— 78 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
A component identifi ed by this
X
symbol indicates that it
has been carefully factory-selected to satisfy regulations
regarding X-ray radiation. Should replacement be required,
replace only with the value originally used.
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
VARIANT PARTS LISTING
The parts on this page belong to the following model(s) only:
A BOARD VARIANT PARTS LIST (KV-34FS13C)
* A-1299-506-A A COMPLETE PC BOARD
CAPACITOR
!
C507 1-117-652-11 FILM 22000pF 3% 1.2KV
!
C511 1-115-521-11 FILM 0.82µF 5% 250V
C514 1-115-521-11 FILM 0.82µF 5% 250V
C517 1-107-846-11 FILM 0.1µF 5% 250V
!
C520 1-130-118-91 FILM 0.051µF 5% 400V
C530 1-163-009-91 CERAMIC CHIP 0.001µF 10% 50V
C548 1-107-995-11 ELECT 100µF 160V
C550 1-117-667-11 FILM 0.47µF 5% 250V
!
C555 1-117-635-11 FILM 4700pF 3% 1.2KV
C615 1-130-202-00 FILM 0.022µF 10% 400V
C616 1-107-824-11 CERAMIC 220pF 5% 1KV
C625 1-135-572-51 ELECT 1000µF 20% 50V
C658 1-135-572-51 ELECT 1000µF 20% 50V
!
C660 1-128-714-11 ELECT 330µF 20% 400V
!
C661 1-128-714-11 ELECT 330µF 20% 400V
CONNECTOR
* CN604 1-573-963-11 PIN,CONNECTOR (PC BOARD) 3P
DIODE
D609 8-719-311-31 DIODE RU-1P
FERRITE BEAD
FB605 1-410-397-21 FERRITE 1.1µH
IC
IC502 8-759-192-71 IC STV9379
!
IC601 8-749-014-48 IC STR-F6656
COIL
L505 1-406-976-11 INDUCTOR 68µH
TRANSISTOR
!
Q502 8-729-045-26 TRANSISTOR 2SD2580-YB
RESISTOR
R436 1-216-073-91 RES-CHIP 10K 5% 1/10W
R437 1-216-073-91 RES-CHIP 10K 5% 1/10W
R438 1-216-073-91 RES-CHIP 10K 5% 1/10W
R490 1-216-073-91 RES-CHIP 10K 5% 1/10W
!
R513 1-215-905-11 METAL OXIDE 10 5% 3W
R514 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R518 1-215-439-00 METAL 5.6K 1% 1/4W
R519 1-215-439-00 METAL 5.6K 1% 1/4W
R529 1-216-107-00 RES-CHIP 270K 5% 1/10W
R530 1-208-812-11 METAL CHIP 18K 0.50% 1/10W
R533 1-215-453-00 METAL 22K 1% 1/4W
R534 1-215-457-00 METAL 33K 1% 1/4W
R537 1-215-373-31 METAL 10 1% 1/4W
!X
R564 1-208-824-11 METAL CHIP 56K 0.50% 1/10W
!
R615 1-218-265-11 METAL 8.2M 5% 1W
!
R626 1-202-933-61 FUSIBLE 0.1 10% 1/2W
R627 1-215-479-00 METAL 270K 1% 1/4W
R628 1-215-479-00 METAL 270K 1% 1/4W
R629 1-215-929-11 METAL OXIDE 100K 5% 3W
!
R632 1-217-611-00 METAL 0.1 10% 2W
!
R637 1-216-485-11 METAL OXIDE 5.6K 5% 3W
R638 1-249-402-11 CARBON 56 5% 1/4W
!
R641 1-216-369-00 METAL OXIDE 1 5% 2W
R646 1-249-418-11 CARBON 1.2K 5% 1/4W
!
R660 1-216-485-11 METAL OXIDE 5.6K 5% 3W
!
R662 1-216-485-11 METAL OXIDE 5.6K 5% 3W
TRANSFORMER
!
T504 1-435-098-11 TRANSFORMER, HORIZONTAL LINEAR
!
T505 1-453-338-11 FBT ASSY, NX-4600//X4J4
!
T602 1-426-717-11 TRANSFORMER, LINE FILTER (LFT)
!
T603 1-435-402-11 TRANSFORMER, CONVERTER (SRT)
THERMISTOR
!
THP601 1-803-540-11 THERMISTOR
VARISTOR
!
VDR601 1-803-967-11 VARISTOR (ENE621D-14A)
KV-34FS13C
A
