— 93 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
COMPLETE PARTS LISTING FV SERIES
Q305 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q306 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q356 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q357 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q365 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q368 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q375 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q378 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q379 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q380 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q387 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q388 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q389 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
RESISTOR
R001 1-216-043-91 RES-CHIP 560 5% 1/10W
R002 1-216-041-00 RES-CHIP 470 5% 1/10W
R003 1-247-807-31 CARBON 100 5% 1/4W
R004 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R005 1-216-295-91 SHORT
R006 1-216-025-11 RES-CHIP 100 5% 1/10W
R007 1-216-025-11 RES-CHIP 100 5% 1/10W
R008 1-216-049-11 RES-CHIP 1K 5% 1/10W
R009 1-216-121-11 RES-CHIP 1M 5% 1/10W
R010 1-216-033-00 RES-CHIP 220 5% 1/10W
R011 1-216-033-00 RES-CHIP 220 5% 1/10W
R012 1-216-045-00 RES-CHIP 680 5% 1/10W
R013 1-249-417-11 CARBON 1K 5% 1/4W
R014 1-216-073-91 RES-CHIP 10K 5% 1/10W
R015 1-216-073-91 RES-CHIP 10K 5% 1/10W
R016 1-216-041-00 RES-CHIP 470 5% 1/10W
R017 1-208-798-11 METAL CHIP 4.7K 0.50% 1/10W
R018 1-249-409-11 CARBON 220 5% 1/4W
R019 1-216-113-00 RES-CHIP 470K 5% 1/10W
R020 1-216-033-00 RES-CHIP 220 5% 1/10W
R021 1-216-073-91 RES-CHIP 10K 5% 1/10W
R022 1-249-409-11 CARBON 220 5% 1/4W
R023 1-249-429-11 CARBON 10K 5% 1/4W
R024 1-249-409-11 CARBON 220 5% 1/4W
R025 1-249-426-11 CARBON 5.6K 5% 1/4W
R026 1-249-426-11 CARBON 5.6K 5% 1/4W
R027 1-249-426-11 CARBON 5.6K 5% 1/4W
R028 1-216-049-11 RES-CHIP 1K 5% 1/10W
R029 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R030 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R031 1-216-355-11 METAL OXIDE 3.3 5% 1W
R032 1-216-033-00 RES-CHIP 220 5% 1/10W
R033 1-216-033-00 RES-CHIP 220 5% 1/10W
R034 1-216-033-00 RES-CHIP 220 5% 1/10W
R035 1-216-033-00 RES-CHIP 220 5% 1/10W
R036 1-216-049-11 RES-CHIP 1K 5% 1/10W
R037 1-249-409-11 CARBON 220 5% 1/4W
R038 1-216-049-11 RES-CHIP 1K 5% 1/10W
R039 1-216-045-00 RES-CHIP 680 5% 1/10W
R040 1-249-409-11 CARBON 220 5% 1/4W
R041 1-216-045-00 RES-CHIP 680 5% 1/10W
R042 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R043 1-249-417-11 CARBON 1K 5% 1/4W
R044 1-216-033-00 RES-CHIP 220 5% 1/10W
R045 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R046 1-216-033-00 RES-CHIP 220 5% 1/10W
R047 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R048 1-216-025-11 RES-CHIP 100 5% 1/10W
R050 1-216-033-00 RES-CHIP 220 5% 1/10W
R051 1-216-033-00 RES-CHIP 220 5% 1/10W
R052 1-249-417-11 CARBON 1K 5% 1/4W
R054 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R055 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R056 1-208-798-11 METAL CHIP 4.7K 0.50% 1/10W
R057 1-216-097-11 RES-CHIP 100K 5% 1/10W
R058 1-216-097-11 RES-CHIP 100K 5% 1/10W
R060 1-249-409-11 CARBON 220 5% 1/4W
R061 1-216-033-00 RES-CHIP 220 5% 1/10W
R064 1-216-295-91 SHORT
R069 1-249-409-11 CARBON 220 5% 1/4W
R070 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R071 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R073 1-249-425-11 CARBON 4.7K 5% 1/4W
R074 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R077 1-216-097-11 RES-CHIP 100K 5% 1/10W
R085 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R086 1-216-045-00 RES-CHIP 680 5% 1/10W
R087 1-216-045-00 RES-CHIP 680 5% 1/10W
R088 1-216-045-00 RES-CHIP 680 5% 1/10W
R089 1-216-033-00 RES-CHIP 220 5% 1/10W
R091 1-216-073-91 RES-CHIP 10K 5% 1/10W
R092 1-208-798-11 METAL CHIP 4.7K 0.50% 1/10W
R093 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R094 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R095 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R096 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R097 1-249-414-11 CARBON 560 5% 1/4W
R099 1-216-089-91 RES-CHIP 47K 5% 1/10W
R100 1-216-295-91 SHORT
R101 1-216-295-91 SHORT
R150 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R151 1-216-025-11 RES-CHIP 100 5% 1/10W
