Sony LDI-D100B - Page 49

3-30
IC508
IC502
IC507
IC443
J101
RGB terminal
CN501
Connect the adjusting
remote commander
CN206
For
adjustment
– MA-324 (H) BOARD (Side A) –
J1001
AUDIO IN jack
IC1106
IC1001
CN1004
Q1001
Q1002
CN1003
For
adjustment
– YC-148 (H) BOARD (Side A) –
Adjustment and Connection Location:
Fig. 3-4
3-30 E
adjusting remote
commander
RM-95
(J-6082-053-B)
extension cable
(J-6082-291-A)
Set
RGB terminal
J101
PC
+
–
regulated
power supply
+
–
+
–
digital
voltmeter
+
–
digital
voltmeter
regulated
power supply
battery terminals
DC IN 8.4 V jack
(J701)
