RES-CHIP 75 5% 1/10W
R214 1-216-113-00 RES-CHIP 470K 5% 1/10W
R215 1-216-113-00 RES-CHIP 470K 5% 1/10W
R218 VARIANT (SEE VARIANT PARTS LIST)
R221 1-216-033-00 RES-CHIP 220 5% 1/10W
R224 1-208-798-11 METAL CHIP 4.7K 0.50% 1/10W
R225 1-208-798-11 METAL CHIP 4.7K 0.50% 1/10W
R226 1-216-022-00 RES-CHIP 75 5% 1/10W
R227 1-216-113-00 RES-CHIP 470K 5% 1/10W
R228 1-216-113-00 RES-CHIP 470K 5% 1/10W
R229 1-216-113-00 RES-CHIP 470K 5% 1/10W
R231 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R232 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R401 1-216-080-00 RES-CHIP 20K 5% 1/10W
R402 1-216-073-91 RES-CHIP 10K 5% 1/10W
R403 1-208-798-11 METAL CHIP 4.7K 0.50% 1/10W
R404 1-208-798-11 METAL CHIP 4.7K 0.50% 1/10W
R407 1-208-758-11 METAL CHIP 100 0.50% 1/10W
R408 1-208-758-11 METAL CHIP 100 0.50% 1/10W
R411 1-249-417-11 CARBON 1K 5% 1/4W
R412 1-216-113-00 RES-CHIP 470K 5% 1/10W
R413 1-216-113-00 RES-CHIP 470K 5% 1/10W
R414 1-249-417-11 CARBON 1K 5% 1/4W
R421 1-249-425-11 CARBON 4.7K 5% 1/4W
R422 1-249-389-11 CARBON 4.7 5% 1/4W
R426 1-216-009-91 RES-CHIP 22 5% 1/10W
R429 1-216-113-00 RES-CHIP 470K 5% 1/10W
R430 1-216-049-11 RES-CHIP 1K 5% 1/10W
R431 1-216-049-11 RES-CHIP 1K 5% 1/10W
R433 1-216-113-00 RES-CHIP 470K 5% 1/10W
R436 1-208-798-11 METAL CHIP 4.7K 0.50% 1/10W
R437 1-216-073-91 RES-CHIP 10K 5% 1/10W
R438 1-208-798-11 METAL CHIP 4.7K 0.50% 1/10W
R440 1-216-097-11 RES-CHIP 100K 5% 1/10W
R441 1-216-081-00 RES-CHIP 22K 5% 1/10W
R442 1-208-758-11 METAL CHIP 100 0.50% 1/10W
R445 1-216-073-91 RES-CHIP 10K 5% 1/10W
R446 1-215-457-00 METAL 33K 1% 1/4W
R447 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R454 1-216-025-11 RES-CHIP 100 5% 1/10W
R490 1-216-073-91 RES-CHIP 10K 5% 1/10W
R501 1-249-425-11 CARBON 4.7K 5% 1/4W
! R502 1-216-455-21 METAL OXIDE 560 5% 2W
! R503 1-249-425-11 CARBON 4.7K 5% 1/4W
